Ross MC1-MK Quick Start Manual

This QuickStart Guide provides a brief summary of the components in your MC1-MK System, and a list of related
openGear documentation that will help you install, configure, and operate your system.

System Integration

Figure 1 provides an example of one way to integrate your MC1-MK. Please note that this is only an example and your
facility needs may differ from what is presented here.
