CardioWall
®
Pro-X Elite
Order and Installation Manual
For models from March 2016 onwards
Rugged Interactive
Unit 1, Callywith Court,
Callywith Industrial Estate,
Bodmin, Cornwall, UK
PL31 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated 20/01/2021
© Rugged Interactive
2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CardioWall Pro-X Elite and is the answer not in the manual?

Questions and answers

Related Manuals for Rugged Interactive CardioWall Pro-X Elite

Summary of Contents for Rugged Interactive CardioWall Pro-X Elite

  • Page 1 ® Pro-X Elite Order and Installation Manual For models from March 2016 onwards Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated 20/01/2021 © Rugged Interactive 2021...

  • Page 2: Table Of Contents

    Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide Pro-X Elite System Specifications Pro-X Elite Installation Checklist Next Steps © Rugged Interactive 2021...

  • Page 3: Section 1 - Ordering Process

    Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use.

  • Page 4: Order And Installation Checklist

    1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐...

  • Page 5: Ordering And Installation Timeline

    * We do our best to ensure orders are ready on a five-week lead time, however during busy periods or for large orders, the lead time may be longer than outlined here. Lead time will also be affected by graphics guidelines, approval and payment delays. Pro-X Elite – Section 1 - Ordering Process © Rugged Interactive 2021...

  • Page 6: Getting Started

    If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:...

  • Page 7: Section 2 - Safety Guidelines

    Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. ▪ Don’ts: Do not wear shoes with leather soles or high heels.

  • Page 8: In Play Safety Guidelines

    (such as buckles, studs, toggles or alike). Do not wear shoes with leather soles, high heels, sandals, boots or bare feet. ▪ No food, drink or chewing gum during participation. ▪ Pro-X Elite – Section 2 - Safety Guidelines © Rugged Interactive 2021...
  • Page 9 Use of this equipment is physically demanding: this is a high-impact, full body activity which requires intense focus, awareness of your body’s strengths and limitations, awareness of the environment around you and extreme caution. Pro-X Elite – Section 2 - Safety Guidelines © Rugged Interactive 2021...

  • Page 10: Section 3 - Installation

    +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. ☐ 1 x CardioWall Pro-X Elite. ☐...

  • Page 11: Installation Overview

    Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. If you have any concerns on how or what the product is installed to, contact a structural engineer prior to beginning the installation.

  • Page 12: Detailed Installation

    A waiting / spectating area positioned nearby is advised. ▪ A leaderboard is highly recommended. IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882. Pro-X Elite – Section 3 - Installation © Rugged Interactive...
  • Page 13 Pro-X Elite Order and Installation Manual: Installation CardioWall Pro-X Elite The Pro-X Elite will usually arrive fully assembled. An area of suitable size will be required to position it (see System Specifications). Figure 3.4.1: Pro-X Elite When moving the Pro-X Elite, ensure there is enough manpower or suitable equipment. The Pro-X Elite is extremely heavy.
  • Page 14 To remove the CAT5 cable, you will require a flat blade screwdriver to release the clip. Remove the CAT5 cables CAREFULLY. Installing the Pods 3 x 7 mm bolts and penny washers Pro-X Elite – Section 3 - Installation © Rugged Interactive 2021...

  • Page 15: Section 4 - How To Use

    Section 4 - How to Use On power up, the CardioWall Pro-X Elite will sound a ‘laugh’ and will turn to its idle state. The monitor may be on standby after power up - the monitor indicator light will show as red. To switch on, tap the bottom right-hand side button on the monitor.
  • Page 16 RI logo. When this shows green, FitMakr Software is connected to a network. If the RI logo is red, the FitMakr Software is not connected to a network. Pro-X Elite – Section 4 - How to Use © Rugged Interactive 2021...
  • Page 17 Power - Shut down the User Interface. Configure - Assign the CardioWall a “device name”. Additionally, select the CardioWall device type. For the CardioWall Pro-X Elite, this must show “CardioWall Pro-X”. Restart - Restart the User Interface. Upgrade - Upgrade the CardioWall to the latest version. (Only available when connected to high-speed Internet: >10MB.)

  • Page 18: Section 5 - Programs Guide

    Program timeout: *whistle* NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. Pro-X Elite – Section 5 - Programs Guide © Rugged Interactive 2021...
  • Page 19 Program timeout: *whistle* NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. Pro-X Elite – Section 5 - Programs Guide © Rugged Interactive 2021...
  • Page 20 Program timeout: *whistle* NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. Pro-X Elite – Section 5 - Programs Guide © Rugged Interactive 2021...
  • Page 21 Level increases by 0.1 point for each pod hit e.g. L7.2 NOTE: At any time, if the CardioWall behaves unexpectedly, wait for the program to end and for the unit to reset to its idle state. Pro-X Elite – Section 5 - Programs Guide © Rugged Interactive 2021...
  • Page 22 +1 point for each pod hit NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. Pro-X Elite – Section 5 - Programs Guide © Rugged Interactive 2021...
  • Page 23 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk CardioWall Pro-X Elite System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight...
  • Page 24 Power Supply Specification for 5~9V) Features ‧  ‧  ‧  ‧  ‧  ‧  ‧  ‧   ‧  ‧  ‧ ℃ ‧ Ⅱ ‧  ‧  ‧  ‧   ...
  • Page 25 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
  • Page 26 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...
  • Page 27 Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk CardioWall Pro-X Elite Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. ☐ Stable and secure construction capable of supporting its weight and gameplay.
  • Page 28 * The volume control (a small blue control) can be found on the bottom left of the PCB, which is stored in the box at the back of the CardioWall Pro-X Elite. Rotate clockwise for volume up, counter-clockwise for volume down.
  • Page 29 If you would like any help, guidance or examples of using this product in your marketing campaign, please contact Rugged Interactive and we will be able to assist with this. Pro-X Elite – Next Steps ©...
