Pulsar 27000 Manual

650W LANTERN RANGE
SPECIFICATION
27000 - FRESNEL
27002 - FRESNEL
27100 - PEBBLE CONVEX BLACK
27102 - PEBBLE CONVEX WHITE
27050 - PROFILE ZOOM
27052 - PROFILE ZOOM
The PULSAR 650W Lantern Range gives the lighting designer
the ability to produce variable beam sizes and shapes with either a
hard or soft edge. Runners are provided to accept an optional
drop in Gobo Holder or Iris.
contains profiling stainless steel shutter blades, and these,
together with the zoom lens system provides the operator with full
control over the beam.
BACK PANEL CONNECTIONS
~
MAINS SUPPLY - 240VAC 650W Max., 50-60Hz nominal
Ensure that the lamp voltage suits the supply voltage.
The mains cable should be protected by a fuse with a maximum
rating of 10A.
The mains cable should be fitted with a suitably approved and
rated plug.
Note: in some countries it is a requirement that such a plug be
fitted by a qualified electrician.
We recommend the use of a Residual Current Circuit Breaker.
CABLE COLOURS
Green/Yellow =
Brown = Live / Phase / Hot
Blue = Neutral
WARNING - THIS APPLIANCE MUST BE EARTHED
A Steering Handle and a Safety Chain Fixing Point are provided
on the rear panel.
