- Page 2 Disconnect the battery pack before storing your model. WARRANTY WRC guarantees this model kit to be free from defects in both material and workmanship within 30 days of purchase. The total monetary value under warranty will in no case exceed the cost of the original kit purchased.
- Page 3 TECHNICAL INFORMATION TECHNICAL DATA - BRAKE:Laser cut brake disck with Ferodo brake pad - WIDTH ..........310 mm - WHEELS LOCK:Lightweight 17 mm 7075 T6 Nut - WHEEL BASE ....adjustable 315-320 mm - CHASSIS:4.0 mm Swiss 7075 T6 aluminium - WEIGHT READY TO RUN ....3500g - RADIO PLATE:Composite Material - DRIVETRAIN TYPE:Spring steel CVD Driveshfts - FRONT DIFFERENTIAL:Differential Gear...
- Page 4 BAG 1 Front Diff. Gear 100811 100805 97000 100810 Ø2.5x11.8 100815 100809 95014 O-ring 6x2 100805 100809 100813-L 95014 90024 O-ring 6x2 8x16x5 97000 Ø2.5x11.8 100802-L 90024 8x16x5 100812 92004 M3 x12 100812 DIFFERENTIAL OIL : Front : 500000 cst Weight : 3 g 100804-05 Fill the differential up to the top of the pin.
- Page 5 BAG 2 Rear Diff. Gear 100811 100805 97000 100810 Ø2.5x11.8 100815 100809 95014 O-ring 6x2 100805 100809 100813-L 95014 90024 O-ring 6x2 8x16x5 97000 Ø2.5x11.8 100802-L 90024 8x16x5 100812 92004 M3 x12 100812 DIFFERENTIAL OIL : Rear : 40000 cst Weight : 3 g 100804-05 Fill the differential up to the top of the pin.
- Page 6 BAG 3 Rear Transmission Cut on both front and rear bulkhead blocks 97022 Ø2.5x14.8 100611 98015 M5x4 90024 100201 8x16x5 100817 100606 13.2x15.9x0.2 100603 100616 100612 GREASE 90024 8x16x5 200013 100201 93005 M3 x14 GREASE 100817 93007 13.2x15.9x0.2 M3 x18 93005 M3 x14...
- Page 7 BAG 4 Front Transmission Cut on both front and rear bulkhead blocks 97022 Ø2.5x14.8 100610 98015 M5x4 90024 100201 8x16x5 100817 100606 13.2x15.9x0.2 100603 100612 100616 GREASE 90024 8x16x5 100201 200012 100817 13.2x15.9x0.2 GREASE 93007 M3 x18 93005 M3 x14...
- Page 8 BAG 5 Front Suspension Lower Arm Position 92008 M3 x20 98019 ADJUST THE PLAY M5x8 WITH THE SHIMS 100452 100507 F-R 100512 100512 100506 F-F 100302-H (Hard) OPTIONAL 100302-S (Soft) 100302-M (Medium) 97024 Lower Arm Position Ø4x65 91011 M3x40 SCREW POSITION...
- Page 9 BAG 6 Front Suspension 91010 M3x20 03069-3 98000 M3x3 100116 UN0002 91010 M3x20 100517.28 98016 M3X5 93037 93002 M2.5 x 8 M3 x8 100300-S (Soft) OPTIONAL 100300-M (Medium) 100704 100300-H (Hard) 100420 100512 100514-1 100512 100300 Upper Arm Position 97023 Ø4x45 100300 93004...
- Page 10 BAG 7 Front Upr ight 97022 Ø2.5x14.8 100314 90026 100605 90025 8x16x5 15x21x4 98015 M5x4 100119 100606 GREASE 100607 100520 97025 93004 Ø3x16.7 M3 x12 100414 100410 97022 100605 Ø2.5x14.8 90025 15x21x4 100314 90026 8x16x5 98015 100119 M5x4 100606 GREASE 100607 100520 97025...
- Page 11 BAG 8 Rear Suspension Lower Arm Position 91011 M3x40 98019 100510 M5x8 ADJUST THE PLAY WITH THE SHIMS 100512 100301-H (Hard) 98019 100452 M5x8 OPTIONAL 100301-M (Medium) 100301-S (Soft) 97024 Ø4x65 100512 100511 92008 M3x20 100301 Lower Arm Position 98000 M3x3 91010 M3x20...
- Page 12 BAG 9 Rear Suspension 97022 100605 Ø2.5x14.8 100607 90025 15x21x4 90026 8x16x5 100606 100410 GREASE 98000 M3x3 100304 97025 98015 Ø3x17 M5x4 97022 Ø2.5x14.8 90025 90026 15x21x4 8x16x5 100410 100605 GREASE 100607 100606 100304 98015 98000 M5x4 M3x3 93011 94001 97025 M3 x25 M3 Autolock...
- Page 13 BAG 10 93002 200034 Rear Suspension M3 x8 100310 93004 M3 x12 93002 M3 x8 100120 100405 100310 200034 93002 M3 x8 93002 M3 x8 100120 100311 100120 93002 M3 x8 100311 97017 200036 Ø2x14 200036-1 91016 M2X10 200023 200036 200022 200021 94001...
- Page 14 BAG 11 Front & Rear Assembly 200037 200003 92029 M4x16 92003 M3x10 100407 92021 M4x10...
- Page 15 BAG 11 Front & Rear Assembly 92003 M3 x10 100405 93004 100518 M3 x12 90001 6x10x3 100120 100310 90001 100405 6x10x3 100310 100409 100309 100408 100309 100120 90001 6x10x3 100309 100408 100309 23.5 95015 OR 12x1.5 100412-1 90001 6x10x3 100413 93004 M3 x12 93004...
- Page 16 BAG 12 Front & Rear Assembly 00161 92001 M3x6 03277 98012 M4x4 90024 8x16x5 97003 Ø2.5x13.8 90027 200009-2 13x19x4 200048 200010 200039...
- Page 17 BAG 12 Front & Rear Assembly 100438 92020 M4x8 92020 M4x8 Electric motor ELECTRIC MOTOR NOT INCLUDED 98012 M4x4 NOT INCLUDED 93003 M3 x10 100438 PINION GEAR PINION GEAR NOT INCLUDED RCM10-12 12 T RCM10-13 13 T RCM10-14 14 T RCM10-15 15 T RCM10-16...
- Page 18 BAG 13 Batteries supports 93003 M3 x10 200044 93003 M3 x10 200044 00130 93002 M3 x8 93002 M3 x8 93002 M3x8 03055 03069 96002 M3 x8 00125 SERVO NOT INCLUDED 03086-1 03069 SERVO ADJUST 200043 200019 92003 M3x10 93003 M3x10...
- Page 19 BAG 14 Upperdeck 91001 91015 M3X10 M3x20 93001 M3 x6 200045 200042 93002 M3 x8 200041 200040...
- Page 20 BAG 16 200025 Front/Rear Shock 100114 100107 100104 100101 100104 100101 100101 100106 100103 100102 100105 100112 200050 (4.5 Lbs) 94012 OPTIONAL M2.5x3.5 200050-1( 4 Lbs) 100113 100115 200051 100116 Assembly 4 set DO NOT BLOCK COMPLETELY ALLOW THE PISTON TO ROTATE SHOCK FILLING P- ONE SHOCKS OIL...
- Page 21 BAG 15 Front Shock Set distance 100101 100130 100116 200012 SX 91015 M3x20 200012 DX 91015 M3x20 93013 M3 x28 100121 100416 94002 M3 Autolock 93005 M3 x14...
- Page 22 BAG 15 Rear Shock 200012-SX 91015 M3x20 91015 M3x20 200012-DX 94002 M3 Autolock 93005 M3 x14 94002 M3 Autolock 93005 M3 x14...
- Page 23 BAG 16 Front Bumper CUT TO SIZE 92021 200035 M4x10 200033 200026 03472 200027 03472 200024 92021 M4x10 92021 M4x10 92021 M4x10 Batteries VELCRO STRAP BATTERY NOT INCLUDED BATTERY NOT INCLUDED...
- Page 24 BAG 16 Battery Straps / Tyres 100411 100411 Tyres Not Included Receiver Not Included 100411 00172 00172...
- Page 25 Driver: Track: Date: Event: Front Suspension: Ride Height: Caster Shim: Whellbase Shim: Camber: Toe: Anti-Roll Bar Size: Gap: Upper Ball Type: Caster Shim: Ackerman Lower Ball Type: Whellbase Shim: Upper Ball Shim: Lower Arm Position Drive Shaft: Washer: Chassie Brace: Hex: Upper Arm Position Lower Ball Shim:...
