- Page 1 Smart Lock User Manual Model: S31A...
-
Page 3: Table Of Contents
Table of Contents In the Box Product Specifications Features Preparing the Lock Installation Instructions Programming Your Lock Setting Your Passcode Adding IC Card Lock Records Remote WiFi Management Manual Key Troubleshooting... -
Page 4: In The Box
In the Box 1.) Front Panel (1) 2.) Back Panel (1) 3.) Mortise Lock (1) 4.) IC Card (1) 5.) Manual Key (2) 6.) Waterproof Rubber Gasket (2) 7.) U-Clip (1) 10.) Spindle for Door 8.) Strike (1) 9.) Dust Box (1) Thickness 35mm-55mm (1 3/8’’-2 1/8’’) (1) - Page 5 12.) Screw Casing: 13.) Sliding Screws: 11.) Spindle for Door 35x8mm (2) 16x5mm (2) Thickness 50mm-75mm (2 3/8’’- 3’’) (1) 14.) Mortise Screws: 15.) Mortise Screws: 16.) M5x30mm 10x5mm (For Aluminum 25x4mm (For Wooden for door thickness Door) (4) Door) (4) 35mm-55mm (1 3/8’’-2 1/8’’) for upper (1)
-
Page 6: Product Specifications
Product Specifications Model Materials 304 Stainless Steel & Zinc Alloy Front Panel Lock Size 280x38x25mm (11x1 1/2x1’’) Back Panel Lock Size 280x38x25mm (11x1 1/2x1’’) Lock Weight 2.5KG (5.5 lbs) Unlocking Methods Bluetooth Fingerprint (S31B) Password Card Manual Key WiFi Remote Finish Satin Stainless Steel Satin Black... - Page 7 1. Trim Details 2. Mortise Lock Options *For narrow style metal frame backset available for 28mm, 30mm and 35mm. Minimum style required 46mm for 28mm & 35mm...
-
Page 8: Features
Manual key can be used to lock and unlock the door • Auto locking time setting option: After successfully unlocking, the Port Smart Lock will re-lock after a period of time (between 5 to 120 seconds). The owner sets this function •... -
Page 9: Preparing The Lock
Preparing the Lock Adjust the levers to match the swing hand of the door Exterior Panel 1. Turn the handle on 2. Remove the handle 3. After adjusting the the front panel. direction of the handle, insert it into the handle Loosen the inner seat and re-lock the hexagon screw of the... -
Page 10: Installation Instructions
Installation Instructions Install Mortise 1. Use the template enclosed to cut holes for the door. ٭It is important to follow the template 2. Install the mortise lock (Part #3) using the 25x4mm (Parts #15) for wood doors and 10x5mm (Parts #14) for aluminium doors 3. - Page 11 Installing Sliding Screw Casing 1. Install the 35x8mm screw casing (Parts #12) *The screw casing location is adjustable and can be fixed anywhere between 55mm to 100mm from the spindle 2. Depending on the location of where the hole was drilled set the screw casing, then tighten Connecting Interior &...
- Page 12 Installing the Batteries 1. Install (4) new AAA batteries into the battery chamber 2. Put the battery cover back...
-
Page 13: Programming Your Lock
Programming Your Lock 1.) Search for TTLock in the App Store or Google Play to download Register Login Register Phone Email Country/Region American Samoa+1684 Enter your Phone number Password between 6-20 characters Phone number/Email Confirm Password Password Verification Code Get Code Login Register Forgot Password? - Page 14 Door Lock Padlock Lock Safe Lock Cylinder Press to Add Lock Bicycle Parking Lock Lock Remote Control The phone must be within 6 feet of the Smart Lock during the Pairing process Add Lock Nearby Locks BL01_63230b Lock Name S202C_f4324e S31A...
-
Page 15: Setting Your Passcode
Passcodes can be generated for: permanent, limited time, single use and custom schedule. TTLock Generate Passcode Generate Passcode anent Timed One-Time Erase Custom Custom S31A anent Timed One-Time Erase Recurri Permanent 4-9 Digits in length Permanent 2020-03-06 09:00 Start Time... - Page 16 Passcode Types Passcode Type Description Type Permanent General use passcode Time-Limited Passcode with set time frame Single Use Single-use short term password Custom Schedule Set your own passcode and time frame Passcode Management All generated passwords can be viewed and managed in the password management module.
- Page 17 *The owner can send keys, passwords, etc. to others; however the authorized administrator can not authorize others. Only the main administrator. TTLock Send eKey Timed Permanent One-Time Recurring S31A Enter Recipient’s Account Recipient Please enter a name for this eKey Name Allow Remote Unlocking Touch to Unlock. Long Press to Lock...
-
Page 18: Adding Ic Card
◊ Expiration Reminders are shown in Adding IC Cards The S31A supports opening doors through various IC cards. Before an IC Card is used to open the door, it needs to be added first. The adding process needs to be performed by the app. The validity period of the IC can be set, it can be permanent, or it can be limited in time. - Page 19 Add IC Card Add IC Card Name Permanent Start Time 2020-03-06 10:18 End Time 2020-03-06 10:19 Next Connecting with lock. Please wait... b) Add card remotely (You must add gateway first!) TTLock IC Cards Clear IC Cards Add card remotely Add IC Card Name Please enter a name...
-
Page 20: Lock Records
Add card remotely Add card remotely Please place the Card near your phone Please place the Card near your phone Card Card Card Number Card Number:1777986718 Next Next Lock Records Click “ ” as shown below. With “Lock Records” you can view: eKeys, save passcodes and unlock history. -
Page 21: Remote Wifi Management
Records Refresh Records Search 2019-07-12 18050066613 11:28:56 unlock with app success Remote Wifi Management Adding a Gateway... - Page 22 TTLock is directly connected via Bluetooth and is not connected to the network itself, which is why it is not vulnerable to network attacks. The gateway is an accessory of the smart lock, it is th bridge connecting the smart lock and the home wifi nework.
-
Page 23: Troubleshooting
Troubleshooting Programming Troubleshooting 1) How do I read the operation In the “Records” of the main interface records? or on the TTLock website 2) What is the maximum limit of There is no limit e-Keys? 3) Why does it show “pending” when I Before the receiver opens the app to send e-Keys to other people? receive, the status shows pending... - Page 24 Hardware Troubleshooting 1) After installation, touch sensing a) In this case, first check that the keypad is not responding positive and negatve electrodes of the battery have been installed upside down and whether the battery has enough power b) Remove the back panel and see if it’s connected c) To eliminate the above situation, you need to remove the lock, check...
- Page 25 Device Reset Open the battery cover plate on the interior panel. Press the “Reset” but- ton for 5 seconds, then enter “000#”. A prompt will appear once it’s reset successfully.
- Page 26 1 (800) 219-2366 authority@portsmartlock.com www.portsmartlock.com...
