USER MANUAL
Series X - Standard Display (STD) Models
HD 12T21 STD-xxx-Fxxx - 12.1 inch Standard Display
HD 15T21 STD-xxx-Fxxx - 15.0 inch Standard Display
HD 17T21 STD-xxx-Fxxx - 17.0 inch Standard Display
HD 19T21 STD-xxx-Fxxx - 19.0 inch Standard Display
HD 24T21 STD-xxx-Fxxx - 24.0 inch Standard Display
HD 26T21 STD-xxx-Fxxx - 25.54 inch Standard Display
User Manual STD Series X
Updated: 31 Jul 2019
Created: 363
Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
Doc Id: INB100535-1 (Rev 30)
Approved: 6542

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HATTELAND TECHNOLOGY STD X Series and is the answer not in the manual?

Questions and answers

Related Manuals for EMBRON HATTELAND TECHNOLOGY STD X Series

Summary of Contents for EMBRON HATTELAND TECHNOLOGY STD X Series

  • Page 1 USER MANUAL Series X - Standard Display (STD) Models HD 12T21 STD-xxx-Fxxx - 12.1 inch Standard Display HD 15T21 STD-xxx-Fxxx - 15.0 inch Standard Display HD 17T21 STD-xxx-Fxxx - 17.0 inch Standard Display HD 19T21 STD-xxx-Fxxx - 19.0 inch Standard Display HD 24T21 STD-xxx-Fxxx - 24.0 inch Standard Display HD 26T21 STD-xxx-Fxxx - 25.54 inch Standard Display User Manual STD Series X...
  • Page 2 Copyright © 2019 Hatteland Technology AS Eikeskogvegen 52, N-5570 Aksdal, Norway. All rights are reserved by Hatteland Technology AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Technology AS.

  • Page 3: Table Of Contents

    Contents Contents ..................3 Contents of package ....................... 7 General .................... 9 About this manual ......................... 10 About Hatteland Technology ....................10 www.hattelandtechnology.com ..................... 10 Contact Information ......................10 Standard Display (STD) - Introduction ...................11 Touch screen products ......................12 Product Labeling ........................
  • Page 4 Contents Operation ..................41 User Controls ........................42 On Screen Display (OSD) Menu Introduction ............... 44 OSD Key Code (password) overview ................... 44 OSD Keycode / OSD Lock Mode ..................45 OSD Simplified and Full Menu modes (examples) ............... 46 OSD Visual Feedback (examples) ..................
  • Page 5 Contents Technical Drawings - Accessories ..........81 Technical Drawings - HD CMB SX1-A2 ................82 Console Mount Kit 12”,15”,17”,19” ..................82 Technical Drawings - HD CMB SX1-A3 ................83 Console Mount Kit 12”,15”,17”,19” ..................83 Technical Drawings - HD CMB SX1-B1 ................84 Console Mount Kit 24 inch ....................
  • Page 6 Contents Appendixes ................. 109 Pinout Assignments ......................110 Basic Trouble-shooting ......................112 Declaration of Conformity ....................113 Return Of Goods Information ....................114 General Terms and Conditions ....................115 Pixel Defect Policy .......................116 Notes ...........................117 Revision History ........................119 IND100130-44...

  • Page 7: Contents Of Package

    Contents of package Note: Entries listed below are for Standard factory shipments. Customized factory shipments may deviate from this list. Item Description Illustration 1 pcs of Standard DVI Signal Cable. DVI-D 18+1P Male to DVI-D 18+1P Male Single Link - Length 2.0m HA-SDM-2M 1 pcs of Standard VGA Signal Cable.
  • Page 8 This page left intentionally blank...

  • Page 9: General

    General...

  • Page 10: About This Manual

    Hatteland Technology AS About this manual The manual contains electrical, mechanical and input/output signal specifications. All specifications in this manual, due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last updated and revision date of this manual are shown both on the frontpage and also in the “Revision History” chapter. This user manual is a standard/general manual that applies to all variations of its product family, i.e.

  • Page 11: Standard Display (Std) - Introduction

    Displays Series X Standard Display (STD) - Introduction Series X Displays and Panel Computers offer the ultimate in performance, convenience, state of the art design and enduring quality for system integrators and boat builders. Series X products offer a range of feature sets optimized for varying requirements and applications.

  • Page 12: Touch Screen Products

    Touch screen products Introduction to products with touch screen Nearly all of our products with touch screen use Projected Capacitive Touch screen (PCTS), widely used with great success on mobile phones and typical pad devices. PCTS can be equally effective also for marine applications. One of the advantages of PCTS is that it has features seen in both resistive and surface capacitive touch screen technologies.
  • Page 13 Touch screen products Touch Screen Drivers and Documentation All units are shipped with a Documentation and Drivers DVD or CD which contains suitable drivers* for touch screens. (Named MEDIA STD01). You can also visit our website www.hatteland-display.com/archive to view the same list (or even recently new added products) for our models with touch screen.

  • Page 14: Product Labeling

    Product Labeling Introduction This section details the locations, content details and specifications for factory mounted labels for all currently available standard Hatteland Technology Standard Industrial Display (STD) models. This information will in most cases also apply for most Customized Models as well, but may differ based on customer requirements, in that case, please refer to the customized User Manual (paper or electronic version, dependent on customer requirements).
  • Page 15 Product Labeling Label Locations Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below are seen from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation vs product size is drawn in.
  • Page 16 Product Labeling Warranty label covers screw. HD 24T21 STD-xxx-Fxxx Labels placed on rear. Warranty label covers screw. HD 26T21 STD-xxx-Fxxx Labels placed on rear. IND100077-115...
  • Page 17 Product Labeling Warranty Label If you are to perform service on a unit still under warranty, any warranty will be void if this label show signs of removal attempts or damaged by screw driver. This label is located on the back of the product and covers a key screw. This is to aid service departments in determining if there has been any unauthorized service on a unit still under warranty.
  • Page 18 This page left intentionally blank...

  • Page 19: Installation

    Installation...

  • Page 20: General Installation Recommendations

    General Installation Recommendations First Things First! CORRECT HANDLING! CORRECT HANDLING! IND100148-5 - Rev 05 ATTENTION! To prevent damage to chassis and glass, please review the illustrations ! Place horizontally on a smooth and clean surface (table with cloth) Do not stress the corners, nor p RRECT HANDLING! RRECT HANDLING! WRONG HANDLING!

  • Page 21: Installation Limitations

    General Installation Recommendations 9. Do not paint the product. The surface treatment influences the excess heat transfer. Painting, labels or other surface treatments that differ from the factory default, might cause overheating. 10. Expose to heavy vibration and acoustic noise might under certain circumstances affect functionality and expected lifetime.
  • Page 22 General Installation Recommendations General mounting instructions 1. The useful life of the components of all Electronics Units generally decreases with increasing ambient temperature; it is therefore advisable to install such units in air-conditioned rooms. If there are no such facilities these rooms must at least be dry, adequately ventilated and kept at a suitable temperature in order to prevent the formation of condensation inside the display unit.

  • Page 23: Ergonomics

    General Installation Recommendations Ergonomics 1. The front surface of the display glass has an anti-reflective (AR) coating which can be scratched and damaged with improper cleaning. It is recommended to use only 90+% pure Isopropyl alcohol (Isopropanol) and a soft fabric cloth for this first cleaning.

  • Page 24: Maximum Cable Length

    General Installation Recommendations Maximum Cable Length Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal cable length will depend not only on the signal resolution and frequency, but also on the quality of the signal output from the computer/radar.

  • Page 25: Housing / Terminal Block Connector Overview

    General Installation Recommendations Housing / Terminal Block Connector Overview Housing / Terminal Block connectors are available in different sizes (example 2-pin, 4-pin, 5-pin) which plug into the connector area of the unit. They are mounted by factory default and delivered with the unit. The housing / terminal block connectors have steering rails, which ensures that it can not be mounted wrong.
  • Page 26 General Installation Recommendations Configuring Housing / Terminal Block connectors Below is a brief illustration that might be useful during configuration and installation of such connectors. You will need suitable pre-configured cable(s) and tools to configure the connector(s) and cable(s) that are present in your installation environment.

  • Page 27: Panel / Console Mounting Bracket Kit For 12", 15", 17" And 19

    Installation Procedures Panel / Console Mounting Bracket Kit for 12”, 15”, 17” and 19” You need: Allen Wrench tool (3mm), 4 pcs of HD CMB SX1-A2 or -A3 Kit (-A2 included in delivery). Procedure suitable for: Display and Panel Computers. Brackets are EN60945 Tested. Attention: A suitable pre-cut panel cutout should be made prior to mounting.

  • Page 28: Panel Cutout / Console Mounting Bracket Kit For 24 Inch

    Installation Procedures Panel Cutout / Console Mounting Bracket Kit for 24 inch You need: Torx T25 tool, 1 pcs of HD CMB SX1-B1 kit (included in delivery). Procedure suitable for: Display and Panel Computers Series X range. Brackets are EN60945 Tested. Attention: A suitable pre-cut panel cutout should be made prior to mounting.

  • Page 29: Panel Cutout / Console Mounting Bracket Kit For 26 Inch

    Installation Procedures Panel Cutout / Console Mounting Bracket Kit for 26 inch You need: Torx T25 tool, 1 pcs of HD CMB SX1-C1 kit (included in delivery). Procedure suitable for: Display and Panel Computers Series X. Brackets are EN60945 Tested. Attention: A suitable pre-cut panel cutout should be made prior to mounting.

  • Page 30: Mounting Bracket, Table / Desktop / Ceiling - 12",15",17",19

    Installation Procedures Mounting Bracket, Table / Desktop / Ceiling - 12”,15”,17”,19” Typenumber Illustration Fits unit model “Footprint” indicates holes to drill at installation location. HD TMB-SX1-A1 HD 12T21 MMD-xxx-Fxxx HD 12T21 STD-xxx-Fxxx HD 12T21 MMC-xxx-xxxx HD 15T21 MMD-xxx-Fxxx HD 15T21 STD-xxx-Fxxx HD 15T21 MMC-xxx-xxxx HD TMB-SX1-B1 HD 17T21 MMD-xxx-Fxxx...

  • Page 31: Important To Know About Left And Right Brackets

    Installation Procedures Important to know about LEFT and RIGHT brackets Throughout the following installation procedure, it is important to understand the difference between LEFT and RIGHT brackets. The Display and Panel Computer chassis are not 100% square boxed, but are slightly designed with a minor narrow angled chassis towards the rear (FIG1) to allow easier “drop-in”...

  • Page 32: Installation Procedure - Tmb Versions

    Installation Procedures Installation Procedure - TMB Versions Procedure suitable for: Display (MMD/STD) and Panel Computer (MMC) Series X Generation (G1) product ranges. 19 inch model used as example in this procedure. You need: - M4 Unbrako® Hex Key tool (not included with delivery). - M7 Unbrako®...
  • Page 33 Installation Procedures ▼ 4: Inspect the inner side of both brackets and especially the ▼ 5: Notice the indication of LEFT and RIGHT. The orientation of the Key Hole Plug (4 pcs). They should be shaped mounting bracket (2 pcs) is marked with respective as an standing “egg”...
  • Page 34 Installation Procedures ▼ 8: You may now mount the unit onto your desired location. It is advised that you unlock the Lock Pin (as shown in step 5), tilt the unit 90 degrees backwards (FIG1) and properly fasten the bracket base into location (FIG2). NB! Be careful not to break or scratch the edge of the front glass! You may notice that it is now possible to tilt the unit while Base Feets are fasten as the added weight of unit will help the momentum (see Step 2, “Tilting can not be performed by hand”).

  • Page 35: Mounting Bracket, Table / Desktop / Ceiling - 24, 26 And 27 Inch

    Installation Procedures Mounting Bracket, Table / Desktop / Ceiling - 24, 26 and 27 inch You need: M5 Unbrako® Hex Key tool and 1 pcs of HD TMB SX1-C1 Mounting Bracket Kit. Fasteners (6 pcs M6) for Table / Desktop location not included. Procedure suitable for: Display and Panel Computers. 24 inch unit used as illustration below, but same procedure apply for 26 and 27 inch units as well.
  • Page 36 Installation Procedures ▼ 5: You may now mount the unit onto your desired location. It is advised that you unlock the Lock Pin (as shown in step 4), tilt the unit 90° backwards (FIG1) and properly fasten the bracket base into location (FIG2). NB! Be careful not to break or scratch the edge of the front glass! Then repeat step 4 again until your desired tilting position has been achieved and you have verified that the Lock Pin are in locking position and the unit is firmly attached and does not appear loose (FIG3).

  • Page 37: Physical Connections

    Physical Connections Connection area of unit (illustration) USB Touch DVI-D In RS-232 COM VGA/RGB Out Power Input AC RS-422/RS-485 COM VGA/RGB In Power Input DC Grounding Screw Note: 19 inch unit used as example above, please review specifications for your actual model. Reduce Cable Tension To reduce tension on the cables you connect, secure them with a cable tie to the available chassis hinges located near the...
  • Page 38 Physical Connections Important note for DVI signal detection: Please note that for the operating system to detect DVI signals correctly, the DVI cable MUST be connected physically to the unit during boot up otherwise you may experience a black image. Furthermore certain graphics drivers may need to refresh their device list (often done manually by user - detect devices), while in some cases the Plug-n-Play will automatically detect the DVI signal correctly.
  • Page 39 Physical Connections GROUNDING SCREW: Please review “General mounting instructions” in the “Installation” chapter, pt. 7 for more information. Multi-power note: (For units supporting AC & DC input simultaneously) The unit has a dual input power supply which will accept both AC and DC input. If both inputs are connected, the unit will be powered by AC.
  • Page 40 This page left intentionally blank...

  • Page 41: Operation

    Operation...

  • Page 42: User Controls

    User Controls USER CONTROLS OVERVIEW The units are designed using Glass Display Control™ (GDC) touch technology to allow interactivity adjusting brilliance (brightness) and control power on / off with the use of illuminated symbols. Note that these symbols are only visible (backlight illuminated) when suitable power is connected, except for the power symbol which has a white silk print to indicate its position on the front glass.
  • Page 43 User Controls Action Indicators: SERVICE = Built in functionality to determine when the unit requires service in order to perform within preset factory standards. This area will illuminate constantly until the unit is powered off. Note that by touching this symbol no action will be performed or has been assigned. Brightness Adjust: Brilliance / Brightness adjustment of the displayed image is adjusted by touching the (-) or (+) illuminated symbols.

  • Page 44: On Screen Display (Osd) Menu Introduction

    OSD Menu Overview On Screen Display (OSD) Menu Introduction The OSD menu consists of main menus and submenus which is very easy to navigate through. All functions are explained in-depth later in this user manual. Prior to using the OSD menu,you should be sure to familiarize yourself with how to physically access the menu, how to navigate up/down/left/right, how to modify values, exiting menus and more.

  • Page 45: Osd Keycode / Osd Lock Mode

    OSD Menu Overview OSD Keycode / OSD Lock Mode During use, a small requester may pop-up on screen asking you for a 3 digit “Key Code”. This is a safety feature (due to ECDIS Compliance) that might be predefined in your setup. To quickly understand how to enter a code, navigate and finally access the underlying main menu, simply follow the illustration below.

  • Page 46: Osd Simplified And Full Menu Modes (Examples)

    OSD Menu Overview OSD Simplified and Full Menu modes (examples) You may encounter two different menu setups based on factory default or by customized preset configuration. By first apperance they look the same at the main level, but the underlying sub-menus are slightly different. The Simplified Menu mode offers easy and clear access to most commonly used functions.

  • Page 47: Osd Menu Structure

    OSD Menu Overview OSD Menu Structure In this table all functions within menus and their submenus are shown. Functions that begins with an asterix (*) and bold/red font color style indicates this function/menu is only available during “Full” menu mode. Some functions are not available for all signal sources due to industry standards and signal properties.

  • Page 48: Management

    OSD Menu Overview Management Level 1 (Main Menu) Level 2 Level 3 Level 4 Level 5 Management > < Exit LED Drive > (Slider Bar) *Communication > < Exit RS232 > (Radio Button) 2-wire RS485 > (Radio Button) 4-wire RS485/422 > (Radio Button) Address RS >...

  • Page 49: Osd Menu Functions

    OSD Menu Functions OSD Menu Functions The following section covers all possible settings that the user can (in a certain mode) encounter or needs to adjust via easy understandable menus, text and navigation. For simpler reading the menu choice “Exit” has been left out of description in this chapter intentionally.
  • Page 50 OSD Menu Functions Image Settings Lets you configure various visual preferences for any signal. The contents of these submenu are listed below. Please note: The internal Video Scaler circuit does not support Graphic Scaling features, and thus any resolutions except the recommended native resolution as noted on the Datasheet will be displayed to fit screen/full screen regardless of the incoming video signal.
  • Page 51 OSD Menu Functions Image Settings - Display V.Position |--------3-------- Settings as follows: “V.Position” = Move image within the TFT panel active area Vertically (up/down), values from 0 to 100. ● Note: Default value is centered inside the active TFT panel area. Image Settings - Display Clock |--------3--------...
  • Page 52 OSD Menu Functions Color Mode Lets you adjust the color temperature (Kelvin degrees) of the image. This applies to the Source signal only. OSD Menu overlay will be unaffected. Lower values make the image appear warmer, while higher values will make it appear cooler. The contents of these submenus are listed below. Illustration (does not appear in menu): The Kelvin color temperature scale (approximate and symbolic): 1800K 4000K...
  • Page 53 OSD Menu Functions Management Allows you to adjust voltages for LED (which illuminate the front glass symbols) and setup Serial Communication mode. The contents of these submenus are listed below. Management LED Drive |---2--- The touch enabled symbols available on the front glass of the unit is backlight illuminated by LED technology.
  • Page 54 OSD Menu Functions OSD Misc Allows you to customize the visual appearance of the On Screen Display (OSD) menu, such as; position, language, save, load and recall favourite settings and more. The contents of these submenus are listed below. OSD Misc OSD Position |---2--- Settings as follows:...
  • Page 55 OSD Menu Functions OSD Misc - Presets Save *Available in “Full Mode” only |--------3-------- Allows you to save current state of all function and values to user defined presets. The contents of the submenu is listed below. Settings as follows: “User 1”...
  • Page 56 OSD Menu Functions OSD Misc OSD Lock Mode *Available in “Full Mode” only |---2--- To prevent accidental or unwanted user intervention, you can set the behaviour of how the OSD menu is accessible by the user. Normally it is by factory default accessible by touching the MENU” symbol on the front glass of the unit.
  • Page 57 OSD Menu Functions OSD Settings OSD Key Outdoor |---2--- To prevent accidental activation of Glass Display Control™ (GDC) touch functions, you can add an extra layer of security on how “sensitve” the touch detection operates. This applies for “MENU”, “(-) Brilliance (+)” and “Power Off” functions. The OSD Key Outdoor function is especially effective if the unit is located in a outside environment where rain drops could potentionally trigger touch button functions.
  • Page 58 OSD Menu Functions Service Will show various technical and unit related information, such as; Firmware versions, Elapsed Time, Internal Temperature, Fault Status and activation for the internal Test Pattern image useful for trouble- shooting. Whenever you are in contact with helpdesk or service, they might require you to read back some of these values in order to precisely pinpoint any problem/question you should have with the unit or its functionality.
  • Page 59 OSD Menu Functions Service Test Pattern |---2--- Will show the internal test pattern with shading color boxes for Red, Green, Blue and Black/White (Grayscale) to check for deviations in the TFT panel/display controller behaviour. It is independent of any current resolution or specifications found in the signal inputs. The test pattern is generated internally in the display controller and is sent 1:1 directly to the TFT panel.
  • Page 60 This page left intentionally blank...

  • Page 61: Operation Advanced (Ddc/Ci)

    Operation Advanced (DDC/CI)

  • Page 62: Introduction

    Operation Advanced (DDC/CI) Control Overview Introduction DDC/CI (Display Data Channel/Command Interface) specifies a means for a computer to send commands to the unit's Display Video Controller to programatically adjust parameters of the display instead of pressing physical buttons or navigate through an OSD menu. Specific commands to control units are defined in a separate official Monitor Control Command Set (MCCS) industry standard.
  • Page 63 Operation Advanced (DDC/CI) Control Overview Color Mode: = Command ID MCC: Set/Write Color Temperature: Kelvin Color Where Write ww xx (Color Temperature Select) [S] <6E:w> 51 84 03 ww xx Tempearture 05 A9 = 6500 Reply of successfull request: (0x14) 07 AB = 8000 [S] <6F:r>...
  • Page 64 This page left intentionally blank...

  • Page 65: Specifications

    Specifications...

  • Page 66: Specifications - Hd 12T21 Std-Xxx-Fxxx

    Specifications - HD 12T21 STD-xxx-Fxxx SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight Technology • W:314.00 [12.36''] x H:272.00 [10.71''] x D:64.50 [2.54''] mm [inch] •...

  • Page 67: Specifications - Hd 15T21 Std-Xxx-Fxxx

    Specifications - HD 15T21 STD-xxx-Fxxx SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight • W:356.00 [14.02''] x H:307.00 [12.09''] x D:71.50 [2.81''] mm [inch] •...

  • Page 68: Specifications - Hd 17T21 Std-Xxx-Fxxx

    Specifications - HD 17T21 STD-xxx-Fxxx SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight • W:390.00 [15.35''] x H:351.00 [13.82''] x D:73.50 [2.89''] mm [inch] •...

  • Page 69: Specifications - Hd 19T21 Std-Xxx-Fxxx

    Specifications - HD 19T21 STD-xxx-Fxxx SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight • W:429.00 [16.89''] x H:382.00 [15.04''] x D:74.50 [2.93''] mm [inch] •...

  • Page 70: Specifications - Hd 24T21 Std-Xxx-Fxxx

    Specifications - HD 24T21 STD-xxx-Fxxx SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight • W:593.00 [23.35''] x H:384.00 [15.12''] x D:70.00 [2.76''] mm [inch] •...

  • Page 71: Specifications - Hd 26T21 Std-Xxx-Fxxx (Led/Ccfl Version)

    Specifications - HD 26T21 STD-xxx-Fxxx (LED/CCFL version) SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hattelandtechnology.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality TFT with LED Backlight Technology • W:621.00 [24.45''] x H:435.00 [17.13''] x D:98.20 [3.86''] mm [inch] •...
  • Page 72 This page left intentionally blank...

  • Page 73: Technical Drawings

    Technical Drawings...

  • Page 74: Technical Drawings - Hd 12T21 Std-Xxx-Fxxx

    Technical Drawings - HD 12T21 STD-xxx-Fxxx IND100132-230...

  • Page 75: Technical Drawings - Hd 15T21 Std-Xxx-Fxxx

    Technical Drawings - HD 15T21 STD-xxx-Fxxx IND100132-231...

  • Page 76: Technical Drawings - Hd 17T21 Std-Xxx-Fxxx

    Technical Drawings - HD 17T21 STD-xxx-Fxxx IND100132-232...

  • Page 77: Technical Drawings - Hd 19T21 Std-Xxx-Fxxx

    Technical Drawings - HD 19T21 STD-xxx-Fxxx IND100132-233...

  • Page 78: Technical Drawings - Hd 24T21 Std-Xxx-Fxxx

    Technical Drawings - HD 24T21 STD-xxx-Fxxx IND100132-234...

  • Page 79: Technical Drawings - Hd 26T21 Std-Xxx-Fxxx

    Technical Drawings - HD 26T21 STD-xxx-Fxxx IND100132-239...
  • Page 80 This page left intentionally blank...

  • Page 81: Technical Drawings - Accessories

    Technical Drawings - Accessories...

  • Page 82: Technical Drawings - Hd Cmb Sx1-A2

    Technical Drawings - HD CMB SX1-A2 Console Mount Kit 12”,15”,17”,19” IND100132-262...

  • Page 83: Technical Drawings - Hd Cmb Sx1-A3

    Technical Drawings - HD CMB SX1-A3 Console Mount Kit 12”,15”,17”,19” IND100132-271...

  • Page 84: Technical Drawings - Hd Cmb Sx1-B1

    Technical Drawings - HD CMB SX1-B1 Console Mount Kit 24 inch IND100132-240...

  • Page 85: Console Mounting 24 Inch

    Technical Drawings - HD CMB SX1-B1 Console Mounting 24 inch IND100132-240...

  • Page 86: P006801-1 Flush Mounting 24 Inch

    Technical Drawings - HD CMB SX1-B1 P006801-1 Flush Mounting 24 inch IND100132-240...

  • Page 87: Technical Drawings - Hd Cmb Sx1-C1

    Technical Drawings - HD CMB SX1-C1 Console Mount Kit 26 inch IND100132-274...

  • Page 88: Console Mounting 26 Inch

    Technical Drawings - HD CMB SX1-C1 Console Mounting 26 inch IND100132-274...

  • Page 89: P007084-1 Flush Mounting 26 Inch

    Technical Drawings - HD CMB SX1-C1 P007084-1 Flush Mounting 26 inch IND100132-274...

  • Page 90: Technical Drawings - Hd Ved Sx1-A1

    Technical Drawings - HD VED SX1-A1 VESA Bracket 12”,15”,17”,19”,24”,26” IND100132-247...

  • Page 91: Technical Drawings - Jh 15Tap Std-C1

    Technical Drawings - JH 15TAP STD-C1 15 inch Series X to fit 15 inch Series 1 Console Cutout IND100132-272...

  • Page 92: Technical Drawings - Jh 19Tap Std-C1

    Technical Drawings - JH 19TAP STD-C1 19 inch Series X to fit 19 inch Series 1 Console Cutout IND100132-273...

  • Page 93: Technical Drawings - Hd 19Tap Sx1-C2

    Technical Drawings - HD 19TAP SX1-C2 19” Series X to fit 19” Series 2 Console Cutout IND100132-294...
  • Page 94 Technical Drawings - HD 19TAP SX1-C2 19” Series X to fit 19” Series 2 Console Cutout IND100132-294...
  • Page 95 Technical Drawings - HD 19TAP SX1-C2 19” Series X to fit 19” Series 2 Console Cutout IND100132-294...

  • Page 96: Technical Drawings - Jh 26Tap Std-A1

    Technical Drawings - JH 26TAP STD-A1 26 inch Series X to fit 26 inch Series 1 Console Cutout IND100132-275...

  • Page 97: Technical Drawings - Hd 26Tap Sx1-A1

    Technical Drawings - HD 26TAP SX1-A1 26 inch Series X to fit 27 inch Series 1 Console Cutout IND100132-389...

  • Page 98: Technical Drawings - Hd Tmb Sx1-A1

    Technical Drawings - HD TMB SX1-A1 Desktop/Table Mounting Bracket 12”/15” IND100132-263...
  • Page 99 Technical Drawings - HD TMB SX1-A1 Desktop/Table Mounting Bracket 12”/15” IND100132-263...

  • Page 100: Technical Drawings - Hd Tmb Sx1-B1

    Technical Drawings - HD TMB SX1-B1 Desktop/Table Mounting Bracket 17”/19” IND100132-264...
  • Page 101 Technical Drawings - HD TMB SX1-B1 Desktop/Table Mounting Bracket 17”/19” IND100132-264...

  • Page 102: Technical Drawings - Hd Tmb Sx1-C1

    Technical Drawings - HD TMB SX1-C1 Desktop/Table Mounting Bracket 24/26/27 inch IND100132-265...

  • Page 103: Technical Drawings - Hd 15Cov Sx1-A1

    Technical Drawings - HD 15COV SX1-A1 UV Sun Cover (15 inch) IND100132-295...

  • Page 104: Technical Drawings - Hd 17Cov Sx1-A1

    Technical Drawings - HD 17COV SX1-A1 UV Sun Cover (17 inch) IND100132-296...

  • Page 105: Technical Drawings - Hd 19Cov Sx1-A1

    Technical Drawings - HD 19COV SX1-A1 UV Sun Cover (19 inch) IND100132-297...

  • Page 106: Technical Drawings - Hd 24Cov Sx1-A1

    Technical Drawings - HD 24COV SX1-A1 UV Sun Cover (24 inch) IND100132-298...

  • Page 107: Technical Drawings - Hd 26Cov Sx1-A1

    Technical Drawings - HD 26COV SX1-A1 UV Sun Cover (26 inch) IND100132-342...

  • Page 108: Technical Drawings - Hd Rem Sx1-A1

    Technical Drawings - HD REM SX1-A1 For External Mounting IND100132-287...

  • Page 109: Appendixes

    Appendixes...

  • Page 110: Pinout Assignments

    Pinout Assignments Connectors illustrated here are either standard by factory default or may be available (through factory customization). Note that some combinations may not be possible due to space restrictions. List also valid for customized models. All pin out assignments are seen from users Point of View (POV) while looking straight at the connector. Please review the dedicated datasheet or technical drawings for your actual unit to identify and determine the presence of desired connector.
  • Page 111 Pinout Assignments Serial COM RS-232 non-isolated, 9-pin DSUB Female 10-pin RS-422 / RS-485 Module “RS-422/RS-485 SCOM + Buzzer” 4 3 2 1 (Internal Buzzer can be controlled externally) 9 8 7 6 2 4 6 8 10 1 3 5 7 9 PIN 01** BUZ+ Buzzer Control Positive IN* PIN 02 TxD...

  • Page 112: Basic Trouble-Shooting

    Basic Trouble-shooting GENERAL ISSUES FOR TFT PANEL BASED PRODUCTS Note: Applies for a range of various products. This is only meant as a general guide. O PICTURE / LED BEHAVIOUR: If there is no light at all in the LED at the FRONT, check power cables. If the LED in front is green, then check if the brightness is set/adjusted to max brightness.

  • Page 113: Declaration Of Conformity

    Declaration of Conformity We, manufacturer, Hatteland Technology AS, Eikeskogvegen 52, N-5570 Aksdal, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD, HM MIL, HM CMD, HT STD, HD MMD, HM MMD, HM XRD, HM RMD, HT MMC, HD MMC and HT/HM (computers) product ranges is in conformity with the following standards in accordance with the EMC Directive.

  • Page 114: Return Of Goods Information

    Return Of Goods Information Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Technology referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaluation or products subject for credit, you must ensure that all accessories received from our warehouse are returned.

  • Page 115: General Terms And Conditions

    General Terms and Conditions As of January 2015, Hatteland Technology AS’ “Terms of Sales and Delivery” and “Warranty Terms” have been substituted by the updated ”General terms and conditions for sale of goods and performance of additional services” (the “General Terms and Conditions”). Further, from January 2015 onward, the previous “Terms of Sales and Delivery”...

  • Page 116: Pixel Defect Policy

    Pixel Defect Policy PIXEL DEFECT POLICY Dot-defects (Bright or dark spots on the panel) Due to the effect that dot failures are part of the TFT technology such failure occurrence cannot be prevented basically. Even though dot defects usually occur during production process, new defects can appear within the lifespan of a TFT display. Neither the production at LCD-supplier nor the use of an LCD-Monitor after shipment can be influenced by Hatteland Technology.

  • Page 117: Notes

    Notes General Notes: - The unit is type approved according to EN60945 4 th , 4.4, equipment category b) protected from the weather. - Other type approvals applies for the different products. Please see the appropriate “Specifications” page in this manual for more information. - Use of brillance and Glass Display Control™...
  • Page 118 User Notes Appendix IND100077-24...

  • Page 119: Revision History

    Revision History Rev. Date Notes 00-1 23 Feb 2012 Release for internal review. 00-2 16 Mar 2012 Revised after internal review. 14 May 2012 Release for internet 17 Aug 2012 Revised type approvals and removed MTBF data, page 40,41,42,43,44,45 18 Jun 2013 Revised Contents of Package (connectors), page 6 Added General Touch Screen Info and labels page 10,11,12,13,14,15 Revised Product Labeling chapter, ref: QAR/117540, page 12,13,14,15...
  • Page 120 Revision History 06 Nov 2015 General update throughout the manual Revised Touch Screen Introduction, text and tables, page 10 Revised HD TMB SX1-C1, Max Forward Tilting angle (from 62° to 60°), page 96 20 Jan 2016 Revised text for ”OSD Key Outdoor” mode, not applicable for STD units. Ref: QAR/131995, page 19 27 Jan 2016 ”OSD Key Outdoor”...
  • Page 121 Revision History Appendix IND100077-119...
  • Page 122 Hatteland Technology AS | www.hattelandtechnology.com | Enterprise no: NO974533146...

Table of Contents
