- Page 1 ASSEMBLY INSTRUCTIONS ADRIA 6 SEAT CUBE SET SKU: TOMO190-123 / TOMO190-124 2021 V1.0 IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Long Leg Short Leg Table Top Frame Glass Central Bar Parasol Ring M6 x 20mm Screw M6 x 35mm Screw Washer Allen Key Suction Ring... -
Page 3: Safety Advice
• Please only use this product for its intended purpose as outdoor furniture within a residential environment. Failure to do so will void your warranty. • Westminster Outdoor Living holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, misuse and/or negligence •... - Page 4 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 Loosely secure the 2 x long legs (A) onto the table top (C) using 8 x M6 x 20mm (F), 8 x washers (G) using the allen key (I). Apply pressure on the frames to ensure all screws align if needed.
- Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 2 Loosely secure the 2 x short leg (B) onto the table top (C) using 4 x M6 x 20mm (F), 4 x washers (G) using the allen key (I). Apply pressure on the frames to ensure all screws align if needed.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 3 Position short leg (B) to the centre of long leg (A) by securing together both legs using 4 x M6 x 35mm (G), 4 x washers (H). using the allen key (I).
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 4 Position the central bar (D) between both short legs (B). Loosely secure using 4 x M6 x 20mm (F), 4 x washers (H) using the allen key (I). IT’S TIME Tighten all the screws using the provided allen key (I)
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 5 Turn over the table top, add the suctions cups (J) onto the table top (C).
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 6 Position the glass (C1) onto the table top (C). Ensure the suctions cups are flat. Position the parasol ring (E) into the centre of the glass (C1). If you are not using a parasol, cover the parasol ring with the cap.
- Page 10 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 7 Slide all the chairs and footstools (In seperate boxes) into the table frame. TOP TIP We recommend the cushions are stored inside,when not in use.
-
Page 11: Warranty Information
ASSEMBLY INSTRUCTIONS CARE, MAINTENANCE & WARRANTY INFORMATION Our range of aluminium furniture is designed for continual outdoor use. The aluminium frame ensures that you can leave it outside all year round. ALUMINIUM CARE The aluminium framework is incredibly low maintenance and is resistant to UV rays, salt water, frost and snow and requires only basic care to keep it clean.
