MOLTO LUCE LOUM SENTAR T Mounting Instruction

SENTAR T
Montageanleitung /
Mounting Instruction
25°C
Ø 125
1 / 2
1
3-Stufen TOUCH dimmbar
3-steps TOUCH dimmable
3-steps TOUCH dimmerabile
Please read the instruction manual carefully before you use the product.
1. The lamp is delivered with empty accumulators. To get the full power of the accumulators, please charge it before the first use completely.
When charging, the indicator light at the top is green. When fully charged, it turns blue. The average charging time is about 7 hours.
The attenuation of lithium battery is not quality problem. To enlarge the lifetime of the accumulators, they should be recharged in regular
intervals. The lamp need to be charged every three months if the lamp is not used, otherwise the lithium battery will be wrong.
2. The lamp is made for outdoor use. Protection rating: IP44.
3. The best temperature for use is between 3 and 45 degrees centigrade. Lower or higher temperatures can shorten the lifetime of the
accumulators. The lamp should not be used under direct sunlight.
4. Please use the included adapter only to load the accumulators. Other adapters can cause damage to the lamp.
5. To correctly charge the lamp, we recommend that you:
- Remove the protective silicone cover and insert the charging cable;
- Put the plug into the electrical socket;
IP 44
- When fully charged, disconnect the plug from the electrical socket and remove the cable.
- Insert the protective silicone cover
6. To clean the lamp we recommend to use a soft cloth. If needed, the cloth can be humid with a little bit of water. Do not use alcohol or other
aggressive cleaning materials.
7. To start the lamp use the switch
1 x touch = 5% light power
2 x touch = 40% light power
3 x touch = 100% light power
4 x touch = off

8. Technical Data:

Power: 7.5W when the lamp is on charging.
Portable and rechargeable lamp.
2x 2200mA lithium battery.
3 different steps for brightness.
7 hours light on maximum brightness
Recharging time 7 hours, when the accumulators are complete empty.
Adapter included. Incoming power 200- 240V, 50- 60Hz , output 5V 2A.
118-SENTAR T V1.0 REV 00 15 | 04 | 2020
