Airlink101 AWLC5025 Quick Installation Manual

Mimo xr 802.11g cardbus adapter
Hide thumbs Also See for AWLC5025:
1
2
3
4

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version

Quick Installation Guide

MIMO XR™ 802.11g Cardbus Adapter
Model # AWLC5025
Section 1

Install Utility Software

This Quick Installation Guide only provides the basic instructions. For more
advanced features such as configuring encryption settings, please refer to the
User's Manual in the provided CD.
Note: Do not insert the Cardbus Adapter until you have reached the appointed
step.
For Windows 98SE and ME users, you may be prompted to insert the Windows
98SE or ME CD during the driver installation. Be sure to have your Windows 98SE
or ME CD ready.
Ver. 1A
Package Content:
•
Cardbus Adapter
•
Driver & Utility CD
•
Quick Installation Guide
Step 1
Insert the Driver & Utility CD into your CD drive and select Install Utility
from the menu.
Note: If the Autorun screen doesn't appear automatically go to Start, Run, and
type D:\autorun.exe (where D is the letter of your CD drive) and click OK.
Step 2
Click Next at the welcome screen.
Step 3
Click Next to accept the default destination folder.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AWLC5025 and is the answer not in the manual?

Questions and answers

Related Manuals for Airlink101 AWLC5025

Summary of Contents for Airlink101 AWLC5025

  • Page 1: Quick Installation Guide

    Quick Installation Guide MIMO XR™ 802.11g Cardbus Adapter Model # AWLC5025 Section 1 Install Utility Software This Quick Installation Guide only provides the basic instructions. For more advanced features such as configuring encryption settings, please refer to the User’s Manual in the provided CD.
  • Page 2 Step 4 Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt). Step 5 Verify Yes, I want to restart my computer now is selected and click Finish to restart your computer. Step 6 After your computer is restarted, insert the Cardbus Adapter.

  • Page 3: Configure The Cardbus Adapter

    Section 3 Section 2 Configure the Cardbus Adapter To open the Cardbus Adapter’s utility go to Start > (All) Programs > Airlink101 MIMO Cardbus Utility > Airlink101 MIMO Cardbus Utility. Step 1 Go to the AP List tab, select the SSID (Network Name) of the wireless network you wish to connect to, and click Connect.

  • Page 4: Technical Support

    Step 4 Select the proper encryption setting for your wireless router or access point from the drop-down menu and click Next. Step 5 Follow the on-screen instructions to complete the encryption settings. Click Complete when finished. Step 6 You should see a blue circle around the antenna icon indicating a valid connection.
