Aiphone LEF-1C Specifications

LEF-1C
Sub Master Station
DESCRIPTION:
The LEF-1C is an open voice sub master station
for the Aiphone Master Sentry series. It provides
door answering and door release, as well as the
ability to make an All Call announcement
throughout the system. Music can be heard through
every station. The LEF-1C is for use in systems
containing the BG-10C, which provides door chime,
All Call and music. Music and voice volume controls
are included.
A call from the door station sounds a 4-stroke
chime at all master and sub master stations. To
answer, press to talk and release to listen at the
LEF-1C. The person at the door station speaks
hands free. A door release mechanism can be
activated by pressing the door release button.
To place an "All Call", press and hold the "All Call"
button while making an announcement. A short
pre-tone will precede the All Call at the other
stations. There is no hands free reply after placing
an All Call. However, other masters and sub
masters can respond by using their "All Call" button.
The LEF-1C flush mounts into a wall. Additional
sub and master stations are available in surface
or flush mount styles. Outdoor stations are
available in surface or flush mount styles.
Speaker
Door release
Privacy button
BGM Volume
Voice volume OFF Button

SPECIFICATIONS

Mic
Talk Button
All Call Button
FEATURES:
• 4-stroke chime from door station
• Press-to-talk communication at master
• Hands free communication at door
• All Call allows communication to all masters and
sub masters in the system simultaneously
• Monitor entry area undetected from inside
• Voice and background music volume controls
• Will function in any LEF system where
the BG-10C is included
• Door release
MOUNTING &
INSTALLATION:
