350W
BENCH
DRILL
JEFPDB0350
IMPORTANT:
IMPORTANT!
FEATURES
Fitted with a heavy duty motor, capable of drilling into
wood, plastics, ceramics and many metals.
Small footprint area for workshop or portable
enough to take to the job.
Manufactured with a steel pillar, with rigid cast iron
head, table, and base to accurate holes.
Smooth and balanced performance
even at high speeds.
Predrilled base holes for mounting onto
a bench or work stand.
Slotted table allows for mounting clamps
and vises for effective work holding.
Fitted with a table height adjustment control
Supplied with a telescopic chuck guard and
a front mounted.
NVR switch for added convenience and safety.
Please read all of the safety and operatng instructons
carefully before using this product. Please pay particular
attention to all sections of these instructions that display
warning symbols and notices.
www.jeffersontools.com
JEFPDB0350
User Manual
SPECIFICATION
Drilling capacity
Motor power
Chuck capacity
Spindle Taper
Speeds (50Hz)
620~2620 RPM
Swing
Spindle travel
Column diameter
Table size
160 x 160mm
Throat depth
Height
v.1.1
Ø13mm
350W
1.5-13mm
B16
210mm
50mm
Ø46mm
105mm
580mm
Advertisement
Table of Contents
Related Manuals for Jefferson JEFPDB0350
Summary of Contents for Jefferson JEFPDB0350
-
Page 1: Features And Specification
JEFPDB0350 User Manual v.1.1 FEATURES SPECIFICATION 350W Fitted with a heavy duty motor, capable of drilling into Drilling capacity Ø13mm wood, plastics, ceramics and many metals. Motor power 350W BENCH Small footprint area for workshop or portable Chuck capacity 1.5-13mm enough to take to the job. -
Page 3: Table Of Contents
JEFPDB0350 User Manual v.1.1 CONTENT 1. Features and specification …………………………………………………………………………………………………………………………………… 2. Safety information …………………………………………………………………………………………………………………………………………… 3. Maintenance …………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………… 4. Parts identification ……………………………………………………………………………………………………………………………………………………… 5. Unpacking 6. Assembly ……………………………………………………………………………………………………………………………………………………… 7. Operation ……………………………………………………………………………………………………………………………………………………… 8. Exploded diagram …………………………………………………………………………………………………………………………………………… 9. Parts list ………………………………………………………………………………………………………………………………………………………… 10. Troubleshooting ………………………………………………………………………………………………………………………………………………... -
Page 4: Safety Information
JEFPDB0350 User Manual v.1.1 1. SAFETY GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE When using any type of power tool there are steps that should be taken to make sure that you, as the user, remain safe. Common sense and a respect for the tool will help reduce the risk of injury. - Page 5 JEFPDB0350 User Manual v.1.1 SPECIFIC SAFETY INSTRUCT/ON FOR BENCH DRILLS MECHANICAL HAZARDS: 1.21 Crushing When setting/changing a tool or maintaining the machine avoid crushing injuries sustained between fixed and moving elements of the machine. 1.22 Cutting or Severing At all times the workpiece shall be clamped as manual support will lead to injury.
-
Page 6: Maintenance
JEFPDB0350 User Manual v.1.1 2. MAINTENANCE Read this manual carefully.Learn the machine applications and limitations,as well as the specific potential hazards peculiar to it. 2. 2 ALWAYS keep guards in place and in working order. A guard or other part that is damaged should be properly repaired or replaced by an authorized serv ice centre, unless otherwise indicated in this instruction manual. -
Page 7: Parts Identification
JEFPDB0350 User Manual v.1.1 3. PARTS IDENTIFICATION 1 Pulley cover 11 Base 2 Motor 12 Main housing 3 Switch 13 Column 4 Chuck guard 14 Bolts 5 Chuck 15 Depth stop lock knob 6 Feed handle 16 Table lock 7 Table... -
Page 8: Unpacking
Carefully remove the drill from the packaging and examine it for any sign of damage that may have happened during shipping. Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Jefferson Helpline (the telephone number appears on the Title page) and do not attempt to use the lathe. - Page 9 JEFPDB0350 User Manual v.1.1 6. ASSEMBLY RACK & TABLE (Continued) 3. Slide the rack all the way down until it locates into the lower column support(Fig. 8). Slide the collar, tapered side facing down, over the column until it locates the rack.
- Page 10 JEFPDB0350 User Manual v.1.1 7. ASSEMBLY CHUCK & ARBOR Fig.17 Fig.18 Fig.19 1. Before any assembly, ensure the 2. Tighten Philip’s head screws 3. Fit the tapered arbor end into the chuck by chuck jaws are wound all the way up of the chuck guard to quill shaft hand, using reasonable fore (Fig.
- Page 11 JEFPDB0350 User Manual v.1.1 8. ASSEMBLY INSTALLING STRAIGHT SHANK DRILL BITS Fig.26 Fig.27 Fig.28 1. Using the chuck key, loosen the 2. Insert the drill bit into the chuck 3. Whilst holding the drill bit in one hand rotate jaws of the chuck by rotating in an (Fig.27)
- Page 12 JEFPDB0350 User Manual v.1.1 9. ASSEMBLY FLOOR TYPE Fig.33 Fig.34 Fig.35 To stop spindle (and bit) at a desired depth: 1. Loosen depth stop lock knob by turning in an anti-clockwise direction (Fig. 33). 2. Rotate depth scale to the desired depth, then tighten half wing bolt (Fig. 34).
-
Page 13: Operation
JEFPDB0350 User Manual v.1.1 10. OPERATION TURNING ON AND OFF Note: The pulley cover must be closed to operate the drill press. 1. Switch the drill press On by pressing the green(I)button on the switch (Fig.42-43). 2. Switch the drill press Off by pressing the red(O)button on the sw itch. -
Page 14: Exploded Diagram
JEFPDB0350 User Manual v.1.1 11. EXPLODED DIAGRAM OF BENCH PRESS www.jeffersontools.com... -
Page 15: Parts List
JEFPDB0350 User Manual v.1.1 11. PARTS LISTING FOR BENCH PRESS BASE SPRING WASHER COLUMN FLANGE FLAT WASHER MICRO SWITCH PRESSING CLAW SPRING WASHER HEX. SOC SET SCREW OUTSIDE HEX. BOLT MOTOR PULLEY OUTSIDE HEX. BOLT CIRCLIP FOR HOLE SPRING WASHER... -
Page 16: Troubleshooting
JEFPDB0350 User Manual v.1.1 TROUBLE SHOOTING For your safety always turn the main switch on the machine “off” and remove the plug from the power supply before carrying out any maintence or trouble shooting. WARNING: PROBLEM PROBABLE CAUSE REMEDY Machine will not start. -
Page 17: Declaration Of Conformity
JEFPDB0350 User Manual v.1.1 EC Declaration of Conformity We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer, declare that the following equipment conforms to the requirements of the following Directives: Directive: Description: 2014/30/EU (as amended) -
Page 18: Warranty Statement
1 Year together with details of your nearest authorised Jefferson repair centre. On receipt • Jefferson 350W Bench Drill [JEFPDB0350]. of this form Jefferson will arrange to collect the equipment from you at the earliest convenience. 90 Days • All replacement parts purchased outside of the warranty period... - Page 19 JEFPDB0350 User Manual v.1.1 NOTES www.jeffersontools.com...
- Page 20 JEFPDB0350 User Manual v.1.1 350W BENCH DRILL JEFPDB0350 www.jeffersontools.com...
