S M A R T S C A N
EW534
Automist Smartscan
®
Handbook
Version 1.2.3
The Smartscan Handbook is designed to provide
stakeholders with essential information regarding
specification, installation, maintenance and commissioning
of the Automist fire protection device.
Supersedes – Automist Smartscan Handbook Version 1.2.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Automist Smartscan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Plumis Automist Smartscan

  • Page 1 S M A R T S C A N EW534 Automist Smartscan ® Handbook Version 1.2.3 The Smartscan Handbook is designed to provide stakeholders with essential information regarding specification, installation, maintenance and commissioning of the Automist fire protection device. Supersedes – Automist Smartscan Handbook Version 1.2.2...
  • Page 2: Table Of Contents

    Indirect Coverage ..............................21 Calculation of Effective Shadow Area ........................22 Worked Example ..............................22 Use of These Rules ..............................26 Automist Smartscan Known Heat Source Mitigation Procedure ..............27 Installation requirements ............................28 Spray Head Placement ............................29 Detection System ..............................29 INSTALLER GUIDELINES ..............................
  • Page 3 Post-installation checklist – Key points for installers and Building Control ............48 Maintenance ................................51 Cleaning ..................................51 Repair ................................... 51 Troubleshooting ................................51 Warranty ..................................54 Notes .................................... 55 APPENDIX A ................................. 56 APPENDIX B ................................. 62 Plumis Ltd Copyright © 2017. All Rights Reserved. Page 3 of 64...
  • Page 4: Introduction To Smartscan

    ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N INTRODUCTION TO SMARTSCAN Plumis Ltd Copyright © 2017. All Rights Reserved. Page 4 of 64...
  • Page 5: Introduction

    When this product has reached the end of its serviceable life, it should be disposed of in a safe • manner. IMPORTANT: Once installed, complete and submit an installation and commissioning form to Plumis. WARNING: To avoid hazards, all installation procedures and maintenance must be supervised by an Accredited Automist Smartscan Installer.
  • Page 6: Automist Smartscan Operation

    The high momentum vertical spray orientation with a horizontal trajectory ensures that even shielded fires are saturated with a turbulent flow of mist, suppressing the fire. In the event of a fire, Automist Smartscan is triggered automatically by a relay contact, provided by one or more heat alarms/detectors,...
  • Page 7: The Automist Smartscan System

    Handbook v1.2.3 S M A R T S C A N The Automist Smartscan System WRAS approved isolation valve Automist Smartscan supply label & cable tie ¾” single check valve Filter ¾” Stainless Steel Inlet Hose Automist Smartscan Pump Unit...
  • Page 8: Automist Smartscan Compliance And Fire Performance

    Control a Fire - "Room Fire Test for Watermist Systems with Automatic Nozzles" Document Reference 356258" can be downloaded from the Plumis website. For more details on the descriptive and performance requirements of BS 8458:2015 please see table 3 in Appendix A.
  • Page 9: Concept

    United Kingdom Water Byelaws. Company • Third Party Certification by BRE Global have established Plumis Limited have complied with the Quality Management Systems requirements of ISO 9001:2008 for the design, manufacture and supply of water mist fire suppression systems.
  • Page 10: How To Specify Smartscan

    ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N HOW TO SPECIFY SMARTSCAN Plumis Ltd Copyright © 2017. All Rights Reserved. Page 10 of 64...
  • Page 11: Use And Specification Of Automist Smartscan

    S M A R T S C A N Use and Specification of Automist Smartscan Automist Smartscan is intended to be used as an alternative to domestic/residential fire sprinklers or water mist system as it has been shown to have equivalent fire performance. Where guidance or fire engineering...
  • Page 12: Protected And Shadowed Areas

    Protected and Shadowed Areas Automist Smartscan will only operate at its maximum effectiveness when spray heads have collective visibility of all fire loads throughout the entire room to be protected, with a minimum of obstructions by furniture or indeed doors.
  • Page 13: Preferred Positions" And Avoidance Of Potential Obstructions

    Adjust until the effective shadow area is below the maximum square metreage for the project type (see below). The diagram (later submitted to Plumis) should show the Effective Coverage Area and state its area in square metres for each compartment to be protected.
  • Page 14 Where one or both sides of the spray pattern might be obstructed, either because a Preferred Position is not available, or because the Preferred Position is only guaranteed free from obstruction in one direction, Plumis Ltd Copyright © 2017. All Rights Reserved. Page 14 of 64...
  • Page 15 Figure 5: Installation in Preferred Position between window and wall. Use of preferred position ensures that insertion of a bookcase after installation has low consequences - grey shaded area is approximately 0.3m2. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 15 of 64...
  • Page 16 See for example Figure 8 and Figure 9. This principle applies only to unknown, potential obstructions. Known obstructions should be treated as creating simple shadows as per page 12. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 16 of 64...
  • Page 17: Example: At Front Of Built-In Cupboard

    If distance d is greater than 3m then the spray pattern is assumed unobstructed by potential obstructions to our right. See Figure 11 for example treatment of a kitchen worktop. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 17 of 64...
  • Page 18 If distance d is greater than 3m, the area on our left can be assumed free from potential obstruction. Note that this spray head does not protect the recessed area to the rear right. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 18 of 64...
  • Page 19: Example: Close To A Wall

    Figure 10: Spray head close to a wall. Any object to the (viewer’s) left of the spray head cannot obstruct other objects due to the limited space between the spray head and the wall. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 19 of 64...
  • Page 20: Example: Over Worktop

    Provided that the worktop and cupboard heights are suitable, the need to access a kitchen worktop guarantees its freedom from unplanned obstructions. Figure 11: Automist Smartscan head Preferred Position above kitchen worktop Plumis Ltd Copyright © 2017. All Rights Reserved.
  • Page 21: Areas Not Required For Coverage

    Indirect Coverage Because Automist Smartscan is activated only by heat detectors, the fires that it must tackle are inherently quite well-developed. Tests with obstructed views of fires have shown that a partial view of the developed fire is sufficient for Automist Smartscan’s sensor to locate the fire correctly, and that turbulent spray flow...
  • Page 22: Calculation Of Effective Shadow Area

    6m range view of all points, two heads are to be used and both could have potential obstructions on one side. The pattern is truncated where a known obstruction blocks the spray (see chimney breast, Figure 13 below). Plumis Ltd Copyright © 2017. All Rights Reserved. Page 22 of 64...
  • Page 23 In Figure 14 the areas not required for coverage are marked (staircases, doorways and a “0.8m doormat” from each of these). Figure 14: Areas not Required for Coverage Plumis Ltd Copyright © 2017. All Rights Reserved. Page 23 of 64...
  • Page 24 In Figure 15 the shadow areas are marked. In Figure 16 (detail in Figure 17) the shadow area is reduced to the Effective Shadow Area by expanding the actual coverage by 0.3m in all directions (to allow for Indirect Coverage). Figure 16: Indirect coverage marked (gold) Plumis Ltd Copyright © 2017. All Rights Reserved. Page 24 of 64...
  • Page 25 Area must be below 2m as this is an Approved Document B-style three storey open plan house. For other property types the area should be reduced below 1.1m Plumis Ltd Copyright © 2017. All Rights Reserved. Page 25 of 64...
  • Page 26: Use Of These Rules

    Plumis accredited installers are trained to specify, install, commission and maintain the Automist Smartscan system. Their early involvement in the project is recommended as they are required to verify installation proposals, provide critical supporting technical information and also commissioning certificates for project approval by Building Control or other involved third parties.
  • Page 27: Automist Smartscan Known Heat Source Mitigation Procedure

    ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N Automist Smartscan Known Heat Source Mitigation Procedure Object Type Positional Constraints Radiator or heated towel rail, within 180° field of No constraints. view of spray head, with height less than 800mm No point on the radiator must be closer than 3.0m...
  • Page 28: Installation Requirements

    A cold water supply which can deliver 6 litres per minute flow at a minimum of 1 bar (100kPa) and a • maximum of 10 bar (1MPa) static pressure. If multiple Automist Smartscan units are to operate simultaneously, a proportionately higher flow will be required.
  • Page 29: Spray Head Placement

    S M A R T S C A N Spray Head Placement The Automist Smartscan Head is designed to be affixed into a rectangular hole (89+/-2mm wide x 117mm high) that is at least 57mm deep when using the “old work” clips provided.
  • Page 30 DO NOT trigger Automist Smartscan from a manual call point. • DO NOT connect the Automist Smartscan pump’s alarm input to any device other than a volt free • relay. In particular, connecting the three coloured cables to the alarm interconnect or to any power supply whatsoever is likely to damage the Automist Smartscan pump beyond repair.
  • Page 31 Ensure Automist Smartscan is only connected to the main heat alarm(s) in the volume it protects. You can check these interconnections using the product’s ALARM TEST MODE (see page 44). In this mode, the alarm lamp will light to indicate a functioning alarm input.
  • Page 32: Installer Guidelines

    ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N INSTALLER GUIDELINES Plumis Ltd Copyright © 2017. All Rights Reserved. Page 32 of 64...
  • Page 33: Installation Procedure

    A suitable tool for tightening BSP hoses • A set of screwdrivers including Torx bits • A suitable electric drill • Electrical cable • A pressure gauge kit • A commissioning kit Plumis Ltd Copyright © 2017. All Rights Reserved. Page 33 of 64...
  • Page 34: A) Preparing The Site

    Components of the fire detection and alarm system may use this circuit, which must remain powered in the event of a fire. Power to Automist Smartscan must be provided via an unswitched fused connection unit (FCU). Automist Smartscan should be supplied using FP200 cable or better, ideally inside conduit or protected 50mm deep within a wall, and with no RCD or RCBO protection.
  • Page 35: B) Installing The Automist Smartscan Head

    Automist system. Many options for such an alarm are available and Plumis recommends the purchase of an inexpensive alarm from Amazon, using the following link: https://www.amazon.co.uk/gp/product/B01GE3NDB4/ref=pd_cp_107_1?ie=UTF8&psc=1&refRID=REA5Y9F0R...
  • Page 36 Attach and fasten the front plate to the intermediate plate and align, ensuring parallelism to floor • and wall. You can align the Front Plate in reference to the floor at this stage. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 36 of 64...
  • Page 37 ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N Front plate Plumis Ltd Copyright © 2017. All Rights Reserved. Page 37 of 64...
  • Page 38: C) Connecting The Water Supply

    IMPORTANT: If new pipe has been fitted, remember to flush out any contaminants before connecting to Automist Smartscan, to avoid clogging the nozzle. Connect the high pressure hose from the assembled head to the outlet on the pump. Plumis supplies suitable high-pressure hoses. If using another brand of hose, follow Plumis’s guidance note, available on the Plumis Partner Site.
  • Page 39 Test Point o-ring The Automist Smartscan pump unit should be housed close to a 3/4” BSP water supply with an approved isolation valve to the check valve. A synthetic rubber washer is supplied with each device to facilitate fitting to the flat-faced outlet.
  • Page 40 Note: If the filter has a paint mark running over the cap and body (as in the image below), then the o-ring has already been lubricated and the connection adequately made by Plumis. Plumis Ltd Copyright © 2017. All Rights Reserved.
  • Page 41: D) Other Electrical Connections

    For installations that require a wireless relay receiver, position the relay base on the wall next to the Automist Smartscan pump unit, as close as possible to the front of the cupboard door. IMPORTANT! Connecting the power requires a suitably qualified & competent person. Switch off electricity at the mains before working on existing circuits.
  • Page 42 Handbook v1.2.3 S M A R T S C A N General wiring arrangement for Automist Smartscan. In most installations the remote STOP is not installed and the associated wire loop remains intact as supplied. The Smartscan spray head connects to the pump using a Smartscan Head Cable as specified above (p35).
  • Page 43 (see diagram above). The button should have an appropriate IP rating (e.g. IPX5 if used in the room protected by Automist Smartscan), located as close to the pump as possible and should be clearly labelled. The auxiliary button cannot be used to commission the unit but can be used to enter ALARM TEST MODE (see page 49).
  • Page 44: E) The Automist Smartscan Controls

    E) The Automist Smartscan Controls STOP Button: Pressing the STOP button during a fire condition will stop the Automist Smartscan pump for 2 minutes. If at the end of 2 minutes, an alarm input remains active, Automist Smartscan will recommence mist operation.
  • Page 45: F) Commissioning And Maintenance

    Commissioning must be performed annually by an Accredited Automist Smartscan Installer. When Automist Smartscan is powered up for the first time the yellow FAULT LED will flash twice to indicate that the system has not been commissioned. Commissioning is a simple programmed procedure which allows Automist Smartscan to be tested.
  • Page 46 020 7871 3899 if the situation cannot be resolved. Following a successful pressure test, the high pressure hose must be cleared of water by connecting a suitable pump to the Plumis supplied attachment, that is connected to the test point tee.
  • Page 47 Place the two warning stickers and the commissioning label: Label the separate circuit on the circuit breaker • Label the heat alarm that triggers Automist Smartscan, preferably near the test button • Complete the installer commissioning label and affix to your Automist Smartscan unit •...
  • Page 48: Post-Installation Checklist - Key Points For Installers And Building Control

    50mm deep within a wall • Automist Smartscan may be protected by an RCD or RCBO but this protection must not be shared with other circuits. Therefore, Automist Smartscan should be connected to the non-protected side of the consumer unit.
  • Page 49 The Installer Commissioning form should have been provided (can be obtained from Plumis or the installer) with a matching layout drawing The Plumis Warranty Certificate is provided (can be obtained from Plumis) once the layout has been submitted and approved by Plumis.
  • Page 50 ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N SMARTSCAN CARE Plumis Ltd Copyright © 2017. All Rights Reserved. Page 50 of 64...
  • Page 51: Maintenance

    CAUTION! Do not attempt to repair the Automist Smartscan wall head or pump unit. Doing so will invalidate your warranty. Automist Smartscan should be serviced or replaced if any part of the system, including any heat alarms, has been exposed to fire conditions.
  • Page 52 Five beeps indicates a problem with the spray head. Check the cabling. Six, seven, eight, nine or ten beeps – contact Plumis Technical support Plumis Ltd Copyright © 2017. All Rights Reserved.
  • Page 53 Pump damaged in alarm condition by pressing STOP on the pump. transit If Automist Smartscan is not triggered, power off the system and replace the relay with a two-way a.c. light switch. The NO and NC terminals on the switch will normally be labelled L1 and L2 (both L1 and L2 terminals must be present and connected).
  • Page 54: Warranty

    If the product is found to have failed for reasons outside our warranty cover Plumis may quote to repair the unit and return it. Where products are replaced or repaired under warranty, they will be returned to a UK address free of charge.
  • Page 55: Notes

    ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N Notes Plumis Ltd Copyright © 2017. All Rights Reserved. Page 55 of 64...
  • Page 56 ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N APPENDIX A Plumis Ltd Copyright © 2017. All Rights Reserved. Page 56 of 64...
  • Page 57 6.3 System Design Descriptive System is a dry pipe system. Does not impact b) should be a wet performance and avoids pipe system. risk of Legionella Plumis Ltd Copyright © 2017. All Rights Reserved. Page 57 of 64...
  • Page 58 Dry pipe avoids Legionella supply risk. requirements 6.8.2 Water Supplies Descriptive Automist is always supplied from Complies with water can be from a mains supply boosted by requirement. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 58 of 64...
  • Page 59 (system flow and integrity tested at nozzle) c) drain valve not required as open nozzle (quick disconnect used for water purge) Plumis Ltd Copyright © 2017. All Rights Reserved. Page 59 of 64...
  • Page 60 Annex C. Room fire Performance System has been tested in Complies with tests accordance with requirements of performance. Annex C and meets all performance criteria. Table 3: BS 8458 Compliance table Plumis Ltd Copyright © 2017. All Rights Reserved. Page 60 of 64...
  • Page 61 ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N Plumis Ltd Copyright © 2017. All Rights Reserved. Page 61 of 64...
  • Page 62 ® Automist Smartscan ® Handbook v1.2.3 S M A R T S C A N APPENDIX B Plumis Ltd Copyright © 2017. All Rights Reserved. Page 62 of 64...
  • Page 63 Reduction in periods of fire resistance Table 4 Not applicable External fire spread and doubling 18.4e) Not applicable unprotected areas Where buildings are not provided with fire 50.1.2 Not applicable mains Plumis Ltd Copyright © 2017. All Rights Reserved. Page 63 of 64...
  • Page 64 Balcony escape where no construction is C.2.1 Not applicable provided between a balcony and an atrium Table 5: BS 9991 Not applicable applications of Watermist Systems Plumis Ltd Copyright © 2017. All Rights Reserved. Page 64 of 64...
