- Page 1 INSTALLATION AND OPERATION MANUAL Q.FLAT-G6 Flat roof system for south orientation...
-
Page 2: Table Of Contents
4.4.4 BALLAST TROUGH TYP V02 O FIT MIDDLE AND END CLAMPS F AND SCREW MODULES TOGETHER REAR PANEL OPTIONAL STEP 4.7.5 MOUNTING THE SIDE COVER O FINAL INSPECTION INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 3: General Safety Information
Î The Q.FLAT-G6 flat roof system is only permitted for use on flat roofs. The Q.FLAT-G6 may only be used with Q CELLS solar modules with the dimensions 1673 mm × 1030 mm × 32 mm (e.g. Î Q.PEAK DUO BLK-G9), 1840 mm × 1030 mm × 32 mm (e.g. Q.PEAK DUO ML-G9) and 1740 mm × 1030 mm × 32 mm (e.g. -
Page 4: Required Material
Ballast trough V01 / V02 V01: Assembly after adding the bulk material middle and end clamps V02: Assembly before adding the bulk material Rear panel Side cover 10° INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 5: Required Tools
REQUIRED TOOLS REQUIRED OPTIONAL Rubber hammer Tape measure Chalk line Torque spanner with SW5 hexagon socket attachment INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 6: Assembly
ASSEMBLY Just 5 steps to the finished system Required Optional INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 7: Lay Out Base Profiles A And B; Connect And Erect
INFO All Q CELLS base profiles are fitted with 11 mm thick high-tech protective mats. The gaps between the protective mats ensure free water drainage. The protective mats prevent damage to the roof covering due to mechanical impact and long-term damage due to plasticiser migration. -
Page 8: Assemble The Centre Components Tower C And The Rear Panel Tower
ASSEMBLE THE CENTRE COMPONENTS TOWER C AND THE REAR PANEL TOWER H. INFO The component towers serve as upper support elements for the modules in all Q CELLS systems, the rear panel towers serve as support elements for the rear panel. Procedure: Î... -
Page 9: Mount Connecting Component Cross Brace And Ballast Brace D
Note: The cross brace must always be mounted on the tower. The cross brace and ballast brace must always be inserted on the tower as far as the marking. INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 10: Optional Step
INFO In order to protect the string lines from permanent and damaging environmental influences, especially UV radiation, all Q CELLS base profiles have cable duct cover receptacles. The installation of the cable duct covers is possible after each work step of the system assembly. -
Page 11: Ballast Block
40 × 40 × 4 cm; if the dimensions of the blocks differ, manual adjustment may be necessary on site. Deviations from the planning must always be agreed with Q CELLS and only carried out after written approval. - Page 12 Deviations from the planning must always be agreed with Q CELLS and only carried out after written approval. The position of the ballasting elements must be selected in such a way that slipping down, tilting or wobbling is permanently prevented.
-
Page 13: Ballast Trough Typ V01
. Ensure even coverage in the trough ATTENTION Ensure minimum cover in the trough according to the planning documents! The maximum fill height must not exceed 70 mm. INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 14: Ballast Trough Typ V02
Six screws per trough are to be inserted centrally, evenly distributed. Observe the maximum torque of 5 Nm! ATTENTION Ensure minimum cover in the trough according to the planning documents! The maximum fill height must not exceed 70 mm. INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 15: Fit Middle And End Clamps F And Screw Modules Together
Observe the tightening torque of 10 Nm. (Please observe the note MAINTENANCE.) NOTE: Care must be taken not to excessively press the clamps too far and thus bend them. INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 16: Rear Panel
M8x16 screw. Observe the tightening torque of 10 Nm. ATTENTION The direction of work from east to west must be adhered to 1 4… INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 17: Optional Step
The side cover is a component relevant to stability. Omission of the side covers specified in the project report will inevitably lead to an exclusion of liability by Hanwha Q CELLS GmbH. INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... -
Page 18: Final Inspection
(maintenance interval at least once a year, observe the maintenance log). Changes and deviations from the planning documents must be agreed in writing with Hanwha Q CELLS GmbH! INSTALLATION AND OPERATION MANUAL FOR FLAT ROOF SYSTEM Q.FLAT-G6 – Q CELLS... - Page 19 +49 (0)9225 9550 - 999 EMAIL info@pmt.solutions www.pmt.solutions HANWHA Q CELLS GMBH OT Thalheim Sonnenallee 17 – 21 06766 Bitterfeld-Wolfen Germany +49 (0)3494 66 99 – 23222 +49 (0)3494 66 99 – 23000 EMAIL sales@q-cells.com www.q-cells.com Subject to change © Q CELLS Installation_Instructions_South_Orientation_Q.FLAT-G6_2021-01_Rev01_EN...
