Instruction Manual
Hydro-pneumatic tool for blind rivets
SAR002
Ed. January 2021
2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum
INSTRUCTION MANUAL
SAR002
DISTRIBUTOR'S STAMP
SAR
002
H Y D RO - PN E UM A T I C T O O L F O R
B L I N D RI V ET S
2 , 4 ÷ 4, 0 M M A L L A L L O Y S
A N D 4, 8 M M A L UM I N UM
SARIV s.r.l. Unipersonale
Via del Progresso, 2 - 35014 FONTANIVA PD - ITALY
Tel. (+39) 049 594 1313 - Fax. (+39) 049 594 1920
www.sariv.it-
info@sariv.it
1
Advertisement
Table of Contents
Related Manuals for SARIV SAR002
Summary of Contents for SARIV SAR002
- Page 1 2 , 4 ÷ 4, 0 M M A L L A L L O Y S A N D 4, 8 M M A L UM I N UM SARIV s.r.l. Unipersonale Via del Progresso, 2 - 35014 FONTANIVA PD - ITALY Tel.
-
Page 2: Table Of Contents
Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum Contents 1 – SAFETY INSTRUCTIONS ........................3 2 – GENERAL INFORMATION ........................ 3 2.1 - MANUFACTURER ......................3 2.2 - ASSISTANCE ........................3 2.3 –... -
Page 3: Safety Instructions
The tool is manufactured in compliance with the European Directives, which are in force when the tool itself is put on the market. As the tool is not included in ENCLOSURE IV of DIRECTIVE 89/392/EEC, Sariv S.r.l. issues a self-certification to apply the EC marking. -
Page 4: Tool Description
3 – TOOL DESCRIPTION 3.1 – OPERATING SYSTEM La rivettatrice oleopneumatica SAR002 è progettata per l’applicazione di rivetti di diametro 2,4 mm, 3,0 mm, 3,2 mm, 4,0 mm di tutte le leghe e rivetti di diametro 4,8 mm in alluminio. -
Page 5: Operation
Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum 4 – OPERATION 4.1 – TOOL PREPARATION BEFORE USING 1. Prior to each operation of the riveter, you must choose the rivet size you are going to use. If you set 4.8mm rivets, no changes on the tool are necessary (4.8mm nosepiece is installed on the riveter). -
Page 6: Maintenance
Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum 5 – MAINTENANCE Regular services should be performed on the tool, in order to assure that the riveter could work properly and have a longer life. - Page 7 Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum To remove the oil in excess, unscrew part #51 approximately 1/4 turn. Depress and release the trigger to make the air circulate through the riveter; the oil will leak out of the top of the tool from the oil hole as the trigger is depressed.
-
Page 8: Spere Parts
Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum 6 – SPERE PARTS Picture 6.1-A – Spare Parts... - Page 9 Instruction Manual Hydro-pneumatic tool for blind rivets SAR002 Ed. January 2021 2,4 ÷ 4,0 mm all alloys, and 4,8 mm aluminum MACHINE SPARE PARTS CODE DESCRIPTION Q.TY CODE DESCRIPTION Q.TY SAR002/8-01 NOSEPIECES SET SAR002-30 SPRING FOR AIR VALVE ROD SAR002-02...
-
Page 10: Declaration Of Conformity
Via del Progresso, 2 – Fontaniva (PD) – Italy STATE In the person of the Legal Representative Nicola Sartore that the following tool SAR002 – Hydro pneumatic riveting tool for blind rivets IS MANUFACTURED ACCORDING TO the requirements Council Directive Machineries C.E.E. 89/392 (Machinery), subsequent amendments, and standards EN292-1, EN292-2 SARIV s.r.l.
