CD3550
ASSEMBLY INSTRUCTIONS
IMPORTANT
Please read these instructions carefully before assembly.
Save instructions for future reference.
P.O. Box 458
27725 Danville Avenue
Castle Rock, MN 55010
www.poly-tex.com
REV: AA-121205
355 circle display
U.S. & Canada Toll Free
800-852-3443
(651) 463-7009
fax (651) 463-2479
Advertisement
Table of Contents
Related Manuals for Poly-Tex CD3550
Summary of Contents for Poly-Tex CD3550
- Page 1 355 circle display CD3550 ASSEMBLY INSTRUCTIONS IMPORTANT Please read these instructions carefully before assembly. Save instructions for future reference. P.O. Box 458 U.S. & Canada Toll Free 27725 Danville Avenue 800-852-3443 Castle Rock, MN 55010 (651) 463-7009 www.poly-tex.com fax (651) 463-2479...
- Page 2 PARTS IDENTIFICATION CD3580 CD3572 CD3573 CIRCULAR BASE (5') CIRCULAR SHELF (5') CIRCULAR SHELF (3') CD3574 VERTICAL (48-1/2") NB1968 FB2512 SNAP PIN 5" CASTER/EXP 1.66'' W/BRAKE (OPTIONAL) NB1978 NB1842 5/16" x 3/8" HEX BOLT 5/16" x 3/4" ZP G5 SET SCREW TOOLS &...
- Page 3 ASSEMBLY INSTRUCTIONS 1. LAY THE 5' BASE FACE DOWN ON A FLAT SURFACE. LARGE RING HEX BOLT LOCATIONS (4) 2. OPTIONAL CASTERS. INSERT CASTER STEM INTO TUBE. HAND-TWIST LARGE RING UNTIL CASTER IS SECURE. 3. TIGHTEN HEX BOLTS IN BASE SOCKETS IF NOT ALREADY TIGHTENED.
- Page 4 ASSEMBLY INSTRUCTIONS 4. INSERT THE SNAP PIN INTO THE HOLE OF THE VERTICAL AS SHOWN. 5. CAREFULLY TURN THE 5' BASE UNIT OVER. MEASURE EACH VERTICAL TO FIND THE END WHERE THE HOLE IS 23" FROM THE END AND INSERT THAT END OF THE VERTICAL INTO THE SOCKETS UNTIL IT REACHES THE HEX BOLT.
- Page 5 ASSEMBLY INSTRUCTIONS 5. SLIP THE VERTICALS THROUGH THE HOLES IN THE 5' CIRCULAR SHELF UNTIL THE SHELF RESTS ON THE SNAP PINS.
- Page 6 ASSEMBLY INSTRUCTIONS 6. TIGHTEN THE SHELF TO THE VERTICALS USING THE SET SCREW & WRENCH PROVIDED. SNAP PIN SET SCREW...
- Page 7 ASSEMBLY INSTRUCTIONS 7. SET THE 3' SHELF ONTO THE VERTICALS INSERTING THE SHELF STUBS INTO EACH VERTICAL. ENSURE THAT EACH STUB IS FULLY ENGAGED.
- Page 8 Limited Warranty Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a period of (1) year from date of invoice. This warranty is provided to the original purchaser of the product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex, but does assign any transferable manufacturer or supplier warranties.
