- Page 1 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment: Model #: ___________________________ Serial #: ___________________________ Date Purchased: ____________________ Parts Manual PCC & PCF L22-367 R1 (02/15)
-
Page 2: Table Of Contents
Parts-PCC and PCF Model NOTICE IN THE EVENT OF PROBLEMS OR QUESTIONS ABOUT YOUR ORDER, CONTACT THE PITCO FRIALATOR FACTORY AT (603) 225-6684. IN THE EVENT OF PROBLEMS OR QUESTIONS ABOUT YOUR EQUIPMENT, CONTACT THE PITCO FRIALATOR AUTHORIZED SERVICE AND PARTS REPRESENTATIVE (ASAP) COVERING YOUR AREA, OR CONTACT PITCO AT THE NUMBER LISTED ABOVE. -
Page 3: A) Pcc14
Parts-PCC & PCF Model A) PCC14 Parts List ITEM # PART NUMBER DESCRIPTION 18602‐0155 GREASE FILTER 18612‐0113 TUBULAR HEATER ELEMENT 15600‐0061 HIGH LIMITS SWITCH 18607‐0009 TERMINAL BLOCK 18309‐0086 RUBBER FOOT 18602‐0083 ON/OFF SWITCH 18614‐0365 BLOWER WHEEL 18614‐0359 INLET SCREEN 18600‐0016 THERMOSTAT 18614‐0362 C‐FRAME MOTOR 120V Parts View... -
Page 4: Parts View
Parts-PCC and PCF Models B) PCC18 Parts List ITEM # PART NUMBER DESCRIPTION 18602‐0155 GREASE FILTER 18612‐0113 TUBULAR HEATER ELEMENT 18600‐0061 HIGH LIMITS SWITCH 18607‐0009 TERMINAL BLOCK 18309‐0086 RUBBER FOOT 18602‐0083 ON/OFF SWITCH 18614‐0365 BLOWER WHEEL 18614‐0359 INLET SCREEN 18600‐0017 THERMOSTAT 18614‐0362 C‐FRAME MOTOR 120V Parts View L22-367 R1 (02/15) -
Page 5: C) Pcc28
Parts-PCC & PCF Model C) PCC28 Parts List ITEM # PART NUMBER DESCRIPTION 18602‐0158 GREASE FILTER 18612‐0113 TUBULAR HEATER ELEMENT 18600‐0061 HIGH LIMITS SWITCH 18607‐0009 TERMINAL BLOCK 18305‐0087 RUBBER FOOT 18602‐0170 ON/OFF SWITCH 18614‐0365 BLOWER WHEEL 18614‐0359 INLET SCREEN 18600‐0016 THERMOSTAT 18614‐0363 C‐FRAME MOTOR 208V 18614‐0364 C‐FRAME MOTOR 240V Parts View... -
Page 6: Parts View
Parts-PCC and PCF Models D) PCF14 Parts List ITEM # PART NUMBER DESCRIPTION 18602‐0155 GREASE FILTER 18612‐0113 TUBULAR HEATER ELEMENT 15600‐0061 HIGH LIMITS SWITCH 18607‐0009 TERMINAL BLOCK 18616‐0135 TRANSFORMER 18616‐0198 PROBE 18614‐0365 BLOWER WHEEL 18614‐0359 INLET SCREEN 18616‐0223 RELAY 18614‐0362 C‐FRAME MOTOR 120V Parts View L22-367 R1 (02/15) -
Page 7: E) Pcf18
Parts-PCC & PCF Model E) PCF18 Parts List ITEM # PART NUMBER DESCRIPTION 18602‐0175 GREASE FILTER 18612‐0113 TUBULAR HEATER ELEMENT 15600‐0061 HIGH LIMITS SWITCH 18607‐0009 TERMINAL BLOCK 18616‐0135 TRANSFORMER 18616‐0198 PROBE 18614‐0365 BLOWER WHEEL 18614‐0359 INLET SCREEN 18616‐0223 RELAY 18614‐0362 C‐FRAME MOTOR 120V Parts View... -
Page 8: Parts View
Parts-PCC and PCF Models F) REMOTE CONTROL ASSEMBLY Parts List ITEM # PART NUMBER DESCRIPTION 18312‐0189 CONTROL OVERLAY 18602‐0172 ON/OFF SWITCH 18616‐0229 CONTROLLER Parts View L22-367 R1 (02/15) - Page 9 Parts-PCC & PCF Model LEFT BLANK INTENTIONALLY...
