10.3. Removal of battery
To charge the battery from version 1.1 / reinforced battery nest must be removed. To remove battery
turn keys counterclockwise and fold battery in forward direction. Battery can now be removed and
replaced to the front / top.
To assemble the battery first insert the battery pack down and then lock at turning the key into place
above.
Attention / handle with care!
Always make sure before driving that battery will completely have locked in, as well as to have
removed the key; Otherwise battery could get lose when driving.
10.4. Charger and charging of battery
Always double-check if voltage on power outlet matches voltage permissible for your charger! The
voltage permissible when connecting chargers to power outlets is marked on nameplate of your
charger. For Europe this is 110-230V / 50-60Hz.
Outside of EU appropriate chargers should be used in accordance with national regulation. (See details
on charger/installation of battery)
At all times try to avoid mechanically damaging device (risk of explosion!). Do not recharge
battery in proximity of inflammable items. And do not cover charger with any item.
When charging within the area of EU, only the charger supplied on delivery should be used.
Beware!
The same applies for technically flawless extension cables – always handle with care. Charger should
only be used indoors. Avoid exposure of charger to water or humidity. In case of sudden change in
temperature from cold to warm, condensation may result. In the latter case, please wait for charger to
attain warmer room temperature prior to connecting charger with power plug. Try to prevent such
situations while keeping / storing charger where device is being charged.
Keep all items away and out of vents to prevent electrical shock. Pull the plug on charger once
charging has been completed.
Protect charger from potential blows. In case of potential damage, e. g. after falls, bring to your
retailer to make sure it is being double-checked, tested – even if externally no apparent damage may
be visible.
Charger needs to remain out of reach for children!
It is forbidden to manipulate charger and battery. Manipulation will lead to all warranty being voided.
Charger should only be used together with the battery supplied on delivery.
11. Maintenance
To be able to keep enjoying MySlave for a long time, regular and diligent maintenance is a must. Prior to
each maintenance, check all mechanical connections. Make sure all electrical connectors are safely
connected. Prior to each and every single ride, make sure to examine efficiency of manual drum brake(s).
Mechanical components:
As a general guideline, all screws on non-removable components need to be pulled (Allen
key SW6).
Tighten grub screws of adapter unit with particular care to avoid twisting of adapter unit.
The specific torque required for individual screw connections can be taken from corresponding torque list
in enclosures to this manual.
