Model: DGSNCKNT32
Description: 32 inch Non Touch LCD Digital Screen
Scan QR code to visit
the product page
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please call
our Customer Service Department at 1-844-221-3393.
DISPLAYS2GO
User Manual
Operating Instructions for Digital Signage
FCC ID: 2ASCB-DGSNCKNT32
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
1
V20.09
Advertisement
Table of Contents
Related Manuals for Displays2go DGSNCKNT32
Summary of Contents for Displays2go DGSNCKNT32
- Page 1 V20.09 Model: DGSNCKNT32 Description: 32 inch Non Touch LCD Digital Screen Scan QR code to visit FCC ID: 2ASCB-DGSNCKNT32 the product page This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
-
Page 2: Table Of Contents
Edit picture ..........................15 Music ............................17 Factory Reset ..........................17 Screen Rotation ........................... 18 Choose System Language ......................18 Technical Specifications…………………………………………………………………………………………………………20 Troubleshooting……………………………………………………………….……………………………………………………22 Cleaning and Maintenance……………………………………………….……………………………………………………24 Names and Contents of Toxic and Hazardous Substances or Elements in the Product…….………25 DISPLAYS2GO... -
Page 3: Features
Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 4 Do not use the Digital Signage in stormy weather, especially when there is lightning; instead, please disconnect the power and antenna plugs to avoid lightning strike. Do not disassemble the Digital Signage without permission, or else it may cause electric shock or fire. Please ask qualified technician for repair. DISPLAYS2GO...
- Page 5 The unit is class-A product, which may cause radio interference in living environment. In this case, please take feasible measures, and use power plug as the disconnection device. DISPLAYS2GO...
-
Page 6: Assembly And Connection
Assembly and Connection Parts List Accessory Photo Qty. Note AC Power cord with Ground Pin Remote control M5x10 Screw M6x20 Screw Hex wrench Back Door User manual DISPLAYS2GO... -
Page 7: Description Of Parts
9 - Door Lock 10 - Foot Pad 11 - HDMI port 12 - USB port 13 - Ethernet port (RJ45 socket) 14 - AC power socket 15 - Caster CAUTION: Disconnect the power plug before assembling or disassembling the unit! DISPLAYS2GO... -
Page 8: Steps For Assembly
Connect the base and the Signage body. Insert M6x20 screws from the bottom of the base and M5x10 screws from the top of the bracket on the signage. Tighten screws with enclosed Hex Wrench to secure the signage body with the base. DISPLAYS2GO... -
Page 9: Remote Control
To move the cursor down NOTE: Press the SETUP button in the main interface to call out the OSD menu. After exiting the playback mode by pressing the STOP button, the playback will start according to the schedule next time. DISPLAYS2GO... -
Page 10: Description Of Basic Operation
When powered on, enter “System Assistant” and press the “ ” button on the remote control, and the Digital Signage enters standby state. About Launch Desktop Description of Desktop Icons Icon Function App Drawer Back Home page Background applications Sound - Sound + DISPLAYS2GO... -
Page 11: Description Of Wallpaper Switch
” in the Home page to enter the “APPS” menu interface (Fig. 2); 2. Click the “Explorer” icon in the “APPS” menu interface (Fig. 2) and enter “Explorer” menu (Fig. 3); 3. Click options in the “Explorer” menu to read the files from different devices. Fig. 1 Fig. 2 Fig. 3 DISPLAYS2GO... -
Page 12: Local Settings
Fig. 3 Description of Settings Interface (shown on the right) Icon Function WIFI switch Bluetooth Data usage Display Notifications Sound Apps Screenshot Setting Storage Battery Memory Users Location Security Accounts Google Languages & input Backup & reset Date & time DISPLAYS2GO... -
Page 13: Status Of Menu Bar
Step 2: Plug in your USB drive to the computer. Open the drive in Windows Explorer and create a new folder, rename it “MediaFolder”. As shown below: Open "MediaFolder", create 3 subfolders, and change their names to "Images", "Videos", "Music". Copy the media file to be displayed, image to "Images", video to "Videos", Music to "Music" DISPLAYS2GO... - Page 14 AVI, MPEG4, WMV, MKV, FLV, MP4, MOV Music AAC/MP3/AMR/OGG Step 3: Plug the USB drive into the device and click the DiViEx APP. Step 4: When the screen shows “Copy finished” after “Usb Disk:”, the media files are ready to be displayed. DISPLAYS2GO...
-
Page 15: Settings
NEGATIVE, PSTERIZE, ROTATE, SATURATE, SEPIA, SHARPEN, TEMPERATURE, TINT, VIGNETTE. ⚫ Reset Click “Reset” to remove all the editing you applied to the image. ⚫ Save “ ” Click the icon to save the edited image as a new image. DISPLAYS2GO... - Page 16 ⚫ Image deletion Click " " to delete unwanted pictures DISPLAYS2GO...
-
Page 17: Music
1. Go to Settings, then click “Backup & reset” (Fig. 1) 2. Click “Factory data reset” (Fig. 2) 3. Choose “Reset Tablet”, then click “ERASE EVERYTHING” to get the unit to default settings. (Fig. 3) Fig. 1 Fig. 2 Fig. 3 DISPLAYS2GO... -
Page 18: Screen Rotation
2. Click “Languages”, then click “Add a language” (Fig. 2) 3. You can add the required system language (Fig. 3) 4. Drag the system language you just added up to the front (Fig. 4)-Please use a mouse to operate. Fig. 1 Fig. 2 DISPLAYS2GO... - Page 19 Fig. 3 Fig. 4 DISPLAYS2GO...
-
Page 20: Technical Specifications
-4~140 °F (-20~60°C) Environment Storage humidity 10~80% RH Non-condensing Operating humidity 10~80% RH Non-condensing Maximum operating time (hrs/day) 18 hours Operating system Android 7.1 Processor RK3288, quad-core Functions Internal Storage Decoding resolution 1080P Playback mode Support loop, inter-cut, timer, shim, etc. DISPLAYS2GO... - Page 21 App installation Support download and installation Ethernet (RJ45) HDMI I/O interfaces Headset USB 2.0 Gross Weight 31.8kg Net weight 23.3kg Unit dimensions (W*D*H) 1300(H)x432(W)x305(D)mm LCD Screen Package dimensions (W*D*H) 1420x250x500mm Material Aluminum, Steel, Acrylic Shell color Black Language English DISPLAYS2GO...
-
Page 22: Troubleshooting
DGSNCKNT32 Troubleshooting the Digital Sign – Issue Probable Cause Solutions ⚫ ➢ No picture or sound Unit not plugged into wall outlet □ Check that the unit is plugged into wall ➢ Power cord not properly outlet. connected to the terminal on the □... - Page 23 □ Having problems Did you purchase the If you purchased DisplayIt!Xpress software with installing DisplayIt!Xpress software from from Displays2go or from Best Wave directly, software or getting Displays2go? please contact Best Wave at ➢ content to play Did the customer purchase or support@bestwave.
-
Page 24: Cleaning And Maintenance
3. Don't place the product under direct sunlight which may shorten the service life of the screen. 4. Clean screen and product by using a glass cleaner. 5. If the product will not be used for a long time, pull out the power cord to prevent the internal short circuit or other potential dangers. DISPLAYS2GO... -
Page 25: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product
To protect the earth, if you do not need this product or its service life expires, please abide by your local Waste Electrical and Electronic Products Recycling and Disposal Regulations or send it to qualified local manufacture for recycling. This Manual is for reference only and is subject to change without prior notice. DISPLAYS2GO...
