- Page 1 Smart Sprinkler Controller with HD Camera User Guide VERSION 1.2...
-
Page 2: Table Of Contents
Understand Your Irrigation System The Yardian Installation Step 1. Replace your old controller Step 2. Install your Yardian controller Step 3. Download the Yardian app Step 4. Pair your Yardian to your profile Step 5. Wi-Fi onboarding Set-Up of the Yardian App... -
Page 3: What's In The Box
What’s in the Box 1. Yardian, the controller Operating -22°F to 122°F (-30°C to 50°C) Temperature Input: 100-240VAC, 50/60Hz, Max. 0.5A Power Output: 24VAC, Max. 750mA 2. Wi-Fi dongle 3. Labeling stickers 4. Wall screws and anchors... -
Page 4: Overview
Overview LED indicator Camera IR LED (night vision) : <Serial Number> : <MAC Number> Light sensor AA00754F YID : Product label Warranty label Wi-Fi reset button Wi-Fi dongle Terminal blocks... -
Page 5: Yardian Led Indicator
Yardian LED Indicator 1 second 1 second System Wi-Fi Station Mode Booting Up Connecting to Your Router Initializing Connected to Your Router Firmware Updating Watering (Do not turn off power) Reboot Required Wi-Fi AP Mode (Direct Control) (Press Wi-Fi Reset Button until LED turns red) -
Page 6: Wi-Fi Reset Button
Wi-Fi Reset Button Press : <Serial Number> : <MAC Number> AA00754F YID : Reset Wi-Fi Reset to factory default Press and hold for around 5 Press and hold for around 10 seconds, release when the LED seconds, release when the LED is blinking green and blue. -
Page 7: Understand Your Irrigation System
Common Wire Main Rain Sensor Master Valve Wire If you have a master Master Valve Wire valve, connect it to any zone and specify it in Yardian app. Master Valve RAIN SENSOR Valve ZONE 1 ZONE 2 ZONE 3 ZONE 4... -
Page 9: The Yardian Installation
Installation Set up your Yardian in a few easy steps... -
Page 10: Step 1. Replace Your Old Controller
Take a picture of your current wiring. This will help you identify the correct sequence of wires. Step Replace your old controller... - Page 11 Step 1. Disconnect your old controller and remove sprinkler wires. Adhere a numeric labeling sticker to tag each associated wire for easy identification. Remove your old controller from the wall. •Master Valve - Optional •Zones - Wires are Connected to Zone Valves •Common Wire or Ground Wire •Rain Sensor - Optional Zones...
-
Page 12: Step 2. Install Your Yardian Controller
Identify an appropriate spot to mount your Yardian so that the camera is able to view your designated location (e.g., inside the garage). Step Install your Yardian controller... - Page 13 Step 2. Open the top cover. Mark the wall for the screws. Mount the Yardian with the screws.
- Page 14 Step 2. Open the inside cover. PULL : <Serial Number> : <MAC Number> AA00754F YID : : <Serial Number> : <MAC Number> AA00754F YID : : <Serial Number> : <MAC Number> AA00754F YID : PUSH...
- Page 15 Note: Please specify rain sensor type (normally open or closed) : <Serial Number> : <MAC Number> in Yardian app if applicable. AA00754F YID : Note: If you have a master valve, connect it to any zone and specify...
- Page 16 Step 2. Close the inside cover and the top cover. PRESS HERE CLICK : <Serial Number> : <MAC Number> AA00754F YID : PRESS Note: Please make sure you HERE hear a click sound by pressing at the top of the inside cover.
- Page 17 Step 2. Plug the Yardian electrical cord into the home outlet.
-
Page 18: Step 3. Download The Yardian App
Create an account and personal profile. Sign in the Yardian app with your account. Step Download the User Guide Yardian app Video My Account Create Account... - Page 19 Step 3. Add Profile Enter your Profile Name and your Zip Code (or click on the map to find your location), then click the "Done" button to proceed. Note: The profile captures all the information about your yard at a specific location (e.g., your home).
-
Page 20: Step 4. Pair Your Yardian To Your Profile
Click the Yardian device setting card to start pairing. Step My Yardian Yardian Device Setting Unpaired Pair your Yardian Please Click To Pair to your profile Watering Schedule 2021-01-04 : Smart Watering Day °C | °F : Manual Watering Day... - Page 21 Step 4. Yardian Pairing Enter the 8-digit Yardian ID number (YID) on the device. Please Enter Your YID: Next : <Serial Number> : <Serial Number> : <MAC Number> : <MAC Number> AA00754F YID : AA00754F Y I D :...
-
Page 22: Step 5. Wi-Fi Onboarding
From the app, click the Yardian card and go to "Wi-Fi onboarding". Step My Yardian Yardian Device Setting Wi-Fi onboarding YID: AA00754F Offline Yardian will use historical ETo and rainfall weather data for watering schedules when it is offline. The Yardian is now paired to your Profile. - Page 23 Allow Yardian to access this device’s location? Select DENY ALLOW Zone 4 Zone 5 Zone 6 For Android users, please allow the Yardian app to access the device’s location to get a list of available networks. Zone 7 Zone 8 Zone 9...
- Page 24 5 seconds and release when you see the LED blinking green and blue. LED in purple! If your Yardian is in Wi-Fi AP mode for more than 15 minutes, you will be asked to reboot Yardian (Press Wi-Fi reset button until LED turns...
- Page 25 Step 5. Wi-Fi Onboarding Select the Yardian SSID. Step1. Select Yardian SSID YardianAA00 The Yardian app will scan for nearby : <Serial Number> : <MAC Number> wireless signals to provide you with AA00754F YID : a list of wireless networks to choose...
- Page 26 Step 5. This step applies to Android. This step applies to iOS. Specify your home Wi-Fi router Specify your home Wi-Fi router SSID # and password. SSID #. Wi-Fi Onboarding Accessory Setup Cancel Next Step 2. Specify Your Wi-Fi Router SSID This accessory will be set up to join My Wi-Fi Router “My Wi-Fi Router“.
- Page 27 Step 5. WARNING Check your Yardian LED: if it turns into Software may be updated when Yardian is connected to a steady green light, it means that you the Internet. Please DO NOT have successfully connected your turn off the power when the LED Yardian to the Wi-Fi network.
- Page 28 iOS 9.0+ and Android 4.4+...
-
Page 29: Set-Up Of The Yardian App
Setup of the Easy access to the settings with 5 simple tabs... - Page 30 You may review all information here Receive the latest information Home regarding your watering schedule, Yardian notifications, and more.
- Page 31 My Yardian Yardian will use historical ETo and rainfall weather data for Yardian Device Setting watering schedules when it is offline. YID: AA00754F Online Week Schedule Stop All Watering Activities Watering Schedule 2021-01-04 : Smart Watering Day Smart Manual Skip °C |...
- Page 32 You get to control all zones here Control your zones to start watering Control at any desired time with just a touch of the button on your mobile device.
- Page 33 Instant Control MyZone 1 00:01:59 Settings Default minutes 2min MyZone 2 00:03:00 MyZone 1 2min MyZone 2 2min MyZone 3 00:03:00 MyZone 3 2min Home Control Yard Program Video...
- Page 34 Profile your yard You may set up and manage all your yard profile information here. Our app can automatically detect Yard the connected zones and enable them.
- Page 35 to the “Yard” tab. My Yard MyZone 1 MyZone 1 Zone 1 Watering For One Minute Warm Season Grass Name Spray Head MyZone2 Loam Enable Smart Program/running at 100% Plant Warm Grass MyZone 2 Sprinkler Heads Zone 2 Spray Head Fruit, Deciduous Soil Types Tell...
- Page 36 Program the watering schedule Set up "Smart Program" or "Manual Program Program" for each zone according to your needs.
- Page 37 My Program Unassigned Zones MyZone 3 Smart Program MyZone 1 Smart Program designs automatic watering schedules based on your zone profiles, Add New Manual Program weather data, watering restrictions, and your preferences for each zone. Program MyZone 2 Manual Program allows you to create your Every 4 Days own watering schedule.
- Page 38 Watch live video streaming and more You can view live video streaming via Video your Yardian camera here.
- Page 39 Video Settings Live History Motion Detection Video Cloud Recording Alert Sensitivity Threshold Repellent Enable Repellent Zone MyZone2 Duration (in seconds) Home Control Yard Program Video...
