- Page 1 10/100Mbps Fast Ethernet LAN Card User's Guide Model # ALN-101C...
-
Page 2: Hardware Installation
FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits of a Class B computing devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Driver Installation
2. Insert the adapter into a PCI slot. 3. Secure this adapter to the rear of the computer chassis and put back the computer cover. 4. Connect the adapter to the network using twisted-pair cable. 5. Connect the NIC and the PC mother board with WOL cable. (If adapter supports WOL function) Driver Installation: Windows XP, Windows 2000, Windows a) When Windows boots up, operating system will detect the LAN card and Found New... - Page 4 c) When OS finishes loading device driver, window below will appear. Click Ok to complete the installation: Windows 98SE a) When Windows boots up, operating system will detect LAN card and Add New Hardware Wizard window will appear. Click Cancel: b) Insert the Driver Installation CD into CD-ROM drive, window below will appear then click Install Driver:...
- Page 5 c) After OS finishes loading device driver, window below will appear then click OK to restart the system. d) After the system boots up, Please wait for a while to finish setting up the device. When operating system finishes loading LAN card files, window below appear.
