Jabra Pro 9450 Quick Start Manual

How to connect my Jabra PRO 9450 with Aastra Open Phone
6771, 6773, 6775, 71, 73, 75, Aastra 6739i, Aastra 7434 and
7444
Jabra Pro 9450 Mono Flex
Prerequisite:
Jabra PRO 9450 + Jabra LINK 14201-10
In combination with one of the following phones:
Open Phone 6771 / 6773 / 6775 incl. IP (Old name: Open Phone
71/73/75 incl. IP)
Aastra 6739i
Aastra 7434 / 7444 IP
Connection:
1. Plug the 1-sided end of the DHSG cable marked "blue" into the socket
of your phone marked with the "headset" symbol.
2. Insert the RJ9 plug into the socket identified with the "phone" symbol
and the RJ45 plug into the socket identified with "AUX" on the base.
Automatic configuration:
You now have the option of setting up the headset on your phone via the
automatic or manual configuration.
To start the automatic configuration, ask someone to call you on this
phone and wait at least 10 seconds before taking the call. The appropriate
EHS mode should now be installed.
If the automatic configuration has not worked, please select DHSG mode
manually.
