- Page 1 WEIGHING INDICATOR user manual Model: TI-02 Please read this manual carefully before operation ----Important safety info ----Operating condition and other attentions ----Guarantee info...
- Page 2 @TI-02 USER MANUAL Important Safety And Operation Info Please read the manual in details Please use the right plug and right voltage before operation. Be much attention of 110V or 220V!!! Don’t clean the indicator with the Keep it away from the corruptive gas or liquid.
-
Page 3: Table Of Contents
@TI-02 USER MANUAL INDEX Specifications Power Before using System power consumption Display description Basic function operation Connection of load cell and RS232 Basic parameter setting UF-1 A/D count UF-2 High / Low limits setting UF-3 Auto-power off UF-4 Backlight setting... -
Page 4: Specifications
@TI-02 USER MANUAL SPECIFICATIONS Accuracy: Class III ≤0.01%F.S Nonlinear: Excitation voltage: DC 5V,up to 4 load cells 350 Ω Large display connector: Sampling serial output way Sample rate: 20 times per second (can select) POWER Input: 120~240V Output: 9V/500mA Rechargeable battery: 6V/1.3AH BEFORE USING 1) Place this product on a firm and smooth place, don´t place it in vibration or shaking,... -
Page 5: Basic Function Operation
@TI-02 USER MANUAL BASIC FUNCTION OPERATION Press and hold this key for 2 seconds to turn off the balance. Function 1. Press this key to turn on the balance Function 2. To reset the weight to “0”, but the display value has to be lesser than ±... -
Page 6: Basic Parameter Setting
@TI-02 USER MANUAL 2) Connection of RS232 to PC or Printer INDICATOR PC/PRINTER ------------- RXD ------------- TXD ------------- GND ------------- NC BASIC PARAMETER SETTING To access to functions setting, press the key at the same time in key to select the parameter (UF-1 ~ UF-12 ) weighing mode.Press the... -
Page 7: Auto-Power Off
@TI-02 USER MANUAL number. 10. Press the key to confirm. Remarks: A --- Buzzer on: 0= Stable not required 1= Stable required B –- LCD indicator and RELAY on: 0= Stable not required 1= Stable required C : Buzzer beeps when: 0= Buzzer off... -
Page 8: Rs-232 Output
@TI-02 USER MANUAL HoLd 2 : Peak value hold (when held can press any key to cancel) HoLd 3 : Stable hold (when held can press any key to cancel) HoLd 4 : Stable hold (when held can auto cancel at zero) 1. - Page 9 @TI-02 USER MANUAL 232 7 : Manual accumulate output – Format 3 232 8 : Auto accumulate output – Format 3 232 9 : Manual accumulate output – Format 4 232 10 : Auto accumulate output – Format 4 232 11 ~ 232 13 : LP50 printer is used...
-
Page 10: Speed Setting
@TI-02 USER MANUAL OL – Overload ST – Stable NT – Net weight US – Unstable GS – Gross weight Fixed 18 BYTES ASCII (kg g t lb) 1 2 1 1 2 1 1 2 3 4 5 6 7 8 1 2 1 2... -
Page 11: G Value Setting
@TI-02 USER MANUAL 3. Press the key to confirm. UF-9 G Value setting 1. Press the key to display the G value of manufacture place. 2. If set the G value of local press the key and then press the key and key to input the new G value. -
Page 12: Ecf-1 Zero And Span Calibration
@TI-02 USER MANUAL key to select ECF-1 , ECF-2 or ECF-3 . 2. Press the ECF-1 Zero and Span Calibration key to enter, display will show cALZ . 1. Press the 2. Press the key to calibrate zero point. 3. The display will show the calibration weight 00.6.000 . - Page 13 @TI-02 USER MANUAL During this period Gravity covers the labour cost and the spare parts necessary for the reparation of the scale. This guarantee does not cover the failures caused by an inappropriate use or overcharge. The guarantee does not cover the freight cost (transport) necessary to repair the scale.
