NOTE: If you do not find your watch movement here, please go to www.
adidas.com/watches.
CHRONOGRAPH TWO EYE
A
B

TIME SETTING

1. Pull crown out to position 3.
2. Turn crown to set the desired time.
3. Return crown to position 1.

DATE SETTING

1. Pull crown out to position 2 (the watch continues to run).
2. Turn crown until yesterday's date appears.
3. Pull crown out to position 3 (the watch stops).
4. Turn crown until correct date appears.
5. Continue to turn crown until correct time appears.
6. Return crown to position 1.

CHRONOGRAPH OPERATION

1. Press A to start/stop the chronograph.
2. Press B for reset.
ADJUSTING THE CHRONOGRAPH
1. Pull crown to position 3.
2. Press A to reset the second hand to "0."
3. Press B to reset the chronograph minute hand.
4. Return crown to position 1.
OS11
Hour hand
1
2
3
2
Second
hand
Chronograph
minute hand
A
Minute hand
1
2
3
Date
b
Chronograph
second hand

Advertisement
