- Page 1 Item # : AF44JAMET Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Revised 11/05/2020 (I) Walker Edison ® Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
-
Page 2: General Assembly Guidelines
. Wipe away excess glue immediately. A Phillips head screwdriver is required for the assembly of this product . VII. Power tools should not be used to assemble this product . Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 3: Parts List
Parts List Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 4: Hardware List
Plastic strap Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©... - Page 5 Step 1 Insert wooden dowel (A) into part (2) and secure bolt (F) into part (4) as per diagram. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 6 Step 2 Using washer (G) and Nut (H) secure part (2) into part (4) with Wrench (J) as per diagram. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 7 Step 3 Using bolt (C) attach part (3) to part (4) with Hex key (D) as per diagram. Note:Do not fully tighten all bolts. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 8 Using washer (G) and Nut (H) secure part (2) into part (4) with Wrench (J) ,then using bolt (C) attach part (3) to part (4) with Hex key (D) as per diagram. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 9 Step 5 Using Flat head screw(B) secure part (2) to part (1) with Philips head screwdriver as per diagram. Note: Fully tighten all bolts. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 10 Step 6 Using screw (K) attach Velcro strap (M) into part (1) with Philips head screwdriver as per diagram. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. P.10 ©...
- Page 11 Wall Using screw (L) attach Velcro strap (M) into Nut (N) to wall with Philips head screwdriver as per diagram. Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. P.11 ©...
-
Page 12: Final Assembly
Step 8 Final Assembly Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. P.12 ©...
