PowerDIN 4PZ
MANUAL
18.11.2020

Advertisement

Table of Contents
loading

Summary of Contents for Netio PowerDIN 4PZ

  • Page 1 PowerDIN 4PZ MANUAL 18.11.2020...
  • Page 2: Table Of Contents

    5.3.4 M2M API Protocol – Telnet ............40 5.3.5 M2M API Protocol – Modbus/TCP ..........45 5.3.6 M2M API Protocol – MQTT-flex ............. 49 5.3.7 M2M API Protocol – Netio Push ............ 53 5.3.8 M2M API Protocol – SNMP ............55 Cloud ....................59 Users ....................
  • Page 4: Introduction

    Introduction Thank you for purchasing this product of NETIO products a.s. Before using your product, please read this (MAN) and the included to avoid problems with incorrect User Manual Quick Installation Guide (QIG) installation or use. Caution: The product works with mains voltage. Mishandling may damage it or result in injury or death.
  • Page 5: General Characteristics

    2 General characteristics  Metered outputs: 2 channels  Digital Outputs: 4 in total  DO Metered power outputs switching element: 2x Relay + ZCS (Out 1, 2: SPST-NO) – Max 16A  DO Relay outputs switching element: 2x Relay (Out 3, 4: NO/NC) – Max 2A ...
  • Page 6: Specifications

    3 Specifications 100–240 V; 50/60 Hz; 16 A Power 2x, 16 A total / 16 A per output (Out 1, 2) DO Metered power outputs Type 3 (CAT III) Surge protection Micro-disconnection (µ) (resistive load), SPST-NO 1E5 switching cycles, max. 1.5 kV pulse voltage DO Power Output relays Switch heat and fire resistance class 1 ZCS (Zero Current Switching)
  • Page 7: Features

    (especially in case of frequent switching on and off).  Significantly reduced electromagnetic interference caused by repeated switching on and off. Zero current switching (ZCS) significantly improves the lifetime of the NETIO device and the connected end devices. This function is particularly important in case of frequent switching.
  • Page 8 <1% Quick WiFi connection setup (AP mode installation)  NETIO PowerDIN 4PZ creates a WiFi network that you connect to with your PC or mobile phone.  It then scans for WiFi networks in the vicinity, and lets you choose from a list and type the password.
  • Page 9: Drawings

    3.2 Drawings Figure 1 – PoweDIN 4PZ front and side view (millimeters) Figure 2 – PoweDIN 4PZ cut view (millimeters)
  • Page 10: Device Description

    3.3 Device description 1. 1x RJ45 LAN jack 2. LEDs (OUTPUTS, INPUTS, M2M and WiFi) 3. RJ45 LEDs – Ethernet states (yellow and green) 4. “SETUP” button (under plastic plate with green label) 5. 230V Input and Outputs terminal blocks 6.
  • Page 11: Led And Button Functions

    Blink when some Input state change Blink when some M2M communication is in progress. M2M (red) Communication with NETIO Cloud included (if Cloud enabled). (communication of WEB administration or Mobile app is not indicated) WiFi (yellow) Light when connected to WiFi...
  • Page 12: Package Contents

    Figure 5 – PoweDIN 4PZ package 4 Configuration and control NETIO PowerDIN 4PZ can use the Ethernet connection (RJ45) or WiFi connection to network. The description of connection options below (LAN or WiFi) apply for the new devices or devices after “Restoring factory defaults”.
  • Page 13: Connecting Powerpdu 4Pz To A Local Wifi (Ap Mode)

     Device configuration page should open automatically. If not, open a web browser and enter http://10.0.42.1 You will see NETIO PowerDIN 4PZ WiFi configuration page. (Figure 7). Figure 6 – Connecting to PowerDIN 4PZ AP Figure 7 – Web Interface in AP mode...
  • Page 14  Select your network in the list of detected networks and click “Next” (Figure 8).  Enter the password for the selected WiFi network. You may also change the device name. If your network does not use DHCP, unselect this option and manually enter the IP address and other network parameters (Figure 10;...
  • Page 15 DNS – DNS server for your network or a public DNS, e.g.  8.8.8.8 Device name – specify a name under which the PowerDIN 4PZ  will be visible in the local network For more information, see chapter 5.6 Network Configuration Figure 10 –...
  • Page 16: Nfc Installation In 60 Seconds

    NFC (Near Field Communication) is a technology supported by some mobile phones (and tablets). Using a mobile phone with NFC support and the NETIO Mobile 2 app, even a device that is powered off can be configured. The device will apply the new configuration as soon as it is powered on.
  • Page 17 IP address, Subnet mask and Default gateway. After applying the settings, NETIO device will be accessible at the specified address. Enter the IP address into a web browser or the NETIO Mobile app and log in to the device. Note: For MAC or Linux users use the NETIO Discover Multiplatform version.
  • Page 18: Login To Device Web

    4.5 Login to device web Figure 15 – PowerDIN 4PZ login dialog To log in, use admin admin (default login username / password)
  • Page 19: Restoring Factory Defaults

    Forgotten password The reset to factory defaults is also used when the password has been forgotten. After restoring the factory defaults, the username and password to access the PowerDIN 4PZ will be “admin” / “admin”. 4.7 Controlling the output manually The outputs can be switched on/off (toggled) by pressing the button quickly 3 times in a row.
  • Page 20: Web Interface

    5 Web interface 5.1 Outputs In the left menu, click Outputs. A screen showing the output appears. The output can be controlled directly with two buttons: Figure 16 – Controlling the output ON/OFF button controls the output directly. When the output is on, the button is green; when the output is off, the button is grey .
  • Page 21: Outputs - Energy Measurements

    Reset button switches the output off and then back on. It is actiove only when the output is On. A confirmation is requested before the action is performed. The function is enabled only when the output is switched on. When the output is switched off, the Reset button is disabled. Click Reset to confirm the action or Cancel to cancel it.
  • Page 22 By default, the cumulative energy consumption is counted from the time the NETIO device was first powered on. To reset the counter, go to the Settings > System tab and click the Reset Power Consumption Counters button (see Figure 18).
  • Page 23: Outputs - General

    5.1.2 Outputs - General Click the picture of the output to open detailed settings. General tab configures basic parameters for controlling the output. Figure 19 – General output configuration Output name is shown above the two control buttons to improve clarity. Short ON/OFF delay is an integer specifying, in milliseconds, the duration for the Short OFF (power cycling) and Short ON actions.
  • Page 24: Outputs - Schedule

    5.1.3 Outputs - Schedule Scheduler function can be used to switch the output on and off at specified times. Select a schedule to specify when the output should be turned on. After selecting a schedule, the on-times for the output according to that schedule are shown graphically. Click Save Changes to confirm the selected schedule.
  • Page 25: Inputs

    5.2 Inputs The PowerDIN 4PZ has two inputs providing their status and S0 counter value. 5.2.1 Digital Inputs – Status and S0 Counters In the left menu, click Inputs. A screen showing the inputsappears. Figure 21 – Viewing the inputs...
  • Page 26: Inputs - General

    5.2.2 Inputs - General Click the picture of the input to open detailed settings. General tab configures basic parameters of the input. Figure 22 – General input configuration The Digital Input name can be set to identify specific digital input. Click Save Changes to save the settings.
  • Page 27: M2M Api Protocols

    5.3 M2M API Protocols All M2M protocols use the same values for the action parameter to control the output. Allowed values are: 0 – turns the output off 1 – turns the output on 2 – short OFF – turns the output off for a short time (if the output was off, it will be turned on) 3 –...
  • Page 28: M2M Api Protocol - Xml (Rest M2M Api)

    (output control). You may also fill in the username and password for this mode. Username Username for the respective access mode (Read-Only/ReadWrite). Note – this is unrelated to the username for accessing the NETIO 4x web administration interface. When left empty, the protocol will not require any authentication. Password Password for the corresponding username (Read-Only/ReadWrite).
  • Page 29 For an example of reading the output state using XML API, click the “Test XML API - Open XML API file (read password required)” link. After entering the username and password, you will receive an xml file with the NETIO device current state.
  • Page 30 <State>1</State> <Action>6</Action> <Delay>2020</Delay> <PowerFactor>0.60</PowerFactor> <Phase>-37.57</Phase> <Load>10</Load> <Current>67</Current> <Energy>9</Energy> <ReverseEnergy>0</ReverseEnergy> </Output> <Output> <ID>2</ID> <Name>Power output 2</Name> <State>0</State> <Action>6</Action> <Delay>2020</Delay> <PowerFactor>1.00</PowerFactor> <Phase>0.00</Phase> <Load>0</Load> <Current>0</Current> <Energy>27</Energy> <ReverseEnergy>0</ReverseEnergy> </Output> <Output> <ID>3</ID> <Name>Free Contact 3</Name> <State>0</State> <Action>6</Action> <Delay>2020</Delay> </Output> <Output> <ID>4</ID> <Name>Free Contact 4</Name> <State>1</State> <Action>6</Action>...
  • Page 31 The following example XML files for controlling the device can be downloaded directly from the web administration:  Set output 1 to ON  Set output 1 to OFF  Toggle output 1 Click Download XML Schema (XSD) to download the .xsd schema file. The Upload XML file to the device button opens the following dialog for testing: Host –...
  • Page 32 For the specifications of the M2M XML API protocol, visit the Support > Download section of our website and see the following document: XML - description of NETIO M2M API interface - PDF For more information and a practical demonstration of using the XML protocol with NETIO smart sockets, see the following Application Note: AN20...
  • Page 33: M2M Api Protocol - Json (Rest M2M Api)

    Username Username for the respective access mode (Read-Only/ReadWrite). Note – this is unrelated to the username for accessing the NETIO device web administration. When left empty, the protocol will not require any authentication.
  • Page 34 For an example of reading the output state using JSON API, click the “Test JSON API: Open JSON API file (read password required)” link. After entering the username and password, you will receive a json file with the NETIO device current state.
  • Page 35 {"ID":2,"Name":"Input 2","State":0,"S0Counter":30} The following example json files for controlling the device can be downloaded directly from the web administration:  Set output 1 to ON  Set output 1 to OFF  Toggle output 1 The Upload JSON file to the device button opens the following dialog for testing: Host –...
  • Page 36 For more information about the M2M JSON API, visit the Support > Download section of our website and see the following document: JSON - description of NETIO M2M API interface - PDF For more information and a practical demonstration of using the JSON protocol with NETIO smart sockets, see the following Application Note: AN21...
  • Page 37: M2M Api Protocol - Url-Api (Rest M2M Api)

    5.3.3 M2M API Protocol – URL-API (REST M2M API) Figure 27 –URL API protocol configuration Enable URL API Enables M2M URL API functions in the system kernel. Port Read-only value. Indicates the port where the device currently listens for M2M URL API commands. This port is the same for all http based M2M API protocols and web administration and can be changed in Settings / System (chapter System).
  • Page 38 Download section of our website and see the following document: URL API - description of NETIO M2M API interface - PDF For more information and a practical demonstration of using the URL-API protocol with NETIO smart sockets, see the following Application Note:...
  • Page 39 AN19 URL API (http GET) protocol to control NETIO 4x power sockets/outlets 110 / 230V...
  • Page 40: M2M Api Protocol - Telnet

    Username Username for the respective access mode (Read-Only/ReadWrite). Note – this is unrelated to the username for accessing the NETIO device web administration. When left empty, the protocol will not require any authentication.
  • Page 41 Start Telnet connection to a NETIO device IP address and its Telnet port When the connection is established, the NETIO device returns the following response and is ready to receive commands. Telnet welcome message 100 HELLO 489F6C4F - KSHELL V2.1 Note: The Telnet connection is automatically terminated after 60 seconds of inactivity.
  • Page 42 <action> is replaced by a parameter described below If no <action> is provided, the state of the output is returned. input list Returns state of input. input list (input is ON) Each command must be followed by CR and LF characters (hexadecimal 0D and 0A). Typically, you can use Enter in the terminal.
  • Page 43 4 on device, which has only 1 socket) For more information about the Telnet protocol, visit the Support > Download section of our website and see the following document: Telnet - description of NETIO M2M API interface - PDF...
  • Page 44 For more information and a practical demonstration of using the Modbus/TCP protocol with NETIO smart sockets, see the following Application Note: AN10 Telnet control of electrical power sockets (M2M API – KSHELL)
  • Page 45: M2M Api Protocol - Modbus/Tcp

    5.3.5 M2M API Protocol – Modbus/TCP Figure 29 – Modbus/TCP protocol configuration Enable Modbus/TCP Enables M2M Modbus/TCP functions in the system kernel. Port Specific port for Modbus/TCP only, range 1 – 65535. The device do NOT alerts you if you specify a port number that is already occupied. Last access IP Read-only value indicating the IP address from which the last Modbus/TCP command was received.
  • Page 46 Function Register Value Description 0x01 102(101) 0/1 Read 1st output state (101 when Wire address used) 0x01 Read 2nd output state 0x01 Read 3rd output state 0x01 Read 4th output state 0x02 Read 1st input state 0x02 Read 2nd input state 0x03 uInt16 Number of digital inputs...
  • Page 47 Set "Short" delay of 4th output [s*10] For more information about the M2M Modbus/TCP protocol, visit the Support > Download section of our website and see the following document: Modbus / TCP - description of NETIO M2M API interface - PDF...
  • Page 48 For more information and a practical demonstration of using the Modbus/TCP protocol with NETIO smart sockets, see the following Application Note: AN27: Modbus/TCP with NETIO 4x – Control and measure LAN power sockets...
  • Page 49: M2M Api Protocol - Mqtt-Flex

    Text area for entering the MQTT-flex configuration. Save Changes Saves the changes. NETIO device uses json to define the MQTT-flex structure (MQTT-flex Config). Both subscribe and publish topics can be defined. Publish topics may include actions that initiate a transmission.
  • Page 50 MQTT-flex configuration example: "broker": { "clientid": "netio${DEVICE_SN}", "keepalive": 30, "password": "", "port": 1883, "protocol": "mqtt", "ssl": false, "type": "generic", "url": "broker.hivemq.com", "username": "" "publish": [ "events": [ "source": "OUTPUTS/1/STATE", "type": "change" "source": "OUTPUTS/2/STATE", "type": "change" "source": "OUTPUTS/3/STATE", "type": "change" "source": "OUTPUTS/4/STATE", "type": "change"...
  • Page 51 For more information about the M2M MQTT-flex API, visit the Support > Download section of our website and see the following document: MQTT-flex - description of NETIO M2M API interface - PDF There are wide options for subscribe and publish sections and its possibilities expand over the time.
  • Page 52 For more information and a practical demonstration of using the MQTT protocol with NETIO smart sockets, see the following Application Note: AN40 Getting started with PowerCable MQTT-flex via HiveMQ MQTT broker to mobile App...
  • Page 53: M2M Api Protocol - Netio Push

    5.3.7 M2M API Protocol – Netio Push Figure 31 –Netio Push protocol configuration Enable Netio Push Enables Netio Push functions in the system kernel. Target host HTTP server: Defines the parameters of the target: - http / https to specify the protocol...
  • Page 54 60seconds). It means the output can be switched only when the TCP/IP connection is established. In default once every 60 seconds. If the response from Target host is error code 200 (OK) and the payload contains valid NETIO JSON structure with control command then the Output will be set accordingly. This way is possible to control device even if this is in private network behind NAT.
  • Page 55: M2M Api Protocol - Snmp

    Also called the “community string” in SNMP. Similar to a username/password combination. Needed for reading information from NETIO device over SNMP. We recommend to use “pure” ASCII characters (that is, to avoid accented and special characters, such as @, & and so on, if possible).
  • Page 56 Download MIB file Use this button tu download MIB. When the SNMP API is enabled, other M2M protocols are disabled. After clicking Save changes, you will be asked to confirm the deactivation of the other protocols. Click Confirm to confirm the action or Cancel to return to the SNMP API protocol configuration. The MIB can be downloade from a device web administrator as described above.
  • Page 57 netioFrequency.0 INTEGER 49900 Frequency in the 1.3.6.1.4.1.47952.1.2.2.0 power grid [mHz] netioTotalCurrent.0 INTEGER [mA] 1.3.6.1.4.1.47952.1.2.3.0 netioOverallPowerFactor.0 INTEGER Current power 1.3.6.1.4.1.47952.1.2.4.0 factor * 1000 netioTotalLoad.0 INTEGER 1.3.6.1.4.1.47952.1.2.5.0 netioTotalEnergy.0 INTEGER [Wh] 1.3.6.1.4.1.47952.1.2.6.0 netioEnergyStart.0 DateAndT 2017-6- Initial date and 1.3.6.1.4.1.47952.1.2.7.0 23,5:47:3.0,+0: time. UTC based netioInputID.x.0 INTEGER 1.3.6.1.4.1.47952.1.3.1.1.x.0...
  • Page 58 Objects/OIDs). Please contact NETIO support in case of questions. For more information and a practical demonstration of using the SNMP protocol with NETIO smart sockets, see the following Application Note: SNMP management of 110/230V power outlets from the command line in Windows and Linux...
  • Page 59: Cloud

    5.4 Cloud Netio Cloud is a service provided by NETIO Products a.s. and allow easy central remote control and monitoring of the NETIO devices. What can you do in NETIO Cloud? Output control  On/Off switch.  Reset button (Short Off for defined time).
  • Page 60 Connection to NETIO Cloud can be configured on Cloud tab. Figure 34 – Cloud configuration Enable NETIO Cloud Check to enable NETIO Cloud. Status Odd: NETIO Cloud disabled Disconnected: Device not connected to Cloud Cloud connect faild…reconnecting: Device it trying to connect to Cloud.
  • Page 61 Save Changes Saves the changes. Registration token Enter the registration token from NETIO Cloud web - shown when “ADD DEVICE” button used. Then press “Add device” button. Remove device If this device is connected to NETIO Cloud use this button to remove/disconnect it from NETIO Cloud.
  • Page 62: Users

    5.5 Users When several users use the NETIO device, it is advisable to assign them different accounts with the necessary privileges. In the left menu, select Users. Figure 35 – Adding and managing users Username The username. The NETIO device must always have an “admin” account with administrator privileges;...
  • Page 63: Schedules

    Schedules can specify when should an output be switched on or when is an action valid. To manage schedules, select Schedules in the left menu. By default, NETIO PowerDIN 4PZ contains one schedule: Always. To create a new schedule, click Create schedule. Specify the schedule name and set the intervals when the output should be switched Note...
  • Page 64 Figure 36. Adding a custom schedule A new interval can be quickly created by marking the corresponding slots by clicking and dragging with the left mouse button. An existing interval can be shortened or extended by dragging either end of the interval. To delete an interval, click it with the right mouse button. To create an interval encompassing an entire day, click the box next to that day in the All day column.
  • Page 65 Figure 37. Adding an interval with a precision to the second Deleting a schedule By deleting a schedule, all Schedulers for specific outputs with this schedule are automatically disabled. The states of the respective outputs are unchanged; however, from that moment on, the outputs are under manual control.
  • Page 66: Settings

    5.7 Settings NETIO PowerDIN 4PZ can use the Ethernet connection (RJ45) or WiFi connection to network. When the Ethernet cable is connected the WiFi is completely turned off. When the Ethernet cable is disconnected then the WiFi turns automatically on. So Wi-Fi can be the main or only backup connection or not used.
  • Page 67: Network Configuration

    Ethernet is disconnected. 5.7.2 Network Configuration This section allows configuring the IP parameters of the PowerDIN 4PZ network interface, which are essential for correct network operation. One of the options Wi-Fi / Ethernet or both can be configured depending on chosen connectivity.
  • Page 68 (unsupported characters are replaced). Save Changes Saves the changes. Caution After changing the network configuration, it may be necessary to re-discover the NETIO device at its new address. The discovery procedure is described in section Detecting and configuring the IP address...
  • Page 69 Ethernet Figure 40 – Network configuration - Ethernet MAC address Ethernet address of the Ethernet network adapter. Unique for each device. Also] corresponds to the NETIO device serial number. Status Connection status Use DHCP When selected, the device attempts to obtain network configuration from a DHCP server.
  • Page 70 (unsupported characters are replaced). Save Changes Saves the changes. Caution After changing the network configuration, it may be necessary to re-discover the NETIO device at its new address. The discovery procedure is described in section Detecting and configuring the IP address...
  • Page 71: Date / Time

    Set time manually Select if you do not wish to use a NTP server. Date Current date and time on the NETIO device’s clock. Can be modified if necessary. Synchronize with this computer Check this box to copy the current date and time from your computer to NETIO device’s internal clock.
  • Page 72: Firmware

    Build date Creation date of the installed firmware version. Model Model designation. Revision Revision number. Firmware Package Click Browse to select a firmware file to install. Then click Install Firmware to start the installation. Firmware files are available at: https://www.netio-products.com/en/powerdin-4pz-firmware...
  • Page 73 Go to the product page on our website (link below), select your product and scrool down the page. https://www.netio-products.com/en/products/all-products Figure 43 – WEB of NETIO products – Link to Firmware download Figure 44 – Firmware download link at the netio-products.com website...
  • Page 74: System

    Currently installed firmware version and a link to the Firmware tab. Device name Shown in NETIO Discover and under the device logo in the web administration (in the figure above: PowerDIN-EE under the PowerDIN logo in the top left corner).
  • Page 75 Current http port for webadministration and http based M2M API protocols (XML, JSON, URL API). If the port number is different from 80, it has to be specified in the web browser after the NETIO device IP address, e.g.: 192.168.0.99:888 Enable Periodic device restart Enables automatic restarting of the device.
  • Page 76: Log

    5.8 Log In the left menu, select Log. Figure 46 - Event log Refresh Reloads the log to show the most recent entries. Export to file Exports the log in the html format. Clear log Clears the log records. The log contains 40 most recent events only and is cleared when the device is restarted.
  • Page 77 Event related to a request from the web interface, e.g. User logged in M2M XML protocol JSON M2M JSON protocol M2M URL M2M URL API protocol Modbus M2M Modbus/TCP protocol MQTT M2M MQTT protocol SNMP M2M SNMP protocol Web server Web server, e.g. Client disconnected Cloud NETIO Cloud...
  • Page 78: Declaration Of Conformity (Red Ce)

    PowerDIN 4PZ This declaration of conformity is issued under the sole responsibility of the manufacturer. Object of the declaration: “NETIO PowerDIN 4PZ controlled and monitored over the WiFi / LAN network”. RED: The product mentioned above to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the Radio Equipment Directive (2014/53/EU).
  • Page 79: Netio Products Overview

    7 NETIO products overview WiFi / IQRF Output Switched Metered Button(s) Industrial Power-Up Power (RJ45) Antenna 868MHz Type outputs outputs Inputs / LED features state ZCS, PowerPDU 4C 110/230V / 10A 4 / 4 RS232 PowerPDU 4PS 110/230V / 10A...
  • Page 80 NETIO products – features Scheduler IP Watadog function function scripting PowerPDU 4C v1/v3 PowerPDU 4PS v1/v3 PowerPDU 8QS v1/v3 PowerDIN 4PZ v1/v3 PowerBox 3Px (E,F,G) v1/v3 PowerBox 4Kx (E,F,G) v1/v3 PowerCable REST 101x v1/v3 PowerCable IQRF 901x...
