Installation and User's Guide
USER
MANUAL
Video Wall Solution
R4N SERIES
<All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein>

Advertisement

loading
Need help?

Need help?

Do you have a question about the R4N Series and is the answer not in the manual?

Questions and answers

Summary of Contents for OIC Korea R4N Series

  • Page 1 Installation and User's Guide USER MANUAL Video Wall Solution R4N SERIES <All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein>...
  • Page 2 [ USER MANUAL ] LCD Display Monitors Two-Year Limited Warranty Orion Images Corporation (“OIC”) warrants to the first purchaser that its LCD Display monitors are free from defects in materials and workmanship under normal use. The warranty is two years beginning on the date of invoice, as further described in the following text.
  • Page 3: Table Of Contents

    [ USER MANUAL ] <TABLE OF CONTENTS> SAFETY INSTRUCTION FCC RF INTERFERENCE STATEMENT INSTALLATION OSD MENU SETTING SPECIFICATION R4N COMMANDER (Video Wall Control Protocol) TROUBLESHOOTING LIMITED WARRANTY...
  • Page 4: Safety Instruction

    [ USER MANUAL ] 1. SAFETY INSTRUCTION • Follow this safety instruction to use the monitor properly and prevent the damage. * This safety instruction has “Warning” & “Caution” as below Warning - If the user does not follow this instruction, it may cause the serious damage to the user.
  • Page 5 [ USER MANUAL ] Warning For cleaning do not use liquid cleaners. Do not install this monitor on the outside Never touch the power plug with wet- and near water. It may cause damage to hands. the product, electric shock and fire. When lightning and thundering, unplug Unplug this product from the wall outlet, the monitor from the wall outlet and...
  • Page 6 [ USER MANUAL ] Cautions Place this product on a stable place. Install this monitor some distance If not, it may fall, causing serious from the wall and do not install unless damages to the monitor and people. proper ventilation is provided. The openings must not be blocked by When carrying this monitor, be careful curtain, rug or other similar surface.
  • Page 7 [ USER MANUAL ] Cautions Install this monitor about 50cm far from Do not press the LCD panel with hands or the eyes and an angle of 0~15 degrees the sharpened material hardly. below eyes. Too close installation may cause having weak sight. For cleaning, unplug the monitor from the Do not use the chemical liquid for cleaning.
  • Page 8: Fcc Rf Interference Statement

    [ USER MANUAL ] 2. FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 9: Installation

    [ USER MANUAL ] 3. INSTALLATION 3.1 UNPACKING Remove the package cover and place the product on a flat and secure surface or in the installation location. This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately.
  • Page 10 [ USER MANUAL ] KEYPAD 1) KEYPAD CONTROLLER KEYPAD This KEYPAD is attached to a magnet, so you can freely paste UTP Cable (1.5m) If you want to replace with a longer cable Please purchase separately *Depending on the product model type, there may be variations in appearance. OSD KEY FUNCTION On/Off the OSD menu or exit the source selection menu...
  • Page 11 [ USER MANUAL ] 3.4 CONNECTION 1) 46” - SIDE ① ② ③ ④ ⑤ ⑥ ⑦ - BOTTOM ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ① RS-232 IN RS-232 Control signal Input ② RS-232 OUT RS-232 Control signal Loop Output ③...
  • Page 12 [ USER MANUAL ] 2) 43”, 55” - SIDE ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ① DVI signal input ② VGA signal input ③ HDMI1 HDMI signal Input ④ HDMI2 HDMI signal Input ⑤...
  • Page 13 [ USER MANUAL ] 3.5 CONFIGURE THE VIDEO WALL 1. You can combine two or more monitors, and configure the VIDEO WALL. 2. If you want to configure VIDEO WALL, please contact your dealer or a professional installer. 3. JOINT BRACKET helps to easily adjust the VIDEO WALL. (Supplied with monitor) 4.
  • Page 14 [ USER MANUAL ] 3.6 REMOTE CONTROLLER POWER Power On or Off MUTE Turn on or off the speaker VIDEO1/CVBS1 Not functional VIDEO2/CVBS2 Not functional S-VIDEO Not functional Select VGA signal AUTO Auto adjustment of VGA source COLOR TEMP Select color temperature of screen Select DVI signal Select HDMI signal HDMI...
  • Page 15: Osd Menu Setting

    [ USER MANUAL ] 4. OSD MENU 4.1 Main OSD Menu Press a menu button “MENU/EXIT” on a KEYPAD or a remote controller to display this menu on the screen. ① Information of Windows 3840x2160p60Hz LT-Win 1920x1080p60Hz LB-Win ② Title of Main Menu ①...
  • Page 16 [ USER MANUAL ] 4.3 Image HDMI 3840x2160p60Hz IMAGE Brightness Contrast Gamma Dynamic Range Main Sharpness Sub Sharpness 3D De-interlace Ver:O.8.L.0.5 Default Available ITEM FUNCTION Value Mode Brightness Adjust a bright value between 0 ~ 100 Contrast Adjust a contrast value between 0 ~ 100 Gamma Select a 2.2 gamma Off or ON Select a dynamic range mode Off, DCR (Dynamic Contrast...
  • Page 17 [ USER MANUAL ] 4.4 Color HDMI 3840x2160p60Hz COLOR Color Temperature Green Blue Ver:O.8.L.0.5 Default Available ITEM FUNCTION Value Mode Color Select the color Temperature Normal Temperature Warm/Normal/Cool/User Adjust red gain value between 0 ~ 255 Green Adjust green gain value between 0 ~ 255 User mode Blue Adjust blue gain value between 0 ~ 255...
  • Page 18 [ USER MANUAL ] 4.5 Multi-Window HDMI 3840x2160p60Hz MULTI-WINDOW PIP Type Select Input2 Select Input3 Select Input4 PIP1 Size PIP1 Pos PBP1 Size Ver:O.8.L.0.5 Please note that while using Multi-Window function, HDMI1 and HDMI3 can’t be selected simultaneously. (In this case, an error may occur) Default Available ITEM...
  • Page 19 [ USER MANUAL ] 4.6 Video Wall 3840x2160p60Hz HDMI VIDEO WALL Set ID Video Wall Enable Position H. Ratio V. Ratio H. Start V. Start H. Size V. Size Ver:O.8.L.0.5 Default Available ITEM FUNCTION Value Mode Set ID Adjust the Set ID value between 1 ~ 99 Video Wall Enable Set Off or On to enable a video wall mode Set the sequence of installed monitors on the video wall...
  • Page 20 [ USER MANUAL ] 4.6.1 Position numerical order 4.7 VGA Default Available ITEM FUNCTION Value Mode Phase Adjust a phase to clear the screen between 0 ~ 100 Clock Adjust a clock to correct the screen between 0 ~ 10 D-SUB input only H.
  • Page 21 [ USER MANUAL ] 4.8 OSD HDMI 3840x2160p60Hz Horizontal Vertical Transparency OSD Time Out OSD Rotation Ver:O.8.L.0.5 Default Available ITEM FUNCTION Value Mode Adjust a horizontal position of the main menu between Horizontal 0 ~ 100 Vertical Adjust a vertical position of the main menu between 0 ~ 100 Transparency Adjust a transparency of the main menu between 0 ~ 10 OSD Time Out...
  • Page 22 [ USER MANUAL ] 4.9 SYSTEM HDMI 3840x2160p60Hz SYSTEM Language Aspect Ratio Over Scan Over Driver Audio Mute Audio Source Pixel Shift DP Speed FW Update Reset Ver:O.8.L.0.5 Default Available ITEM FUNCTION Value Mode Select a language type of OSD Menu. Language English But now, English only...
  • Page 23: Specification

    [ USER MANUAL ] 5. SPECIFICATION 5.1 General Specifications Model Name R4N43NNF R4N46UNF/UHF R4N46ENF/EHF R4N55UNF/UHF Bezel Width BEZEL to BEZEL 22.15(H) / 28.48(V) Screen Size (inch) 42.51 46.0" 46.0" 55.0" Resolution 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 Pixel Pitch (mm) 0.4902 x 0.4902...
  • Page 24 [ USER MANUAL ] Model Name R4N55ENF/EHF R4N55RNF/RHF Bezel Width BEZEL to BEZEL 0.88 Screen Size (inch) 55.0" 55.0" Resolution 1920 x 1080 1920 x 1080 Pixel Pitch (mm) 0.630 x 0.630 0.630 x 0.630 Brightness 500 cd/m² 700 cd/m² 500 cd/m² 700 cd/m²...
  • Page 25 [ USER MANUAL ] 5.2 Timing Mode Table Vertical MODE Resolution Input Standards Frequency(Hz) EDTV 480p 720x480 59.94 EDTV 576p 720x576 50.00 D-SUB/HDMI/DP HDTV720p 1280x720 50/60 HDTV1080i 1920x1080 50/60 HDMI/DP EIA-861B HDTV1080p 1920x1080 24/25/30/50/60 D-SUB/HDMI/DP UHDTV2160p 3840x2160 24/25/30 HDMI/DP UHDTV2160p 3840x2160 50/60 640x480...
  • Page 26 [ USER MANUAL ] 5.3 Video Wall RS232 Assignment / Specification Pin No. Name Pin 5 Pin 1 - D-SUB 9 pin - Input: Female, bottom position Pin 9 Pin 6 Input 5V(option) Pin No. Name Pin 1 Pin 5 - D-SUB 9 pin - Output: Male, top position Pin 6...
  • Page 27: R4N Commander (Video Wall Control Protocol)

    [ USER MANUAL ] 6. R4N COMMANDER (Video Wall Communication Protocol) This document defines all the command and messages exchanged between the Master (a PC or the other controller) and the Slave (the displays). It also describes the ways to send or read the commands or the messages.
  • Page 28 [ USER MANUAL ] 6.5 Transmission Formats This is the format that the computer will send to the display to execute commands. The format for this command transmission is as follows: - Data Length: 13 byte Ex) <STX>001PWRWOFF0<ETX> (Set ID: 1, “Power Off” Send) 0x0F ‘0’...
  • Page 29 [ USER MANUAL ] 6.6 Command List (Write)(PC ↔ Monitor) Power On/Off (PWR) 0x0F ‘P’ ‘W’ ‘R’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “-ON”: Power On “OFF”: Power Off Ex) <STX>001PWRWOFF0<ETX>...
  • Page 30 [ USER MANUAL ] Line Shift On/Off (LIN) 0x0F ‘L’ ‘I’ ‘N’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “-ON”: Line shift On “OFF”: Line shift Off Ex) <STX>001LINW-ON0<ETX> (Line Shift ON) Mute On/Off (MUT) 0x0F ‘M’...
  • Page 31 [ USER MANUAL ] Virtual Remote Control (RMT) 0x0F ‘R’ ‘M’ ‘T’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “MEN” (Menu) “SOU” (Source) “LEF” (Left & Volume-) “RIG” (Right & Volume+) “ENT”...
  • Page 32 [ USER MANUAL ] Vertical Set Count (VSC) 0x0F ‘V’ ‘S’ ‘C’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “001” ~ “015” Ex) <STX>001VSCW0100<ETX> (V-Set Count 10) Horizontal Edge Adjust (HEG) 0x0F ‘H’...
  • Page 33 [ USER MANUAL ] Display Sequence (SDS) 0x0F ‘S’ ‘D’ ‘S’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “001” ~ “100” Ex) <STX>001SDSW0010<ETX> (Display Sequence 1) Color Temperature Change (CTC) 0x0F ‘C’...
  • Page 34 [ USER MANUAL ] Contrast Adjust (FCC) 0x0F ‘F’ ‘C’ ‘C’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “000” ~ “100” Ex) <STX>001FCCW0400<ETX> (Contrast Adjust 40) Red Gain Adjust (FGR) 0x0F ‘F’...
  • Page 35 [ USER MANUAL ] Blue Gain Adjust (FGB) 0x0F ‘F’ ‘G’ ‘B’ ‘W’ 0x00 0x0D ASCII (capital letter) - ID1 ~ ID3: Set ID (“001” ~ “099”) - DA1 ~ DA3: “000” ~ “255” Ex) <STX>001FGBW0400<ETX> (Blue Gain Adjust 40) Red Offset Adjust (FOR) <Do not change>...
  • Page 36 [ USER MANUAL ] 6.7 Command List (Read) Edge Item Read Command (PC → Monitor) 0x0F ‘S’ ‘D’ ‘S’ ‘R’ 0x00 0x0D ASCII (capital letter) Edge Item Read Data (PC  Monitor) Seque Count Count 0x0F ‘E’ 0x0D ASCII Color Item Read Command (PC → Monitor) 0x0F ‘C’...
  • Page 37 [ USER MANUAL ] Model Info Read Command (PC → Monitor) 0x0F ‘M’ ‘D’ ‘L’ ‘R’ 0x00 0x0D ASCII (capital letter) Model Info Data (PC  Monitor) Set ID MDL1 MDL2 MDL3 PNL1 PNL2 VER1 VER2 VER3 VER4 0x0F ‘I’ 0x0D ASCII - MDL1 ~ MDL3: Model Type...
  • Page 38: Troubleshooting

    [ USER MANUAL ] 7. TROUBLESHOOTING When the following troubles are occurred, follow the trouble shooting. Before contacting a service center. Troubleshooting Troubleshooting Tip 1. Make sure if the power supply is connected property The screen doesn’t show up 2. Turn on the power. 3.
