5.1.2. Mode 2 Settings.

The setting parameters may be changed in mode 2.
Data Displayed
t6x Setting
Full Load Current I FLC
CT Primary Setting In
Hot / Cold Ratio
Thermal O/L Pre-Alarm
E/Fault Current, %In
Earth Fault Time
NPS Current, %FLC
Low Set O/C, %FLC
Low Set O/C Time
High Set O/C, %In
High Set O/C Time
Undercurrent, %FLC
Undercurrent Time
Number of Starts/hr
Start Inhibit Time
Set Password
Serial Link Address
Set Trip Relay Action
Set Program. Relay
Set Alarm Relay Action
Set E/Fault Parameters
Set Trip Reset Action
Set Thermal O/L Curve
Set Speed Switch
Advanced Relay 1.
More detail on these parameter are available in the Setting Section.
14/1/98
LED No/ Colour
1/ Green
1/ Green - Flashing
9/ Green - Flashing
9/ Green
1/ Green/Orange -Alternating
2/ Green
2/ Green - Flashing
3/ Green
4/ Green
4/ Green - Flashing
5/ Green
5/ Green - Flashing
6/ Green
6/ Green - Flashing
7/ Green
7/ Green - Flashing
8/ Green
8/Rsnn on display
Tnnn on Display
Pnnn on Display
Annn on Display
Ennn on Display
Rnnn on Display
Cnnn on Display
Snnn on Display
Xnnn on Display
