Installation steps:

1. Position the equipment so that it receives as less heat as possible from other devices.
2. Before turning on, the connection must be performed as indicated in the installation diagram,
the AV and IR port are not compulsory for use, so connect only if it is necessary.
3. Adjust the TV channel to the HDMI input where we have connected the EK DR-1.
4. Turn on the EK DR-1 with the remote-control button
5. Wait for all applications to load (only in case of first installation or return the product to its
factory settings). It should look like next image. The symbol
cable connected.

Controller buttons:

ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C
08172 Sant Cugat del Vallés · Barcelona (Spain)
Phone: +34935839543 · info@ek.plus · www.ek.plus
USER MANUAL EK DR-1
.
indicate that I have the LAN
1.-Power button.
2.-Mute button.
3.-Button to access settings.
4.-Shortcut button to KD Player.
5.-Switch Mouse/Cursor mode. Press
once to bring up the mouse on the
screen, press again to scroll with the
crosshair.
6.-Address crossover
button.
7.-Botón de Home, to go back to the
home screen if we're in another menu.
8.-Don't use.
9.-Button to go to the previous screen.
10.-Volume buttons.
and accept
