- Page 1 Assembly Instructions L-BB050PCO-1 Parts list Number Description Big bird Little bird Connector Crane Leg 1 Leg 2 Bottom base April 16 Made in China 1 / 3...
- Page 2 Hardware list Number Description Image Number Description Image Stud M6*35 Nut M6 Bolt M6*35 Flat washer M6 Stud M8*30 Bolt M6*20 Nut M8 Bolt M6*15 Wrench M6/M8 Flat washer M8 Fig.1: Put leg 2 (G) at the inner side of the crane, then connect with bolt (BB), flat washer (GG) and nut (FF); connect leg 1 (F) in the same way.
- Page 3 CARE AND MAINTENANCE: To extend the life of garden cart, cover it in bad weather. Due to natural properties of steel material, if rust develops, please clean rust area by sanding slightly, then wipe thoroughly and apply touch-up paint if possible. Limited Warranty: This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the item is maintained with care and used only for personal, residential purposes.
