Mueller Hydro-Guard HG-6 Operating Instructions Manual

Mueller Hydro-Guard HG-6 Operating Instructions Manual

Hydrant-based flushing system
Hide thumbs

Advertisement

Quick Links

HG-6
Hydrant-Based
Flushing System
!
WARNING:
1. Read and follow instructions carefully. Proper training and periodic review
regarding the use of this equipment is essential to prevent possible serious injury
and/or property damage. The instructions contained herein were developed for
using this equipment on fittings manufactured by Mueller Co. only, and may not be
applicable for any other use.
2. DO NOT exceed the pressure ratings of any components or equipment. Exceeding
the rated pressure may result in serious injury and/or property damage.
3. Safety goggles and other appropriate protective gear should be used. Failure to do
so could result in serious injury.
F 12777 3/21
OPERATING INSTRUCTIONS MANUAL

TABLE OF CONTENTS

PAGE
2
3 - 6
7
8
9
10
11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hydro-Guard HG-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mueller Hydro-Guard HG-6

Summary of Contents for Mueller Hydro-Guard HG-6

  • Page 1: Table Of Contents

    The instructions contained herein were developed for using this equipment on fittings manufactured by Mueller Co. only, and may not be applicable for any other use.

  • Page 2: Installation Instructions

    Please read and retain this flow away from the Hydro-Guard manual. It will be helpful for Unit or to be absorbed by the The Hydro-Guard HG-6 Hydrant- future reference, training, surrounding soil. The Unit’s ground- Based Flushing System is a troubleshooting, and maintenance.

  • Page 3: Programming Unit

    HG-6 FLUSHING SYSTEM Programming Unit PROGRAMMING HYDRO-GUARD UNIT FOR OPERATION Technical Data 1. Install the App: • Operating temperature range of From the App Store 32º to 120º F or Google Play • Operating Pressure: 7 to 200 psi Install the free K-RainBL App: Note: Where sustained pressures 2.
  • Page 4 HG-6 FLUSHING SYSTEM Programming Unit 6. The App will now search for devices in range. 7. Choose the Controller. The serial numbers that populate the device list can be found on the label located on the back of the controller housing with the designation “Default name.”...
  • Page 5 HG-6 FLUSHING SYSTEM Programming Unit HG-6 BUILT-IN: (INTEGRATED) Programming Setting Flush Sequence Start Times The NODE has the capability to NODE Programming Instructions hold 3 programs (A, B, C) and 4 1. Press RETURN / ENTER key until Batteries start times per program. When CLOCK icon is displayed.
  • Page 6 HG-6 FLUSHING SYSTEM Programming Unit Setting Flushing Days Battery Life Indicator NOTE: 1. Press RETURN / ENTER Remaining battery life can be – Pressing + or – key when running key until CALENDAR icon is in MANUAL FLUSH mode will modify estimated from the battery life displayed.

  • Page 7: Disassembly/Reassembly Instructions

    HG-6 FLUSHING SYSTEM Disassembly/Reassembly Instructions HG-6 DISASSEMBLY AND REASSEMBLY INSTRUCTIONS TOOLS NEEDED: 3/8" Socket, 7/16" Wrench, Philips screwdriver, A103 Security screwdriver. Disassembly 10. Loosen clamping bolt on bottom 5. Attach Controller to of outside face clamp. Latching Solenoid. 1. If attached to a fire hydrant; close hydrant’s water supply 11.

  • Page 8: Troubleshooting

    HG-6 FLUSHING SYSTEM Troubleshooting TROUBLESHOOTING THE PROGRAMMER If the LCD is not working, the Battery Replacement If you need further assistance, battery could be expired. If please contact us at It is recommended that batteries the flashing battery symbol 1.800.423.1323. be changed every six (6) months appears, the battery power is or when the low battery icon...

  • Page 9: Options

    HG-6 FLUSHING SYSTEM Options HYDRO-GUARD KEY FEATURES, OPTIONS AND UPGRADES From the integrated sample Integrated Sample Station Dechlorination stations to dechlorination Increase your control of The HG-6 Hydrant-Based upgrades, your Hydro-Guard chlorine or chloramines residual Flushing System has a built- Device offers an outstanding maintenance through the in Dechlorination chamber...

  • Page 10: Parts

    HG-6 FLUSHING SYSTEM Parts Stainless Steel Bluetooth Housing Controller Adjustable Control Valve Latching Sample Solenoid Valve Airgap Backflow Prevention 15.88-18.625 Adjustable Height Splash Plate 1. Available option on HG-6 / Basic 2. Not available on HG-6 / Basic 3. Only available on HG-6 / Basic...

  • Page 11: Notes

    HG-6 FLUSHING SYSTEM Notes...
  • Page 12 MWP does not provide products or services to third parties. MWP and each of its subsidiaries are liable only for their own acts and omissions and not those of each other. MWP brands include Mueller ®...
