882IS Digital Weight Indicator

IS6V2 Battery Instructions

The IS6V2 Battery is an FM-Entity Approved battery supply for use in hazardous locations, see specifications below. It is
mounted below the 882IS indicator and is removable for charging in the safe area. Install per RLWS Control Drawing 186430.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at
Warranty information can be found on the website at
If modifications are made to the installation procedure, or the instrumentation is changed in any way including
IMPORTANT
field repair or modification, the FM approval is void, and all warranties, expressed, or implied are void. The
customer becomes fully responsible and liable for such modifications.

Battery Installation in Tilt Stand

Connections to the battery pack must be made in the non-hazardous area before connecting the cable to the
IMPORTANT
882IS indicator.
1. Ensure battery cable and clamp are attached to the 882IS battery before entering hazardous area, see
Connections and Installation on page
2. Thread the tilt stand knobs into the battery, but leave them loose.
3. Slide the battery into the tilt stand with the connector cable on side that rear of indicator is mounted.
4. Secure with the captive screw to mount and tighten up the tilt stand knobs.
June 7, 2019
www.ricelake.com/warranties
Figure 1. IS-6V2 Battery Dimensions (shown in inches)
2.
www.ricelake.com
5.00
Cable
PN 194893
