Agnpro miniBox NMP100 Specifications

Networked Media Player
Networked Digital Signage Solution
Reliable, solid state media players have a standard 10/100 Base-T network interface and can be connected to DHCP
networks or configured with static IP. Connects automatically to our optional online Central Management Server or can be
controlled from a network via HTTP or control command interface through Telnet/SSH.

Specifications

Model
NMP100
Video Out
VGA (640 X 480 @ 30fps)
Resolutions
S-Video (720 X 480 @ 30fps)
Composite (720 X 480 @30fps)
Audio Stereo Line Out (miniphone jack)
Processor IAN402 ARM based processor
ESS Digital Media Processor 2
(DMP2) Dual Processor
Architecture
Networking IEEE 802.3 Ethernet 10/100 Base-T
w/ Auto-MDIX
Video Bit Rate 3Mbps typical, equivalent to 45
mins per 1GB memory card
Storage Medium Removable Compact Flash Type I/II
memory card (not included)
Power Supply 5V DC, 2A
100-240V AC external on plug
Consumption: 4w
Dimensions 5.25" x 4.5" x 1"
133.5 x 113.5 x 25 mm
Weight
13.2 oz. Net
Operating Operating:15 - 35°C, 20%-80%RH
Enviroments Maximum: 15 - 35°C, 5%-95%RH
Storage: -30 - 65°C
File Support
Video MPEG1
MPEG2 (MP@ML)
MEPG4 (ASP, Divx)
AVI, WMV
Audio
MP3
Text Text scroll
Images JPEG
Flash SWF (with conversion software)
PowerPoint PPT (with conversion software)
Device Details
Package Unit, Power Supply, VGA Cable,
Contents S-Video Cable, Composite video
Cable, 1/8" mini cable, 1/8" mini-to-
RCA Cable
Warranty One-year limited warranty on parts
and labor
Out-of-the-Box Digital Signage...Just Plug It In and Deploy
™
NMP
4.5"
Flexability to control media
players through LAN, WAN, &
control command interface.
Our Online Central Management Server lets
you schedule and distribute media from
any location. Control any number of
units individually or in groups.
About AGNPRO
AGN Professional (AGNPRO) provides digital signage and
professional display solutions to specialty markets such as Pro AV,
Security Video Surveillance and Industrial Display Markets. Products
include the miniBox™ line of ultra compact digital signage media
players, oneBox HD™ dynamic messaging appliances and central
management & distribution software for digital signage networks.
5.25
Solid-state compact
flash storage
Package CoMulti-mode Playback Control
• Manual CF card update
Built-in web browser user interface
•
• Accepts control string commands via Telnet/SSH
Online Central Management (Optional)
Optional: The Online
Central Management Server
is accessible through any
browser connected to the
Internet.
Access network-equipped devices
• Plays MPEG-1/2/4 (DivX) files
• Plays most PC Media
Formats using transcoder
• DVD quality video output
• VGA, Composite & S-Video
• Update & schedule content
through 10/100 Base-T
Ethernet
• Built in web browser UI for
uploading content
Featurentents
™
miniBox™
through your LAN or WAN
AGN Professional (AGNPRO)
156 Fifth Avenue Suite 434
New York, NY 10010 USA
Tel: 1-212-647-9080
Fax: 1-212-647-9084
sales@agnpro.com
www.agnpro.com
