2 Hardware Configuration

All connector and strapping field orientations in this manual are relative to the board
orientation as pictured in Figure 1-2. VAMP-XGA3 Basic Layout and Connectors.
Unless otherwise specified, horizontal double row connectors and single row strapping
fields have pin 1 in the top right corner or to the right of the strapping field. Horizontal single row
connectors have pin 1 to the left. All single row connectors are locking type.. Pin 1 always has a
square pad. All other pins have round pads.

Figure 2-1. Horizontal Connectors and Strapping Fields.

Also if the connector is vertical, pin 1 is in the top left corner.

Figure 2-2. Vertical Connectors and Strapping Fields.

Single row connectors are numbered sequentially from top to bottom or one end to the
other.

Figure 2-3. Single Row Connector and Strapping Field Pin Numbers.
