- Page 1 20PX05-00 E2 2018-02-13 USB HID to Stereo Audio Interface PCI Express Mini Card User Manual...
-
Page 2: Table Of Contents
Contents Contents Contents............2 About this Document . -
Page 3: About This Document
This user manual is intended only for system developers and integrators, it is not intended for end users. It describes the design, functions and connection of the product. The manual does not include detailed information on individual components (data sheets etc.). PX5 product page with up-to-date information and downloads: www.men.de/products/px5/ History Issue... - Page 4 About this Document Conventions Indicates important information or warnings concerning situations which could result in personal injury, or damage or destruction of the component. Indicates important information concerning electrostatic discharge which could result in damage or destruction of the component. Indicates important information or warnings concerning proper functionality of the product described in this document.
-
Page 5: Product Safety
Only store the product in its original ESD-protected packaging. Retain the original packaging in case you need to return the product to MEN for repair. 20PX05-00 E2 2018-02-13 Page 5 ... -
Page 6: Legal Information
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE OR USE. In no event shall MEN be liable for more than the contract price for the products in question. If buyer does not notify MEN in writing within the foregoing warranty period, MEN shall have no liability or obligation to buyer hereunder. - Page 7 Legal Information Conformity MEN products are no ready-made products for end users. They are tested according to the standards given in the Technical Data and thus enable you to achieve certification of the product according to the standards applicable in your field of application.
-
Page 8: Product Overview
Product Overview Product Description Analog Audio Interface The PX5 is a PCI Express Mini Card providing an industry-grade USB HID to analog audio interface. It supports one differential stereo audio IN and one differential stereo audio OUT channel at line level. -
Page 9: Product Architecture
Product Overview Product Architecture 1.2.1 Interfaces Figure 1. Board layout – top view PCI Express Mini Card connector Audio connector 1.2.2 Functions Figure 2. Functional diagram Onboard connector Options Audio in Differential line receiver Audio in Differential line receiver USB stereo audio codec Audio out Line driver Audio out 20PX05-00 E2 2018-02-13 Page 9 ... -
Page 10: Technical Data
3 W max. Mechanical Specifications Dimensions: 30 mm x 50.95 mm x 5 mm (PCI Express Full-Mini Card) Weight: 8 g (PX5 only); 15 g (PX5 with cable) Environmental Specifications Temperature range (operation): -40°C to +85°C, compliant with EN 50155, class T1, T2, T3 or TX Temperature range (storage): -40°C to +85°C... -
Page 11: Product Identification
Product Identification MEN documentation may describe several different models and design revisions of the PX5. You can find the article number, design revision and serial number affixed to the PX5. Article number: Indicates the product family and model. This is also MEN’s main ... -
Page 12: Getting Started
» Power down the system and remove the PCI Express Mini Card carrier board. » Install the PX5 on the PCI Express Mini Card slot of the carrier board as described in the carrier board’s user manual. » Insert the carrier board into the system again »... -
Page 13: Functional Description
Functional Description Functional Description Power Supply The PX5 is supplied via the PCI Express Mini Card connector. USB Audio Interface Sampling rates with a resolution of 16bit: 8kHz 11.025 kHz 16 kHz 22.05 kHz 32 kHz ... -
Page 14: Adapter Cables
Audio line out right ground OUT_L_GND Audio line out left ground 3.2.1 Adapter Cables MEN offers two standard cables for connecting an amplifier to the USB audio interface. See the MEN website for ordering information: www.men.de/products/px5/#ord 3.2.1.1 MicroMatch Cable The MicroMatch cable supports: Two outputs with differential line ... -
Page 15: Table 6. Connector Types - D-Sub Cable
Functional Description 3.2.1.2 D-Sub Cable The D-Sub cable supports: Two outputs with differential line One input with differential line Table 6. Connector types – D-Sub cable Connector Type On cable 9-pin D-Sub receptacle connector Mating 9-pin D-Sub plug connector Table 7. -
Page 16: Pci Express Mini Card Interface
Functional Description PCI Express Mini Card Interface The PX5 uses USB isochronous data format on the PCI Express Mini Card interface. Table 8. Pin assignment – PCI Express Mini Card connector (USB 2.0) WAKE# +3.3V COEX1 COEX2 1.5V CLKREQ# UIM_PWR... - Page 17 Functional Description Please refer to the PCI Express Mini Card Specifications for further details: PCI Express Mini Card Electromechanical Specification Rev. 2.0 August 31, 2011 PCI Special Interest Group www.pcisig.com 20PX05-00 E2 2018-02-13 Page 17 ...
