Christie СС2 Installation And User Manual

Gas barbecue cooktop
Hide thumbs Also See for СС2:

Advertisement

Quick Links

Download this manual
CC2 Gas Barbecue Cooktop
Part numbers 1204,
1205 and 1206
+61 3 9708 2999
dachristie.com
Installation and User Manual
This manual is an integral part of the appliance and
must be kept in its entirety in an easily accessible
location. Read these instructions carefully before
installing and using the appliance.
Installation Manual 6837_00

Advertisement

loading
Need help?

Need help?

Do you have a question about the СС2 and is the answer not in the manual?

Questions and answers

Related Manuals for Christie СС2

Summary of Contents for Christie СС2

  • Page 1 CC2 Gas Barbecue Cooktop Installation and User Manual Part numbers 1204, This manual is an integral part of the appliance and 1205 and 1206 must be kept in its entirety in an easily accessible location. Read these instructions carefully before installing and using the appliance.

  • Page 2: Table Of Contents

    2 | Table of contents GENERAL INFORMATION Product diagram | Figure 1, 2 Safety instructions How to read this manual Manufacturer liability Conditions of use Declaration of conformity Specifications | Table 1, Figure 3 Description Disposal 1.10 Boxed contents | Figure 5 INSTALLATION Design guidelines for installing a CC2 cooktop |...

  • Page 3: General Information

    General information | Installation Manual 6837_00...

  • Page 4: Product Diagram | Figure

    | General information 56 mm projection Start/Stop button above benchtop 1.1 Product diagram with LED indicator FIG 1 56 mm projection Start/Stop button above benchtop with LED indicator 459 mm bolt hold down point centres M8 x 100 mm long mount bolts 2 places 495 mm minimum benchtop cutout width 459 mm bolt hold down point centres...

  • Page 5: Safety Instructions

    The appliance must be fixed into an enclosed structure to prevent access to its underside • Where the underside is not fully enclosed, you must use a Christie Open Bench Installation Kit to avoid potential injury refer to FIG 8 on page 16 •...

  • Page 6: How To Read This Manual

    | General information 1.2 Safety instructions Risk of damage to the Appliance • Do not charge the battery while it is connected to the appliance, as this will damage the circuit board • Do not use a power supply below 12 VDC, as this may damage the appliance •...

  • Page 7: Manufacturer Liability

    General information | 1.4 Manufacturer liability The manufacturer declines all liability for damage to persons or property caused by: • Use of non-original spare parts • Use of the appliance other than as intended • Tampering with any part of the appliance •...

  • Page 8: Declaration Of Conformity

    • Do not modify any part of the appliance without written authorisation from the manufacturer • The manufacturer must approve all repairs conducted under warranty. Christie will not take responsibility for any repairs made without prior authorisation • This appliance is suitable for indoor and outdoor use •...
  • Page 9 General information | 1.7 Specifications TABLE 1 Gas Type Natural ULPG Nominal consumption 16.0MJ/h 15.8MJ/h 12.8MJ/h Injector size 1.1 mm 1.8 mm 0.95 mm Min supply pressure 2.75kpa 1.13kpa 2.75kpa Max supply pressure 3.5kpa 3.5kpa 3.5kpa Operating pressure 2.60kpa 0.84kpa 2.60kpa Gas inlet connection 3/8”...
  • Page 10 10 | General information 1.7 Specifications FIG 3 Wiring diagram CC2 Gas Barbecue Cooktop (Part numbers 1204, 1205 and 1206)

  • Page 11: Description

    General information | 1.8 Description • The Christie CC2 Gas Barbecue Cooktop is a self-contained hotplate-style cooking appliance with fully automatic functions, designed for public use • The CC2 gas appliance is capable of using three fuel gas options: Liquefied Petroleum Gas (LPG - Propane). Part number 1204 Natural Gas.

  • Page 12: Boxed Contents | Figure

    Anti-rotation brackets Installation & User Manual Installation & User Manual Christie CC2 Gas Barbecue Cooktops are supplied with the following boxed contents: CC2 Gas appliance with the following variation by gas type: Liquefied Petroleum Gas - LPG/Propane. (Part number 1204) Natural Gas.

  • Page 13: Installation

    Installation | Installation Manual 6837_00...

  • Page 14: Design Guidelines For Installing A Cc2 Cooktop | Figure

    Christie provides pre-manufactured barbecue cabinets to suit most projects and environments. We also offer options for built-in structures Note: For installing the cooktop into a prefabricated Christie barbecue cabinet, please refer to instructions for installing a CC2 cooktop on page TBC.
  • Page 15 Installation | 2.1 Design guidelines for installing a CC2 Cooktop Allow at least 130mm of clear bench space around the cut-out. FIG. 6 130 mm 495 mm x 495 mm 130 mm cut-out 1200 mm Minimum clearance FIG. 7 above cooking surface. Both CC2 electric and CC2 gas cooktops extend 160 mm downwards...
  • Page 16 The cooktop must be fixed into an enclosed cabinet or structure to prevent access to its underside. Where the underside is not fully enclosed, you must use a Christie Open Bench Installation Kit or similar enclosure to avoid possible injury.

  • Page 17: Preinstallation

    Ventilation • Louvres in the Christie access door and perforations in the gas cooktop provide ventilation. The space under the hotplate lip provides exhaust ventilation. This ventilation gives essential airflow for the gas to burn correctly, and to limit heat build-up inside the unit •...
  • Page 18 240 VAC to 12 VDC plug-in transformer (Standard) • All Christie CC2 Gas Cooktops require power for ignition and to operate correctly. Provide a 10 A 3-pin weatherproof power outlet in a convenient location inside the barbecue cabinet for each appliance. The appliance connects to the power outlet through the 240 VAC to 12...
  • Page 19 2.3 Installation STEP 1 Review section 1.10 Boxed contents, and check that all listed parts are present. Contact Christie immediately if there any discrepancies. Open the box and remove cardboard packers to reveal the underside of the appliance. FIG. 9...
  • Page 20 20 | Installation 2.3 Installation STEP 2 Remove the wing nuts and washers on the 8mm hold down brackets then remove the anti- rotation brackets. Using a Phillips head screwdriver, remove the 2 x M5 screws and remove the gas valve cover. Note: The information on the Appliance Data Plate will be required to commission the appliance.
  • Page 21 Installation | 2.3 Installation STEP 3 Insert the washer over the 8 mm bolt. Insert the bolt through the round hole in the anti- rotation bracket and into the hole on the benchtop. Secure the 8 mm nut with two 13 mm spanners, using one to turn the nut and the other to prevent the bolt from turning.
  • Page 22 22 | Installation 2.3 Installation STEP 4 Remove the gas hose from the envelope and attach it to the gas inlet fitting. Screw the hose on by hand, then tighten the nut with an adjustable spanner to create a gas-tight seal. FIG.
  • Page 23 Installation | 2.3 Installation STEP 5 Using two people, lift the appliance out of the container and turn over, so that the cooking surface faces upwards, over the cut out in the bench. Drop the power cord and gas hose into the cut-out hole then lower the appliance, ensuring that the bayonet fitting is not contaminated.
  • Page 24 24 | Installation 2.3 Installation STEP 6 Ensure the appliance aligns with the edges of the benchtop. Tighten the wing nuts so that the appliance does not move at all. STEP 7 • Connect the floor socket to the gas supply as per AS/NZS5601 or local regulations and connect the bayonet to the floor socket.
  • Page 25 Installation | 2.3 Installation STEP 8 Commissioning • To access the pressure adjusting screw in the gas valve, locate the gas valve and then remove the brass screw cap with a large flat-bladed screwdriver • Loosen the test point screw on the injector with a small flat-blade screwdriver and attach a digital manometer to the test point •...
  • Page 26 | Installation 2.3 Installation STEP 8 (continued) • Press the START/STOP button for 6 seconds to turn the appliance on and note the gas pressure. Adjust the pressure upwards by turning the adjustment screw clockwise, or adjust the pressure downwards by turning the adjustment screw counter-clockwise. Turn the appliance off by pressing the START/STOP button for 3 seconds •...

  • Page 27: Operation

    Operation | Installation Manual 6837_00...
  • Page 28 28 | Operation The CC2 Cooktop functions automatically without further operator input after the initial start. To commence operation, press and hold the START/STOP button for at least 6 seconds The appliance will enter a preheat/sterilisation mode, indicated by an audible beep and a red flashing START/STOP button.

  • Page 29: Cleaning And Maintenance

    Cleaning and maintenance | Installation Manual 6837_00...

  • Page 30: Safety Considerations

    Rinse the hotplate with water or wipe with a clean cloth or paper towel Note: If using the Christie pH neutral or other enzyme-based cleaners, no heat is required. Skip steps 2 and 3.

  • Page 31: Cleaning Waste Containers | Figure

    Cleaning and maintenance | 4.4 Cleaning waste containers Waste containers must be emptied on a regular basis. Do not allow the waste container to overflow into the interior of the barbecue cabinet. All fat, grease and oil should be disposed of in accordance with local regulations. Do not dispose of it on the ground, as this will create a health hazard.
  • Page 32 Clean and wash the grease trap with a mild detergent or pH-neutral, biodegradable degreaser, before replacing it inside barbecue surround. A high-pressure cleaner or steam cleaner may also be used. Extra grease traps can be ordered from Christie, to exchange and clean grease traps thoroughly off site...

  • Page 33: General Cleaning And Maintenance

    Cleaning and maintenance | 4.5 General cleaning and maintenance To ensure the lasting safety, reliability, and energy efficiency of your Christie barbecue, we recommend that it be serviced and inspected at least every 12 months. The Servicing Procedure is detailed in our Technical Service Manual, available upon request from Christie.

  • Page 34: Frequently Asked Questions

    | Frequently asked questions CC2 Gas Barbecue Cooktop (Part numbers 1204, 1205 and 1206)
  • Page 35 If the START/STOP button flashes green and red, an error has occurred, and the appliance has entered diagnostics mode. Consult the Trouble Shooting section in this manual to identify and resolve the error, or contact Christie Support on +61 3 9708 2999. Please provide the unit serial number for prompt assistance.
  • Page 36 How do I access the underside of the cooktop? Caution: For authorised personnel only If the cooktop is in a Christie cabinet, you will require a key to unlock the cabinet door. Christie supplies keys for each cabinet purchased. Some clients may install their locks with associated keys.

  • Page 37: Troubleshooting

    Troubleshooting | Installation Manual 6837_00...

  • Page 38: Diagnostic Codes | Table

    Contact a licensed gasfitter or suitably qualified person to check that there is gas supply available, and it is set to the correct operating pressure If this is a built-in or non-Christie cabinet, contact a licensed gasfitter or suitably qualified person to ensure the structure has appropriate ventilation If the fault persists, contact Christie customer support or your local technician for assistance, providing details of the fault and the appliance serial number.
  • Page 39 A CC2 Gas Technical Service Manual is available from Christie upon request, for use by suitably qualified persons only. This manual contains detailed information on how to service and repair the appliance.

  • Page 40: Options And Accessories

    | Options and accessories CC2 Gas Barbecue Cooktop (Part numbers 1204, 1205 and 1206)
  • Page 41 Options and accessories | Christie offers a range of options and accessories. Contact us on +61 3 9708 2999 or visit our website at https://dachristie.com/barbecues/cooktops/ CLEANING KIT 1 x handle, 1 x 500ml pH neutral cleaning concentrate, 6 x medium grain buffing pads.
  • Page 42 | Warranty certififcate WARRANTY CERTIFICATE CC2 Gas Barbecue Cooktop (Part numbers 1204, 1205 and 1206)
  • Page 43 No labour coverage is included with any repair and/or replacement part. This warranty does not apply to any of Christie’s products which are modified in any way by any person other than a person authorised by Christie, including, but not restricted to, products tampered with, altered, modified, repaired, or not installed in accordance with Christie’s published installation instructions.

  • Page 44: Warranty And Claim Procedure

    Warranty service may be obtained by contacting Christie via their website at www.dachristie.com, by telephone on +61 3 9708 2999, or at 5 Lakewood Boulevard, Carrum Downs VIC 3201. The freight to Christie will be at the Purchaser’s expense, but return freight will be at Christie’s expense.
  • Page 45 Installation Manual 6837_00...
  • Page 46 +61 3 9708 2999 dachristie.com Installation Manual 6838_03...
