- Page 1 VERTEX Water Products PureWaterMachine ™ REVERSE OSMOSIS UNDERSINK WATER FILTRATION SYSTEM OWNERS INSTALLATION MANUAL Model 3C VERTEX WATER PRODUCTS...
- Page 2 The VERTEX PURE WATER MACHINE is made with quality components to provide clean, safe drinking water. No chemicals are added or used in this system. To preserve the filter capability, it is a must that the filter replacement be made at the intervals and with replacement ele- ments as specified in section 4.0 of this manual.
-
Page 3: Table Of Contents
Table of Contents Notice ..........pg. 1 Parts List . -
Page 4: Notice
NOTICE This instruction manual was written to guide a professional plumber to make an easy installation of the VERTEX Pure Water Machine. The installation shall conform to local plumbing codes. It is imperitive to install a pressure regulator in front of the unit or at water point of entry to prevent this system from experiencing pressure spikes above 90 psig. -
Page 5: Introduction
Dissolved solids are not removed by municipal water treatment. That is why the Vertex Pure Water Machine is an important safety factor for the water you drink and use in your cooking. Chemical contaminants such as mercury, lead, nitrates, pesticides and others not yet identified which seep into municipal water systems are removed. -
Page 6: Installation
2.0 INSTALLATION Before starting the installation, you should measure the water pressure that is avail- able under the sink to power the Pure Water machine RO. If the pressure is less than 40- PSIG, it is too low; and if it is 90-PSIG, it may be too high. The solution if the pressure is too low is to use a model with a booster pump. -
Page 7: Membrane Stage
Figure 1 3/8” Existing Water Supply 1/4” 3/8” To Clean Water Tank CHECKVALVE ASSEMBLY RO SYSTEM TOP VIEW FLOW RESTRICTER INSIDE DRAIN TUBE – 3 –... -
Page 8: Connecting The Feed Water Supply
2.3 RO Stage Note that the RO housing on the bracket in Figure 1 (horizontal element on top of the bracket) already contains a pre-installed 75 GPD (gallon per day) membrane. There is no need to install the membrane, and when it is time to replace the membrane, the whole element including the housing is discarded. -
Page 9: Installation Of Drain Connection
2.5 Installation of drain connection (Fig. 4) Place the drain outlet saddle on the drain pipe. Allow proper space for the drilling operation. Tighten the saddle bolts evenly on both sides. Using the opening in the drain outlet saddle as a guide, drill a 1/4” hole in the drain pipe. Clean any debris out of the drain saddle connection. -
Page 10: Porcelain/Enamel Over Steel Or Cast Iron Sinks
The sink drilling process is not Step 3. complicated, but requires a cer- Finish Hole Saw tain amount of caution and fore- thought. Porcelain sinks can be chipped if care is not exercised when drilling the hole for the faucet. [NOTE: This procedure is for the non air gap faucet provided.] 2.7 Porcelain/Enamel over Steel or Cast Iron Sinks Using a small diameter carbide tipped drill, drill a pilot hole completely through... -
Page 11: Tubing Connections
2.9 Tubing Connections The model 3C-4.0 has the quick-connect “push-in” fittings. These fittings have a collet to grip the tube and an “o” ring to provide the seal to the tubing. The col- let has steel teeth in it to grasp the tubing to prevent it from backing out. Making a connection. -
Page 12: Air Gap Faucet Installation
Figure 9 Escutcheon Plate Escutcheon Plate Small Rubber Washer Small Rubber Washer Black Rubber Washer Black Rubber Washer Counter Top Counter Top Black Locating Washer Black Locating Washer Lock Washer Lock Washer 3/8 drain line from Airgap 3/8 drain line from Airgap to drainsaddle (Blue) to drainsaddle (Blue) Push-in Fitting, 7/16"... -
Page 13: System Start Up
3.0 System Start Up 3.1 Start-Up Start the system by opening the feed water ball valve. Make sure the ball valve on the storage tank is in the closed position. Check for leaks for at least 10 minutes. If water leaks from a fitting, retighten the fitting nut. -
Page 14: Standard Filter Elements
At year 4 (or sooner if you have severe water problems),we recommend that the Stage 3 reverse osmosis assembly be changed also. When you order your fourth year kit from your Vertex dealer, this will be included, along with the other three elements. Kit part number is FK-102/75 4.2 Standard Filter Elements... -
Page 15: Installation Troubleshooting
Turbidity, less than 1.0 NTU. Max iron content, 0.3 ppm 8.0 Product Warranty The VERTEX Pure Water Machine components, specifically the bracket, the filter housings, the filter elements, tank and valves are warranted to be free of defects. Any defect arising in these items within one year from date of purchase will be replaced at no cost. -
Page 16: Other Models
9.0 Other Models 9.1 Pure Water Machine with booster pump; Configuration and operation Model 3C 4.0/P The 4 stage RO system with pump is used when the city water pressure is below 40 psi. The booster pump allows the RO system to run at peak efficiency by provid- ing a pressure of about 80 psi to the RO membrane. -
Page 17: Appendix A: Theory Of Operation
Appendix A: Theory of Operation Figure A-1: Flow Schematic PURE WATER FAUCET POST FILTER CLEAN WATER AUTO VALVE RO MEMBRANE CHECK VALVE DISCARDED WATER ORIFICE FLOW CONTROL CLEAN WATER TANK BLADDER AIR VALVE FEED WATER AIR PRESSURE CARBON SEDIMENT BLOCK FILTER FILTER A.1 Pre-Filters:... - Page 18 A.2 The Reverse Osmosis Membrane: This is the heart of the Machine, and is the great protector. The membrane is a replica- tion of human or animal stomach tissue, which permits the water molecule to pass through, and holds dissolved molecules back. This is done naturally by osmotic pressure developed because of the content of dissolved solids.
- Page 19 Notes Water Disinfection with chlorine bleach (5.25%) Clean Water Quantity Cloudy Water 2 drops 1 quart 4 drops 1 gallon 8 drops 16 drops 5 gallons 1/2 tsp. 1 tsp.
- Page 20 VERTEX WATER PRODUCTS, Montclair, Calif. M-2 Rev B • 10/02 Copyright 2002 VERTEX Industrials, Inc.
