- Page 1 SAVCH Programmable Logic Controller H/M series PLC MPU User Manual...
-
Page 2: Table Of Contents
Contents 1. Products receiving............................. 3 2. Model description............................3 3. Product model list & dimensions......................3 4. Indicator Description..........................4 5. Power Supply Specification........................5 6. Environmental Specifications for Product....................5 7. Digital Input (DI) Specification......................... 6 8. Digital Output (DO) Specification......................6 9. -
Page 3: Products Receiving
●To check whether there are damaged parts during transportation and delivering. If there are, do not connect with power supply. If any of the above checkpoints are not satisfactory, contact your SAVCH ELECTRIC representative for a quick resolution. 2. Model description 3. -
Page 4: Indicator Description
Ethernet Model 24VDC Model 24VDC Dimension Figure No. SMC-H60MRD-e 0.78A SMC-H60MRD 0.75A SMC-H60MTD-e 0.8A SMC-H60MTD 0.77A 177×95×82mm Size C SMC-M60MTD-e 0.81A SMC-M60MTD 0.78A Ethernet Model 220VAC Model 220VAC Dimension Figure No. SMC-H16MR-e 10.2W SMC-H16MR 9.6W SMC-H16MT-e 10.9W SMC-H16MT 10.3W SMC-M16MT-e 10.7W SMC-M16MT 10.1W... -
Page 5: Power Supply Specification
Consult manage Signify information type ERR the state of the indicator Normal Without error Not light Normal,just prompt take PLC have the component which Yellow flicker: On 0.2 seconds and attention to the locked data locked Off 0.8 seconds Problem in the soft setting ,permit Modificate the PLC hardward Yellow flicker: On 0.2 seconds and user keep on operate the user... -
Page 6: Digital Input (Di) Specification
Item Environment Specification The third kind of grounding(Connecting to the ground of high voltage Ground system is prohibited) Operating environment Avoid dust, moisture, corrosion, electric shock and external shocks 7. Digital Input (DI) Specification Item Digital Input (DI) Input Signal No voltage contact or NPN/PNP Action driving ON>3.5mA... -
Page 7: 10. Mpu Terminal Wiring Diagram
PNP Internal power PNP External power AC / DC Relay output DC NPN Transistor output 10. MPU Terminal Wiring Diagram... -
Page 8: 11. Programming Cable Wiring
4 core S terminal male 12. Address Setting Savch PLC with Ethernet port, the default IP address is: 192.168.1.111, subnet mask: 255.255.255.0, gateway: 192.168.1.1. Hardware DIP dial switch address range: 1-15, the default address is 1. If you need to set a bigger address range, you can set on the software after connection with PLC, it can be set on the PLC parameter option in the software menu by checking on the "soft address"... - Page 9 ■ Innovate for more | win forever ■ Industry intelligence | Energy saving | Green power Savch wechat Service Number Quanzhou Factory Address:3# Zixin Road, Jiangnan Hi-Tech Industrial Park, Sales service contact address Quanzhou, Fujian, China Tel：0595-24678267 Fax：0595-24678203 Service Network Service Hotline：4000-6161-619...
