INTERFACES AND CONNECTION:
Interfaces:
Installation diagram:
ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C
08172 Sant Cugat del Vallés · Barcelona (Spain)
Phone: +34935839543 · info@ek.plus · www.ek.plus
USER MANUAL EK DR-1
1.-Power input.
2.-Ethernet port.
3.-HDMI output.
4.-Audio AV output.
5.-IR Extender port.
6.-2X USB 2.0 ports.
7.-TF (TransFlash)/Micro SD port.
1.-Connect power supply to 220v.
2.-Connect Ethernet port to the
Router.
3.-HDMI output to TELEVISION.
4.-Audio AV output to TV (Only if
you need).
5.-Connect to IR Extender (Only if
you need to).
4
