Service Manual
Treadwall Model CP
tm
Copyright 1997 - Brewer's Ledge Inc.
J:\MANUAL~1\MODELC~1\SERVICE SERVMANL.SAM 12/07/94 06/24/99

Advertisement

loading

Summary of Contents for Brewer's Ledge Treadwall CP

  • Page 1 Service Manual Treadwall Model CP Copyright 1997 - Brewer's Ledge Inc. J:\MANUAL~1\MODELC~1\SERVICE SERVMANL.SAM 12/07/94 06/24/99...
  • Page 2 Normal wear and tear is excluded from this warranty. No warranty shall be provided in the event the Treadwall is modified by original purchaser, for parts not approved by Brewer's Ledge Inc., or for warranty-related service other than by personnel authorized Brewer's Ledge Inc.
  • Page 3 In no case shall Brewer's Ledge be liable for any special, incidental, or consequential damages based on breach of warranty, breach of contract, negligence or any other legal theory.
  • Page 4 Machine Diagram Pulley bar Access hole Drive chain access hole Control line Speed control CONTROL Cable turnbuckle PANEL Angle adjust wheel Interior turnbuckle Cable guard Access hole Locking disk Chain tension adjuster Adjustable bearing Treadwall model CP - side view...
  • Page 5 Maintenance and Service Treadwall maintenance is easy and requires only lubrication and attention to a number of ® adjustments relating to the alignment of the wall. The most important maintenance of the Treadwall occurs during the first month of operation when the chains and cables are stretching to their final length. It is very important to keep the angle-adjuster cables tight during this break-in period so that the winds remain even and do not overlap.
  • Page 6 People required: Time required: 10 minutes Tools required: Small screwdriver, small adj. wrench 2. Two Months. A. Check Main Chain and drlive chain tension after the second month of use. Although the chains used on the Treadwall are designed for much harder use than the Treadwall will give them, they will stretch slightly upon breaking in.
  • Page 7 Do NOT over-grease: only a small amount will be necessary. People required: 1 person Time required: 15 minutes Tools required: Grease gun with bearing grease. For service questions, please call Brewer's Ledge Inc. in Boston, Mass. 800-707-961...
  • Page 8 Troubleshooting Guide TROUBLESHOOTING GUIDE -- TREADWALL® FITNESS CLIMBER Problem Cause Solution Wall is sluggish: lighter Channels misaligned. See Service Bulletin #20. weights will not pull wall Chains too tight. See Service Bulletin #20. down. Internal x-bracing too tight. See Service Bulletin #20. Broken angle adjuster cable.
  • Page 9 Service Bulletins # 1, 2, 3, 4, 6, 7, 8, 10, 11, 18, 20, 21, 23, 27, 28 @These Bulletins are those that pertain to standard service issues. As needed, we develop further Service Bulletins for specific tasks. May, 1996 Now Available from Brewer's Ledge: The Treadwall ® Spare Parts Kit (for Treadwall model CP)
  • Page 10 INDEX OF SERVICE BULLETINS Treadwall Climbing Simulators -- CP Number Index Panel Removal Frame Adj. w/ X-brace Adjustment of the internal Microswitch Replacement of Cables - Angle Adjuster Gland Nut Adjustment - Hydraulic Valves Harness Cord Upgrade and Adjustment Replacement of Brake Control line - Upper Pulley Bar Adjustment of Chain Tension Instructions for Electronic Counter Hold placement...
  • Page 11 Replace all four bolts. MAKE SURE TO ORIENT PANELS SO THAT PANEL BARS AND HOLD-MOUNTING HOLES ALTERNATE!! Side Access holes Panel bolts: four total If you have any questions, please do not hesitate to call 8:30-5 E.S.T. 1-800-707-9616. Copyright 1994, Brewer's Ledge Inc.
  • Page 12 Treadwall Service Bulletin #2: FRAME ADJUSTMENT WITH ® "X-BRACING" The Treadwall is aligned with the support frame by adjusting the diagonal bracing at the back of the machine. It is important to properly align the wall, both for angle adjustment and performance. With the wall at vertical, note the gaps between the side channels and the two main side frames.
  • Page 13 Treadwall Service Bulletin #3: Adjustment of microswitch ® The Treadwall counter is activated by a simple microswitch which counts every other 6" panel, each click/count indicating 1' of distance. The microswitch is mounted inside the panels with its arm passing over every other panel stiffener bar.
  • Page 14 If the cable has been previously replaced with a hook-and-hook style turnbuckle, you can use the old turnbuckle with the new cable. Hook-and-hook turnbuckle Hook-and-eye turnbuckle Brewer's Ledge 34 Brookley Rd. Jamaica Plain, MA 02130 (800) 707 9616...
  • Page 15 Treadwall Service Bulletin #4: REPLACING CABLES (type 1) ® 1. Tools needed: Ball peen hammer A small box wrench with closed end. (Exact size not important.) 2. Procedure (Same on both sides): Removing... 1. Lock wall in a position so hole in Adjuster Pipe faces up (Note how cable dips into hole near the center of the windings and is locked in place with a bolt inside pipe.) 2.
  • Page 16 (Bulletin # 4 - page 2) 9. Hook turnbuckle and tighten. Make sure wraps of cable on pipe are evenly wound and tight together as you tighten turnbuckle. 10. Re-install chrome Adjuster wheel and by swinging wall front and back, stretch new cable.
  • Page 17 Front frame Cable Rectangular sleeve The cable is provided without a turnbuckle. If the original turnbuckle is damaged, order a new hook-and-hook style turnbuckle from Brewer's Ledge. Otherwise, use the old turnbuckle. Brewer's Ledge 34 Brookley Rd. Jamaica Plain, MA 02130...
  • Page 18 Treadwall Service Bulletin #4a: REPLACING CABLES (type 2) ® 1. Tools needed: Ball peen hammer A small box wrench with closed end. (Exact size not important.) 2. Procedure (Same on both sides): Removing... 1. Lock wall in a position so hole in Adjuster Pipe faces up (Note how cable dips into hole near the center of the windings and is locked in place with a bolt inside pipe.) 2.
  • Page 19 (Bulletin # 4 - page 2) 5. Wrap the shackle end around pipe so as to follow a left hand thread as shown in fig. 1. 6. After four turns, attach the cable to the front of the frame with the clevis pin and cotter pin. 7.
  • Page 21 Treadwall Service Bulletin #6: Valve adjustment ® The brake-control valve on the Treadwall sometimes needs adjustment after the initial break-in period. If there is any oil leakage from the stem of this valve, the gland nut must be tightened. 1. Remove the top right fabric side cover. 2.
  • Page 22 Treadwall Service Bulletin # 7: HARNESS CORD UPGRADE ® AND/or REPLACEMENT Enclosed is the replacement harness for the Treadwall Climbing Simulator. While you're at it, you can upgrade the machine to the latest configuration: If your Treadwall does not have a metal ring tied to the control line where it comes out of the machine at the top, you will have to shorten the current control line on your machine.
  • Page 23 Treadwall Service Bulletin #8: Replacing the Treadwall ® control line. Fig. 1 shows the upper pulley bar from the front. Above the middle pulley there is an access hole that can be reached from the top of the machine, behind the pulley bar shroud as shown. Another access hole is on the right side of the pulley bar and its location is shown in both pictures.
  • Page 24 Treadwall Service Bulletin #10 ® Adjustment of chain tension The main chains that suspend the panels on the Treadwall may stretch in the course of the first few months of use. If this happens, the panels will be loose as they move around the bottom and up the back, and they will jam as they attempt to enter the channel in the back (see diagram).
  • Page 25 Treadwall Service Bulletin # 11: Electronic Counter ® Instructions INSTALLATION OF 'CLIMBOMETER' FITNESS COUNTER 1. The Climbometer is installed on the left channel. Install the bracket as shown, using the short bolt for the top hole and the bolt for the channel spacer bar for the bottom hole. The middle hole is for the wire.
  • Page 26 Treadwall Service Bulletin #18 ® Hold placement It is very important when placing holds on the Treadwall that the holds do not overlap the space between two panels. A hold that overlaps two panels will restrict the machine from rotating as the panel moves around the bottom or top of the Treadwall.
  • Page 27 Treadwall Service Bulletin #20 - Correction of stiff operation ® In a properly working Treadwall, a body weight of approximately 60-70 lb.. will operate the wall consistently. If the operation is stiff or sluggish and will not operate at the minimum weight, there are several areas that may be responsible.
  • Page 28 (Bulletin #20 - page 2) hydraulic upper channel control bearings unit channels resist. lever turn- buckle fig. 1 channel x-brace turnbuckles shaft collars access hole lower shaft bearings adj screw fig. 2 bearing bolts If you have any questions, please do not hesitate to call 8:30-5 E.S.T.
  • Page 29 Treadwall Service Bulletin # 21 ® Replacement and use of elastics to fasten sidecovers. The sidecovers for the Treadwall are held in place by neoprene rings at each corner. These are fastened through the sidecover grommet by passing one end of the ring through the grommet and doubling the 1 If you have any questions, please do not hesitate to call 8:30-5...
  • Page 30 Tighten the bolt with the Allen wrench until the Tee-nut is drawn fully into the panel and flush with the surface. Vice-grips Tee-nut Rim Tee-nut Prongs Tee-nut fully seated Panel Hold 3/8" Hold Bolt Allen wrench If you have any questions, please do not hesitate to call 8:30-5 E.S.T. 1-800-707-9616. Copyright 1994, Brewer's Ledge Inc.
  • Page 31 Treadwall Service Bulletin #27 Securing internal x-bracing. ® It has come to our attention that the inside turnbuckles on the Treadwall sometimes loosen up, even when the locknuts are tightened down securely. These are the turnbuckles which can be seen through the access holes at the bottom of the side channels, not the larger turnbuckles on the frame at the back of the machine.
  • Page 32 The following methods are used in re-locating the Treadwall. MOVING WITHIN A ROOM WITHOUT OVERHEAD OBSTRUCTIONS. Casters: Brewer's Ledge provides both light duty (for occasional moving) and heavy duty (for frequent moving) casters. These casters are bolted onto the lower cross-member of the side frames and may be left in place during normal operation.
  • Page 33 The Treadwall may be totally disassembled into parts that will fit through a normal doorway. If this is required, an installation kit is available from Brewer's Ledge that includes a comprehensive manual and video. Price - $45. Call for details.
  • Page 34 Treadwall Service Bulletin #38: FIXING PANELS THAT RUB ® ON CHANNELS The climbing panels on the Treadwall run in tracks in the two large side channels. It is important that the ends of the panels do not rub against the channels. Rubbing panels can produce enough friction to seriously slow or even stop the Treadwall.
