Barcelona
500 CFM/12.5 SONES @ 0.10" WG. HVI CERTIFIED 120 Volts, 2.8 amps, 60 hz.
• Dimensions
Overall bottom projection - 23
Height
-12
(less chimney)
Available widths: 36"
• Hood Body
All metal cold rolled or stainless steel, finished in powder coat
or brushed stainless steel.
• Motor
3 speed, permanently split capacitor motor. Rated 120 volts,
60 hz., 2.8 amps.
• Lighting
2 - fully enclosed 40 watt maximum candelabra bulbs.
• Ducting Options
Vertical ducting: 6" round duct adapter complete with polymetric
back draft damper ensuring quiet operation.
Ductless: Requiers charcoal filter
• Blower Wheel
Dual inlet, electronically balanced polymetric centrifugal blower
wheel, 5
27 / 32
" width 59 paddles.
• Mounting
Wall mounted. Install 20" to 30" from cooking surface.
• Filters
Grease Filter: Dishwasher safe, BCGF-01
Charcoal Filter: BCCF-01
• Available Finishes
White, Black, Stainless Steel and Copper.
Air Flow - CFM
508
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
®
Collection
5 / 8
"
3 / 4
"
(not included).
.
(included)
.
(not included)
Static Pressure (inches of w.g.)
0
0.1
0.125
0.25
500
498
488
IN
RPM
WATTS
W.G.
Wall Mounted Range Hood
PERFORMANCE
0.375
0.5
0.75
478
469
451
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
CANTABRIA
RANGE HOODS
CAN SERIES
29 " to
41 " Max
HVI Sones
Fan Speed
@ .1 SP
1.0
430
12.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
™
7 / 8
7
"
7 / 8
7
"
35
7 / 16
"
Power
RPM
Watts
2375
465
Updated 8-07
