Dawn Model 1202/1203/1204 Curvetine
Assembly and Operation Manual
2014_03_1202/1203/1204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Curvetine M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dawn Curvetine M Series

Summary of Contents for Dawn Curvetine M Series

  • Page 1 Dawn Model 1202/1203/1204 Curvetine Assembly and Operation Manual 2014_03_1202/1203/1204...
  • Page 2 OEM specifications, applicable Dawn warranties will become void, and Dawn sponsored implement improvements will not be granted. ©2012 Dawn Equipment Company, Inc. 370 N Cross Sycamore, IL 60178 USA www.dawnequipment.com Toll Free: 800.554.0007 Fax:815.899.3663...

  • Page 3: Safety Information

    Dawn Equipment Company. protect your feet. Please read your manual before attempting any repair work to your Dawn tool. If you need to work on your Dawn tool, FIRST AID KIT make sure to support it before partially or fully removing In order to minimize the risk of it from the attachment points.

  • Page 4: Product Introduction

    Grease to purge; it is not possible to over-grease hubs. Remove excess grease. ©2012 Dawn Equipment Company, Inc. 370 N Cross Sycamore, IL 60178 USA www.dawnequipment.com Toll Free: 800.554.0007...

  • Page 5: Installation

    Insert hub shaft through 1 supplied washer, tailpiece, lock washer, and thread into nut. Tighten by placing 15/16” wrench onto nut and turning hub shaft using the supplied Dawn 1 3/8” wrench. To tighten, turn Dawn wrench TOWARDS planter unit. To loosen hub, turn Dawn wrench AWAY from planter unit.

  • Page 6: Appendix - Warranty

    Dawn. 3. Defects, damage or failure or deprecation resulting from wear and tear, accidents, misuses, negligence, improper maintenance or improper protection and storage. ©2012 Dawn Equipment Company, Inc. 370 N Cross Sycamore, IL 60178 USA www.dawnequipment.com Toll Free: 800.554.0007 Fax:815.899.3663...
  • Page 7 Dawn Parts Breakdwon M-Series Curvetine Item Dawn Part # Item Description Item Dawn Part # Item Description 5/8”-18 Hex Nut RH thread 9028 Tongue Washer 90428 5/8”-18 Hex Nut LH thread 9178 Castelated Nut 90429 9019 Cotter Pin 9069 Lock Washer...
