- Page 1 OMEGA Separator Units Standen Engineering Limited. Hereward Works, Station Road, Ely, Cambridgeshire. CB7 4BP England. Tel: 01353 661111 www.standen.co.uk Fax: 01353 662370...
- Page 3 Therefore, some illustrations and/or text within this publication may differ from your machine. The copyright of this handbook is the property of Standen Engineering Limited, Hereward Works, Station Road, Ely, Cambridgeshire. CB7 4BP. This handbook is issued on the condition that it must not be used, copied or exhibited without their written...
- Page 5 Introduction to the Handbook This handbook provides the information for the installation, operation and maintenance of your Standen Omega Separator. To enable you to achieve the best results from the machine, the manufacturer recommends that you read the handbook thoroughly prior to using the machine for the first time.
-
Page 6: Replacement Parts
MUST NOT BE FITTED INTO THESE MACHINES IN THE PLACE OF THE EBONITE OR STEEL ROLLERS. Section 2 of this handbook contains a list of spare parts available through your Standen Agents. Each illustration shows a complete unit or assembly in exploded form. -
Page 7: Safety Precautions
SAFETY PRECAUTIONS Safety The Standen Omega Separators have been designed to comply with current Safety Regulations. However, as with all machinery there will be inherent dangers whilst operating and carrying out maintenance on the machine. The following safety precautions should therefore be brought to the attention of all persons operating and working on the machine. - Page 8 INSTALLATION AND OPERATION Omega Separator Installation and Operation The basic Omega unit consists of a row of polyurethane scrolls followed by a clod roller. The units are available with 2, 3 or 4 scroll shafts. A complete Omega separator assembly is made up of a series of these units to give the required area of separation.
- Page 9 INSTALLATION AND OPERATION The clod rollers will normally be adjusted to run approximately 1 to 2 mm away from the tip of the scrolls for effective haulm removal. The clod roller gap is set by adjusting the stop bolts (item 1, fig 2) against the spring tension on the clod roller mounting plates. Spring tension is adjusted on the spring tie bolts (item 2, fig 2).
-
Page 10: Maintenance
Lubrication Regular lubrication will ensure that the Standen Omega separator will have a long and efficient service life. Depending on soil and weather conditions, the service schedule can vary. It is recommended that the separator be given a thorough inspection at least weekly during the working season and at this time the machine should be greased and the gearbox oil levels checked.
