Agnpro miniBox NXP100 Specifications

Networked Interactive Media Player
Networked Interactive Digital Signage Solution
Reliable, solid state units have a standard 10/100 Base-T network interface and can be connected to DHCP networks or
configured with static IP. Connects automatically to our optional online Central Management Server or can be controlled
from a network via HTTP or control command interface through Telnet/SSH. Built in drivers for touchscreens allow you to
create engaging interactive content without complex application development. Playback can also be controlled by sending
control strings through RS-232 or Ethernet.

Specifications

Model NXP100
Video Out VGA (640 X 480 @ 30fps)
Resolutions Composite (720 X 480 @30fps)
Audio Stereo Line Out (miniphone jack)
Processor IAN402 ARM based processor
ESS Digital Media Processor 2
(DMP2) Dual Processor
Architecture
Networking IEEE 802.3 Ethernet 10/100 Base-T
w/ Auto-MDIX
Interactivity
Supports interactive touchscreen
via RS-232
Video Bit Rate 3Mbps typical, equivalent to
45 mins per 1GB CF memory card
Storage Medium Removable Compact Flash Type I/II
memory card (not included)
Power Supply
5V DC, 2A
100-240V AC external on plug
Consumption: 4w
Dimensions
5.25" x 4.5" x 1"
133.5 x 113.5 x 25 mm
Weight 13.2 oz. Net
Operating
Operating:15 - 35°C, 20%-80%RH
Enviroments Maximum: 15 - 35°C, 5%-95%RH
Storage: -30 - 65°C
File Support
Video MPEG1
MPEG2 (MP@ML)
MEPG4 (ASP, Divx)
AVI, WMV
Audio MP3
Text Text scroll
Images JPEG
Flash SWF (with conversion software)
PowerPoint
PPT (with conversion software)
Device Details
Package Unit, Power Supply, VGA Cable,
Contents RS-232 Cable, Composite video
Cable, 1/8" mini cable, 1/8" mini-to-
RCA Cable
Warranty One-year limited warranty on parts
and labor
Out-of-the-Box Digital Signage...Just Plug It In and Deploy
™
NXP
4.5"
RS-232 and USB ports provides ability
to integrate with external devices and
systems
Our Online Central Management Server lets
you schedule and distributre media from
any location. Control any number of
units individually or in groups.
About AGNPRO
AGN Professional (AGNPRO) provides digital signage and
professional display solutions to specialty markets such as Pro AV,
Security Video Surveillance and Industrial Display Markets. Products
include the miniBox™ line of ultra compact digital signage media
players, oneBox HD™ dynamic messaging appliances and central
management & distribution software for digital signage networks.
"
5.25
Solid-state compact
flash storage
Interactive Features
• Built-in drivers for 3M & ELO touch, NEC Displays
• Genovation Keypads, ChyTV Plus
• Send Playback Control Commands through SSH/RS-232
Online Central Management (Optional)
Optional: The Online
Central Management Server
is accessible through any
browser connected to the
Internet.
Access network-equipped devices
• Plays MPEG-1/2/4 files in
the native format
• Plays most PC Media
Formats using transcoder
• DVD quality video output
• VGA and Composite outputs
• Update content and
schedule through Ethernet
10/100 Base-T
• Built-in web browser UI for
uploading content
miniBox™
through your LAN or WAN
AGN Professional (AGNPRO)
156 Fifth Avenue Suite 434
New York, NY 10010 USA
Tel: 1-212-647-9080
Fax: 1-212-647-9084
sales@agnpro.com
www.agnpro.com
