- Page 1 JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL JEFMAGDPER35-230 JEFMAGDPER35-110 User Manual v.1.1 www.jeffersontools.com...
- Page 2 JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL www.jeffersontools.com...
-
Page 3: Table Of Contents
All photographs and drawings in this manual are supplied by Jefferson Tools to help illustrate the operation of the product. Whilst every effort has been made to ensure accuracy of information contained in this manual our policy of continuous improvement determines the right to make modifications without prior warning. -
Page 4: Introduction
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL 1. Introduction This magnetic drill is designed for drilling holes in steel fabrication work. It is an ideal portable drilling solution equally suited for use in building sites or the workshop environment and can be used to cut in horizontal, vertical and overhead positions. -
Page 5: Safety Guidelines
Wear protective hair covering to prevent long hair time. getting caught up in the tool. Contact your nearest Jefferson Dealer for advice on Ensure that suitable safety equipment is worn correct usage, accessories (including compatible during use these include: detergents), servicing and replacement parts. -
Page 6: Specifications
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL 3. Specifications Model Number: JEFMAGDPER35-110 JEFMAGDPER35-230 Maximum Core Drill Diameter: 35mm Maximum Cutting Depth: 35mm Input Voltage / Frequency: 110V 230V Magnetic Adhesion: 16000N Motor Power / Speed: 1600W No Load Speed: 700rpm... -
Page 7: Cleaning & Maintenance
We recommend that you periodically check the brushes for wear and tear and replace them when they reach 6mm. Keep moving parts lubricated. Maintenance, checks and repairs should only be made by qualified electricians or a Jefferson approved technician. We recommend that the machine should be serviced after approximately 250 hours running time. -
Page 8: Parts Diagram - Frame & Magnet Components
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL PARTS DIAGRAM - Frame & Magnet Components www.jeffersontools.com... -
Page 9: Parts List - Frame & Magnet Components
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL PARTS LIST - Frame & Magnet Components Description Description Left Rail Track Gear Shaft For Armature Bar17*230" 40 Pressure Bar 230 Key 9*3 Right Rail Track Bar Gear For Armature 17*230 Slide Bar 1.5*11*230... -
Page 10: Parts Diagram - Motor Components
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL PARTS DIAGRAM - Motor Components www.jeffersontools.com... -
Page 11: Parts List - Motor Components
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL PARTS LIST - Motor Components Description Description Circlip, Inner 19 Gear Shaft For Armature Gasket 9*19*2 Key 9*3 Plastic Gasket Gear For Armature Key For Spring Bearing 608 10.3*12 Spring 120 Oil Seal Ø 10*16*4 Circlip, Inner 33 O Ring Ø... -
Page 12: Limited Warranty Statement
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty periods below. All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is unavailable from the end user, then the date of purchase will be deemed to be 3 months after the initial sale to the distributor. - Page 13 Step 3 - Assessment and Repair On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if the equipment is defective and in need of repair and any repairs needed are covered by the warranty policy. In order to qualify for warranty cover all equipment presented must have been used, serviced and maintained as instructed in the user manual.
-
Page 14: Ec Declaration Of Conformity
Stephen McIntyre Position in the company: Operations Director Date: 14 August 2018 Name and address of Jefferson Tools, Herons Way, Chester Business Park, Chester, United manufacturer or authorised Kingdom, CH4 9QR Telephone: +44 (0)1244 646 048 representative: Fax: +44 (0)1244 241 191 Email: enquiries@jeffersontools.com... -
Page 15: Environmental Protection
JEFMAGDPER35-230 • JEFMAGDPER35-110 PERMANENT MAGNETIC CORE DRILL ENVIRONMENTAL PROTECTION Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. -
Page 16: Www.jeffersontools.com
Before attempting to use this product please read all the safety precautions and operating instructions outlined in this manual to reduce the risk of fire, electric shock or personal injury. Jefferson Tools, Herons Way, Chester Business Park, Chester, United Kingdom, CH4 9QR Tel.
