Dissolved Ozone Sensor
Copyright 2019
Teledyne API
User Manual
MODEL 470
© TELEDYNE API (TAPI)
9970 CARROLL CANYON ROAD
SAN DIEGO, CALIFORNIA 92131-1106
USA
Toll-free Phone:
800-324-5190
Phone:
+1 858-657-9800
Fax:
+1 858-657-9816
Email:
api-sales@teledyne.com
Website:
http://www.teledyne-api.com/
08681B DCN8036
15 January 2019
Advertisement
Table of Contents
Related Manuals for TELEDYNE API 470
Summary of Contents for TELEDYNE API 470
- Page 1 User Manual MODEL 470 Dissolved Ozone Sensor © TELEDYNE API (TAPI) 9970 CARROLL CANYON ROAD SAN DIEGO, CALIFORNIA 92131-1106 Toll-free Phone: 800-324-5190 Phone: +1 858-657-9800 Fax: +1 858-657-9816 Email: api-sales@teledyne.com Website: http://www.teledyne-api.com/ Copyright 2019 08681B DCN8036 Teledyne API 15 January 2019...
- Page 3 TRADEMARKS All trademarks, registered trademarks, brand names or product names appearing in this document are the property of their respective owners and are used herein for identification purposes only. Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036...
-
Page 4: Safety Messages
NEVER use any ozone analyzer to sample combustible fluid(s)! For Technical Assistance regarding the use and maintenance of this instrument or any other Teledyne API product, contact Teledyne API’s Technical Support Department: Telephone: 800-324-5190 Email: api-techsupport@teledyne.com... - Page 5 été prévu, l’instrument pourrait se comporter de façon imprévisible et entraîner des conséquences dangereuses. NE JAMAIS utiliser un analyseur de ozone pour échantillonner des fluide combustibles! Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036...
-
Page 6: Warranty
PRODUCT RETURN All units or components returned to Teledyne API should be properly packed for handling and returned freight prepaid to the nearest designated Service Center. After the repair, the equipment will be returned, freight prepaid. -
Page 7: Table Of Contents
Figure 2-6: Digital Status Outputs ......................12 LIST OF TABLES Table 1-1. Specifications ..........................6 Table 4-1: Status Outputs .......................... 14 Table 4-2: Status Output Truth Table ......................14 Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 8: Introduction, Specifications, Approvals, & Compliance
The Model 470 operates from an external +15 VDC power source, and features either a standard 0-5 volt or 4-20 mA analog signal for reporting process concentration, as well as 4 digital status outputs for sensor diagnostics. -
Page 9: Safety
CE: [pending] IEC/EN 61326-1, Class A Emissions/Industrial Immunity EN55011 (CISPR 11), Group 1, Class A Emissions FCC 47 CFR Part 15B, Class A Emissions CE: [pending] Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 10: Getting Started
This section addresses unpacking, connecting, and initializing the instrument. UNPACKING Upon receiving the Model 470 please verify that no apparent shipping damage has occurred. If damage has occurred please advise shipper first, then notify Teledyne API. The sensor features two hydraulic ports, two pneumatic ports for purge gas, and one electrical 15-pin D-Sub connector at the end of a 11-ft Teflon jacketed cable*. -
Page 11: Mechanical Installation
It is recommended that a 1-inch clearance be allowed on top and sides. The following two illustrations provide dimensions (inches) for mounting: Figure 2-2. Sensor Dimensions (control interface cable fixture not shown) Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 12: Pneumatic Connections
BATH OZONE RE- CIRCULATION PUMP INJECTOR OZONE CATALYST 470 SENSOR 470 SENSOR IN-LINE SIDE-STREAM MIXER DIFFUSER DRAIN DE-BUBBLER PLC OR STATUS DISPLAY Figure 2-4: Typical Installation, In-Line or Side-Stream Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 13: Electrical Connections
OWER UPPLY The Model 470 requires a +15 VDC power source capable of supplying 1.0 A. DC power is connected through the male DB-15 connector. The positive terminal of the power supply should be connected to pins 4 and 5 on the 15-pin connector and the common terminal should be connected to pins 3 and 15. -
Page 14: Zero Calibration Input
ALIBRATION NPUT The zero calibration input is located on Digital Input #1. To zero the Model 470, Digital Input #1 should be connected to the power common for at least 1 second. This can be accomplished using a Normally Open switch or relay. -
Page 15: Operation
ZEROING THE SENSOR Due to its innovative sensing technology, the Model 470 is a highly zero-stable instrument, but should be zeroed periodically. 1. Purge the sensor with an ozone-free reference fluid, typically deionized water, to get rid of dissolved ozone inside the optical chamber for about 15 minutes. -
Page 16: Troubleshooting
Calibrate at Zero (Section 3.2). Action may not be required immediately; otherwise, service soon (Section 5.1). Calibrate at zero (Section 3.2). Call for service (Section 5.1). Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 17: Status Output Descriptions
Channel gain factor has fallen to < 0.5. This value is calculated when the zero calibration is performed. When this output is on, it indicates a loss of optical transmission through the windows in the absorption cell or a calibration fault. Teledyne API Model 470 Dissolved Ozone Sensor User Manual 08681B DCN8036... -
Page 18: Maintenance
Aside from occasional calibration as described in this manual, there is no maintenance required for the Model 470 in the field. The UV lamp is typically replaced once every 2-3 years at the factory; take action according to Table 4-2.
