Summary of Contents for NexSens CB-400
- Page 1 C B - 4 0 0 D a t a B u o y U s e r Ma n u a l...
- Page 2 About NexSens Technology, Inc. NexSens Technology, Inc. was founded in the late 1990s with a mission to advance the capabilities and simplify the development of environmental monitoring systems. The company specializes in environmental sensors, remote data acquisition and communications technology, easy-to-use computer software, and web-based datacenters.
-
Page 3: Table Of Contents
CHAPTER 6 – SAFELY DEPLOYING THE BUOY ....................19 Single-Point Mooring Deployment ..................... 19 Two-Point and Three-Point Mooring Deployment ..............19 CHAPTER 7 – MAINTENANCE ........................20 Post-Season Cleaning ........................20 Replacing an RBP500 Battery Pack ..................... 20 CB-400 Data Buoy User’s Manual... - Page 4 NexSens Technology, Inc. February 19, 2013 CHAPTER 8 – WARRANTY & SERVICE ......................23 Limitation of Warranty ........................ 23 Corporate Headquarters & Authorized Service Center .............. 23 CB-400 Data Buoy User’s Manual...
-
Page 5: Chapter 1 - Introduction
February 19, 2013 CHAPTER 1 - INTRODUCTION NexSens CB-400 data buoy systems are designed for coastal or lake water monitoring applications. The floating platform supports both topside and subsurface environmental monitoring sensors with options for radio, cellular, and satellite data transmission. Temperature strings, multi-parameter sondes, Doppler current meters, weather stations, and other monitoring instruments can all be quickly deployed in protected coastal waters or lakes. -
Page 6: Chapter 2 - Components And Specifications
Hull: 36” diameter, 12” height Overall: 57” height (without instrument cage), 81” height (with instrument cage) Weight CB-400: 95 Lbs. (with SDL500, cage and tower) CB-400S: 120 Lbs. (with solar, RBP500, SDL500, cage and tower) Materials Hull: cross-linked polyethylene foam with polyurea coating... -
Page 7: Common Accessories
” SS187 Stainless steel mooring line Used for buoy and sensor mooring systems. HGPC500i Chain, ½” Galvanized steel chain used for buoy moorings. A-3-RED Marker buoy, 18” diameter Used for 2-point and 3-point mooring systems. CB-400 Data Buoy User’s Manual... -
Page 8: Chapter 3 - Getting Started
CHAPTER 3 – GETTING STARTED Before deploying a CB-400 data buoy , it is very important for the user to become familiar with the hardware connections and operation of the system with iChart software. To begin, lay out the buoy, sensors, data logger, and other components that make up the CB-400 system. -
Page 9: Gathering Sample Data
Connect all sensors, power the system, and gather sets of sample data with iChart software. Refer to the SDL500 and iChart manuals for additional information on setup and testing of the software, data loggers and sensors. Systems may also ship with project-specific startup documentation provided by NexSens Customer Support. CB-400 Data Buoy User’s Manual... - Page 10 NexSens Technology, Inc. February 19, 2013 For troubleshooting assistance, the NexSens Knowledge Base contains detailed information on many of the most common issues that may be encountered: http://nexsens.com/knowledgebase/ NexSens tech support specialists may also be contacted for assistance: NexSens Technology, Inc.
-
Page 11: Chapter 4 - Buoy Setup
February 19, 2013 CHAPTER 4 – BUOY SETUP This section contains detailed instructions on the physical setup of a CB-400 buoy system. Directions are included for a complete CB-400S package with solar panels and RBP500 battery pack. For standard CB- 400 systems without solar charging, the process is the same, but all sensor connections are made directly to the SDL500 data logger. -
Page 12: Installing The Sdl500 Submersible Data Logger
SDL500 maintenance kit for future use. For CB-400S systems, Port P0 will always be used to connect to the RBP500 with the UW-1P cable. Remove the large orange O-ring at the bottom of the SDL500. Keep with the SDL500 maintenance kit. CB-400 Data Buoy User’s Manual... -
Page 13: Securing Buoy Lid
(the washer sits under the lock washer). Tighten the bolts until the lock washers are flattened, then an additional 1/8” turn. Do not over-tighten the bolts to avoid stripping of the threading on the lid and cap. CB-400 Data Buoy User’s Manual... -
Page 14: Setting Pipe Caps
SDL500 within the buoy. Port A is unavailable on the bottom side of the buoy because it serves as a top-side battery vent. The SDL500 manual contains detailed information on selecting ports for sensor connections. CB-400 Data Buoy User’s Manual... -
Page 15: Accessories
Figure 4-8: Sensor Connected to RBP500 Port P0 Accessories Deployment pipes, instrument cages and ballast weights can be added to CB-400 buoy systems. Deployment pipes and instrument cages provide options for secure mounting of sensors, and ballast weights can help to balance the buoy and prevent overturning. -
Page 16: Instrument Cage
February 19, 2013 4.2.2 Instrument Cage The CB-400 buoy allows an instrument cage to be installed on the bottom. Sensors can be securely attached to the instrument cage. To install the cage, first remove the 1-3/4”-10 x 4” bolt, 1-3/4” lock washer and 1-3/4”-10 nut from the buoy frame. - Page 17 On the bottom end of the rod, tighten a 1-3/4” eye nut with a 1-3/4” lock washer. Tighten the top end of the rod securely to the buoy frame or instrument cage with a 1-3/4”-10 nut and 1-3/4” lock washer. Weld the connections to prevent loosening in rough water. Figure 4-13: Securing the Ballast Weight CB-400 Data Buoy User’s Manual...
-
Page 18: Chapter 5 - Mooring The Buoy
NexSens does not endorse any particular mooring strategy for any application unless the end user performs a thorough review of the site conditions with the NexSens engineering team. -
Page 19: Two-Point And Three-Point Moorings
Stainless steel bow shackles are used to connect the various mooring components (mooring lines, marker buoys, chains and anchors) together and to the CB-400 buoy. Bow shackles must be properly connected and secured to prevent hardware from loosening and becoming detached over time in rough water conditions. - Page 20 Figure 5-4: Cable Tie Installed on Bow Shackle A 1/2” bow shackle is used to connect mooring lines to the CB-400 buoy eye nuts and to 1/2” bottom chains. Larger, 5/8” bow shackles are required for connection of marker buoys and anchors.
-
Page 21: Chapter 6 - Safely Deploying The Buoy
Pay out the mooring line from the marker buoy to the CB-400 as the boat is moved. Finalize sensor connections and apply power, then lift the buoy over the side of the boat and set in the water. -
Page 22: Chapter 7 - Maintenance
Next, the topside stainless steel eye nuts must be removed. Use a large wrench to loosen the eye nuts. Remove the eye nuts, lock washers and washers and store them in a safe location. Figure 7-1: Loosen Topside Eye Nuts CB-400 Data Buoy User’s Manual... - Page 23 RBP500 to the SDL500 through the center of the tower so that it can be reconnected to the SDL500. Before lowering the tower completely, reconnect the solar panel power cable to Port D of the RBP500. Important: Double check for O-rings on the UW connectors and inside the RBP500 and SDL500 ports. CB-400 Data Buoy User’s Manual...
- Page 24 Tighten the eye nuts using a large wrench and reinstall the buoy lid. For eye nut reinstallation, set a washer and lock washer onto the lid at each location. Tighten the eye nuts by hand or with a large wrench as needed to flatten the lock washers. Figure 7-5: Tightening Eye Nuts CB-400 Data Buoy User’s Manual...
- Page 25 Limitation of Warranty This warranty is not applicable to any NexSens Technology, Inc. product damage or failure caused by failure to install, operate or use the product in accordance with NexSens Technology, Inc. written instructions; abuse or misuse of the product; failure to maintain the product in accordance with NexSens Technology, Inc.
