Fiber Optic Emergency Stop System
Instruction Manual
Revision C, Released 10-15-2015
The design concepts and engineering details embodied in this manual, which are the property of
MICRONOR INC., are to be maintained in strict confidence; no element or detail of this manual is to
be spuriously used, nor disclosed, without the express written permission of MICRONOR INC. All
rights are reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or
otherwise, without prior written permission from MICRONOR INC.
© Copyright 2013-2015, Micronor Inc., USA
MR380 Series
Doc No: 98-0380-01
Notice of Proprietary Rights
MICRONOR INC.
900 Calle Plano, Suite K
Camarillo, CA 93012
USA
Tel +1-805-389-6600
Fax +1-805-389-6605
sales@micronor.com
www.micronor.com
For Support in Europe:
MICRONOR AG
Pumpwerkstrasse 32
CH-8105 Regensdorf
Switzerland
Tel +41-44-843-4020
Fax +41-44-843-4039
sales@micronor.ch
www.micronor.ch
Advertisement
Table of Contents
Related Manuals for Micronor MR380 Series
Summary of Contents for Micronor MR380 Series
- Page 1 The design concepts and engineering details embodied in this manual, which are the property of MICRONOR INC., are to be maintained in strict confidence; no element or detail of this manual is to be spuriously used, nor disclosed, without the express written permission of MICRONOR INC. All rights are reserved.
- Page 2 MICRONOR automation components Revision History Revision Date Notes 12/11/2013 Initial release 7/13/2015 • Added 50/125 fiber pigtail option • Controller design upgraded to Universal and will work with both 50/125 and 62.5/125 multimode fiber 10/15/2015 Update with new Camarillo address and tel/fax...
-
Page 3: Table Of Contents
MICRONOR automation components Table of Contents 1. Product Description ..............5 1.1. Fiber Optic Emergency Stop Switch .................. 5 1.2. Fields of Application ......................6 1.3. Features ..........................6 2. Standard Contents ..............7 3. Installation and Operation ............8 3.1. - Page 4 MICRONOR automation components Table of Figures Figure 1. MR380 Series Fiber Optic Emergency Switch & MR380 Series Controller 5 Figure 2. Complete Functional System Overview ............6 Figure 3. Panel Cut Out Dimensions and Assembly Hierarchy of Emergency Switch 8 Figure 4.
-
Page 5: Product Description
1. Product Description 1.1. Fiber Optic Emergency Stop Switch Figure 1. MR380 Series Fiber Optic Emergency Switch & MR380 Series Controller The MR380-2 Emergency Stop Switch paired with MR380-1 series Controller provides a new, innovative emergency signaling detection that can be deployed in hazardous environments and over very long distances. -
Page 6: Fields Of Application
MICRONOR automation components 1.2. Fields of Application • Hazardous Environments: Oil & gas mining/extracting, refining • Medical: MRI environment • Energy Distribution: E-Switch maybe deployed next to high voltage lines Emergency Switch 24V Out MR380-1 Controller 5V Out Module Optional Switches in Series ‘POWER’... -
Page 7: Standard Contents
MICRONOR automation components 2. Standard Contents MR380-X ESTOP Sensor: • MR380-X-YY with multimode fiber size and pigtail length as ordered by customer, terminated with LC duplex connector. • 2-56 x 1/8 Pan Head Phillips Screws, Qty 2 • Instruction Manual (this document, one soft copy supplied with each shipment) MR380-1 Controller Module: •... -
Page 8: Installation And Operation
MICRONOR automation components 3. Installation and Operation 3.1. Mounting the Emergency Switch Mushroom Push Button Panel Lock Washer Mounting Nut Gasket 2-56 x 1/8 Panhead Philips Screws Figure 3. Panel Cut Out Dimensions and Assembly Hierarchy of Emergency Switch For mounting the sensor switch into a panel, please provide a cut-out as dimensionally shown in Figure 3 and Mechanical Reference Drawing. -
Page 9: Mounting The Controller Module
MICRONOR automation components 3.2. Mounting the Controller Module The controller unit mounts on DIN rails as well as a single mounting clip. Both mounting schemes are shown below in Figures 5 and 6. Figure 5. DIN Rail Mount Figure 6. Mounting Clip Mount... -
Page 10: Connecting The Controller
Figure 7. Front Panel Outputs of MR380-1 Series Controller The contact on the controller module uses a Phoenix Contact screw terminal. For more information, consult Controller specifications given in Section 6.2 . If connectors are lost or damaged, contact Micronor Sales for replacement details. Page 10 of 25... -
Page 11: System Start-Up & Performance Check
MICRONOR automation components 3.4. System Start-Up & Performance Check Connect +24VDC supply and ground to the designated terminals on the controller module. Verify that the ‘POWER’ LED (green) is illuminated. If the emergency switch is not connected, do so at this time and also verify that the ‘EMERGENCY ON’ LED (red) turns off as the switch is connected. -
Page 12: Troubleshooting
• Verify controller module power supply is +24VDC with a current output of at least 80mA. • Contact Micronor Sales for further assistance. 4.1.2. ‘Emergency ON’ illuminated w/Emergency Switch Connected • Check if emergency switch is ‘On’ when depressed. If so, reset switch and verify ‘Emergency ON’... -
Page 13: Relay Switching Failure
• Verify when switch is depressed, the controller will electro-mechanically switch the state of the relay resulting in a faint ‘click’ sound. • Contact Micronor Sales for further assistance. 4.1.6. Damaged Emergency Switch (Fiber) • Verify controller module outputs optical power by connecting LC loopback directly from one LC connector to the other, shown in Figure 10. -
Page 14: Damaged In Shipment
4.2. Damaged In Shipment In the event of a damaged instrument, write or call your nearest MICRONOR office in the U.S. A. Please retain the shipping container in case reshipment is required for any reason. If you receive a damaged instrument you should: Report the damage to your shipper immediately. -
Page 15: Warranty Information
5. Warranty Information Warranty MICRONOR INC. warrants this product to be free from defects in material and workmanship for a period of 1 (one) year from date of shipment. During the warranty period we will, at our option, either repair or replace any product that proves to be defective. -
Page 16: Specifications
Atmospheres and CE Marking, consult the following additional Micronor documents: • 93-0380-01, Declaration of Conformity - Summary. This document is the short form version of the Declaration of Conformity and is posted on the Micronor.com website. • 93-0380-02, Declaration of Conformity - Detailed Report. This Document is the long form version of the Declaration of Conformity with supporting detail and risk assessments in support of CE marking. - Page 17 MICRONOR automation components Optical Cabling: MR380-X-YY Description Specification Fiber Optic Interface LC Duplex Plug Fiber Optic Cable Where YY is pigtail length in meter MR380-2-YY Duplex 62.5/125µm OM-1 Multimode Fiber MR380-5-YY Duplex 50/125µm OM-2 Multimode Fiber Physical Specifications: MR380-X-YY Description...
-
Page 18: E-Stop Controller Module
MICRONOR automation components 6.2. E-STOP Controller Module Functional Specification: MR380-1-1 Description Specification Digital Outputs Voltage Output(5V): 5VDC/2k& Load Voltage Output(24V): 24VDC/2k& Load (Short Circuit Protected) Relay Contacts 2x Form C (CO) 60W/62.5VA Switching Power Rating Current Rating AgNi, Gold Covered Contact Material 75 V @ 0.75A;... - Page 19 MICRONOR automation components Environmental and Safety Specifications: MR380-1-1 Description Specification Temperature Range -5° to +55° C (23° F to +131° F) Humidity 0-90% RH (non-condensing) Ingress Protection IP50 per IEC 60529 Laser Safety Per IEC 60825-1 850nm, VCSEL Class 1 (Safe)
-
Page 20: Theory Of Operation
MICRONOR automation components 7. Theory of Operation A functional block diagram is shown in Figure 11, showing the Switch Sensor, Optical Link and Controller Module. The switch is connected by a duplex fiber optic cable of readily available 50/125µm or 62.5/125µm multi-mode fiber. The transmit fiber guides steady optical power from a near-IR light source to the optical switch. -
Page 21: Application Notes
MICRONOR automation components 8. Application Notes 8.1. Determining System Loss Budget For Chaining Multiple Switches The MR380-1 controllers have the capacity to chain multiple switches in series permitting that the additional losses fall within the system optical loss budget. Figure 12 illustrates a system using three MR380-2 switches in series. - Page 22 MICRONOR automation components System Component Loss(dB) Quantity Calculation(db) Loss(dB) Length of Fiber 3 dB/km 0.5 km x 2 The sum of Connections all losses Switches Total Loss The total system loss is 11dB, which is under the maximum 15dB system loss margin. Thus, the system should have no issues functioning under this configuration.
-
Page 23: Mechanical Reference Drawings
MICRONOR automation components 9. Mechanical Reference Drawings 9.1. MR380-1 Controller See following page for reference drawings for MR380-1 Controller. 9.2. MR382-2 Sensor See following page for reference drawings for MR380-2 Sensor. Page 23 of 25... - Page 24 THE INFORMATION CONTAINED IN THIS MATERIAL SIZE DWG. NO. DRAWING IS THE SOLE PROPERTY OF MR380-1 MICRONOR CORPORATION. ANY NOTES: UNLESS OTHERWISE SPECIFIED FINISH REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MICRONOR CORPORATION IS SCALE: 1:1 WEIGHT: SHEET 1 OF 1 PROHIBITED.
- Page 25 THE INFORMATION CONTAINED IN THIS MATERIAL SIZE DWG. NO. DRAWING IS THE SOLE PROPERTY OF MR380-2 MICRONOR CORPORATION. ANY NOTES: UNLESS OTHERWISE SPECIFIED FINISH REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MICRONOR CORPORATION IS SCALE: 1.5:1WEIGHT: SHEET 1 OF 1 PROHIBITED.
