Instruction Manual
Ed. December 2019
INSTRUCTION MANUAL
SAR
H Y D RO - PN E UM A T I C T O O L F O R
B L I N D RI V ET S
3 . 0 ÷ 6. 4 M M A L L A L L O Y S , A N D
7 . 8 M M A L U M I N U M
SARIV S.R.L.
Via del Progresso, 2 - 35014 FONTANIVA PD - ITALY
Tel. (+39) 0495 941 313 - Fax. (+39) 0495 941 920
www.sariv.it-
info@sariv.it
Hydro-pneumatic tool for blind rivets
3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum
008
SAR008
DISTRIBUTOR'S STAMP
SAR 008
1
Advertisement
Table of Contents
Related Manuals for SARIV SAR008
Summary of Contents for SARIV SAR008
- Page 1 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum INSTRUCTION MANUAL SAR008 DISTRIBUTOR’S STAMP H Y D RO - PN E UM A T I C T O O L F O R B L I N D RI V ET S 3 .
-
Page 2: Table Of Contents
Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum Contents 1 – SAFETY INSTRUCTIONS ........................3 2 – GENERAL INFORMATION ........................ 3 2.1 - MANUFACTURER ......................3 2.2 - ASSISTANCE ........................ -
Page 3: Safety Instructions
The tool is manufactured in compliance with the European Directives, which are in force when the tool itself is put on the market. As the tool is not included in ENCLOSURE IV of DIRECTIVE 89/392/EEC, Sariv S.r.l. issues a self-certification to apply the EC marking. -
Page 4: Tool Description
3 – TOOL DESCRIPTION 3.1 – OPERATING SYSTEM The hydro-pneumatic SAR008 is designed to place blind rivets of diameters of 3,0 mm, 3,2 mm, 3,4 mm, 4,0 mm, 4,8 mm, 6,0 mm, 6,4 mm of all alloys and 7,8 aluminium. -
Page 5: Opeartion
Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum 4 – OPERATION 4.1 – TOOL PREPARATION 1. Prior to each operation of the Riveter, you must choose the size rivet you’ll be using. If setting diam. 6,0 –... - Page 6 Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum 5. NEVER allow Mandrel Bottle to fill more than 1/3 full; damage to Hydraulic Plunger may occur. To empty Mandrel Bottle, turn knob at end of bottle to reveal bottle opening.
-
Page 7: Care And Maintenance
Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum 5 – CARE AND MAINTENANCE 1. Regular service should be performed on this tool for best performance and longer life of tool. 2. - Page 8 Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum Insert the rivet The rivet body touches the nosepiece 11. To remove excess oil, unscrew Oil Plug (#17) approximately 1/4 turn. Depress and release the trigger to cycle air through the Riveter –...
-
Page 9: Spare Parts
Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum 6 – SPARE PARTS Figure 6.1-A –Spare Parts... - Page 10 Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum TOOL SPARE PARTS CODE DESCRIPTION CODE DESCRIPTION SAR008-01E 6.4 mm NOSEPIECE SAR008-63 O-RING SEAL SAR008-02 HEAD SAR008-64 O-RING SEAL SAR008-03 JAW HOUSING...
-
Page 11: Accessories
Hydro-pneumatic tool for blind rivets Instruction Manual SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum 7 – ACCESSORIES... -
Page 12: Declaration Of Conformity
SAR 008 Ed. December 2019 3.0 ÷ 6.4 mm all alloys, and 7.8 mm aluminum DECLARATION OF CONFORMITY We, SARIV S.R.L. Via del Progresso, 2 – Fontaniva (PD) – Italy STATE In the person of the Legal Representative Nicola Sartore that the following tool SAR002 –...
