Air King AK300LS Specifications

310 CFM/3.5 SONES @ 0.10" wg. • 290 CFM/3.5 SONES @ 0.25 wg.
• Grill
White, polymeric grill secured in place with torsion springs;
easily removed if necessary, dimensions - 14
• Blower Wheel
Balanced polymeric dual inlet blower wheel 6" dia. x 5
59 paddles, secured in place using 8M hex nut.
• Motor
Enclosed 4 pole electronically balanced permanently split
capacitor motor (PSC); life time lubrication, suitable for
continuous operation. Motor bearings - sleeve. Rated 115/120
volts, 60 Hz, 0.75 amps.
• Fan Housing
23 gauge galvanized steel housing.
Overall dimensions 12
• Duct Collar
6" round, zinc plated metal collar adapter. 6" spring loaded
aluminum backdraft damper.
• Ventilating Area
For bathrooms up to 310 sq. ft. For other rooms up to 385 sq. ft.
• Electrical Connections
1 / 2 " electrical knockouts provided. Easy wiring access via either
internal or external wiring compartment cover.
Air Flow - CFM 320
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
HVI CERTIFIED 120 Volts, 0.75 amps, 60 hz.
5 / 16 " x 14
7 / 8 "x 12 3 / 4 "x 9 7 / 8 ".
Static Pressure (inches of w.g.)
0 0.05 0.1 0.15
315 310 304
IN
RPM WATTS
W.G.
5 / 16 ".
9
3 / 8 " depth,
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
• Unit Mounting
The housing will mount through drywall thickness up to
with a rough-in opening of 13
to R-40. The housing will mount either between 16" or 24" on
center joists, using the 2 supplied housing mounting brackets.
The housing mounting brackets can be adapted for overhead
mounting (hardware not provided). The unit is provided with an
optionally installed ceiling flange to ensure proper building
infiltration rates are maintained and that no air leaks occur
between the fan housing and ceiling cutout.
• Single Pack Shipping Info
Box Dim: 20" x 15
UPC: 0-83162223002-7
Shipping Weight: 17 lbs.
PERFORMANCE
0.2 0.25 0.3
299 290 285
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (877)-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
AK300LS
EXHAUST FANS
12 7 / 8 "
12 3 / 4 "
7 / 8 "
14 5 / 16
14 5 / 16 "
CUL/HVI
1 / 8 " x 13". Rated for ceilings insulated
15 / 16 " x 11 3 / 8 "
HVI Sones Fan Speed
@ .1 SP RPM
0.35
275 3.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
6"
"
3 / 4 ",
Power
Watts
1200 80
Updated 6-06
