- Page 1 METAL SEPARATOR MESEP® VA digital 50/ 70 Manual Project Name Order / Project No. Metal separator type MESEP VA digital 70 The final outlook of the units depends on the different features we offer.
-
Page 2: Table Of Contents
Contents CONTENTS..........................2 GENERAL ............................3 ................3 NSTRUCTIONS FOR SE OF THIS ANUAL ...................4 ENERAL AFETY NSTRUCTIONS 2.2.1 Explanation of the Symbols Used..................4 2.2.1 ......................5 ASIC AFETY EASURES APPLICATION AND QUALIFICATION ................6 ....................6 SE FOR NTENDED URPOSE ....................7 XAMPLES OF PPLICATION ......................7 PERATING RINCIPLE ...........................7... -
Page 3: General
ANNEX ...........................35 General Instructions for Use of this Manual This manual applies to MESEP® VA digital50/70 Manufacturer: Pulsotronic GmbH & Co.KG Neue Schichtstr. 14 09366 Niederdorf Phone: 03 72 96 / 930 100 Fax: 03 72 96 / 930 180 Edition: October 2004, v. -
Page 4: General Safety Instructions
Notice: Pulsotronic GmbH & Co. KG does not grant implied warranty for commercial quality and suitability for a particular purpose of application. This document contains copyrighted information. Without Pulsotronic GmbH & Co. KGs prior permission, it may neither be copied nor duplicated, translated or digitally stored. -
Page 5: Basic Safety Measures
2.2.1 Basic Safety Measures • Do not put your hand into the openings of the metal separator. Mechanical forces which may cause heavy injuries occur on switching of the pneumatic gate. • Prior to any maintenance works, disconnect the equipment from compressed air and power. -
Page 6: Application And Qualification
Application and Qualification Use for Intended Purpose The MESEP® VA digital removes metallic contaminations from bulk materials. These materials, for example, can be plastic granules, dry powder, rice or similar products from different industries. Free-fall metal separation: The unit is integrated in the existing conveying system. To guarantee reliable separation, the material must not be dropped into the device from a height of more than 600 mm. -
Page 7: Examples Of Application
semi-finished and finished products industries etc. The 8217 type metal separators are used amongst others at places where long equipment running times are required. The high sensitivity of the separators guarantees shortest possible machine downtimes and metal-free final products according to nominal sensitivity. Especially there where the final products cost effectiveness comes from the quantity, the unit pays for itself within short time. -
Page 8: Owners Duty Of Care
• modifying the metal separator without permission by Pulsotronic SKS GmbH & Co. KG to for the use for other purposes. Consider that after a modification you may be regarded as manufacturer of the metal separator - with all guaranty consequences. - Page 9 the MESEP digital works without problems. • Red LED „VALVE FAULT“ After the last metal detection the separating drum did not reach the end position. The MESEP digital can not separate the detected material. As soon as the separating drum switches perfect again after a further metal detection, the error report goes out automatically.
-
Page 10: Key Functions
Notice: A part of the inscription of the keypad is exchangeable. Cautiously use tweezers to find the small gap at the right side of the keypad. Widen the gap a little and remove the label. Every unit comes with labels in German, English and French. The unit is supplied with labels in German. -
Page 11: Selection Of Operation Variants
3.5.3 Selection of Operation Variants The electronic P.C. board includes four DIP switches. These switches serve to activate or deactivate some basic operation variants. During normal operation, a change of the DIP switch positions is not required. Funktion DIP 1 Working frequency of 295 kHz 290 kHz... -
Page 12: Sensitivity Table
3.6 Sensitivity Table The currently selected sensitivity is indicated by means of the four horizontally arranged yellow LEDs at the front plate. Example: After pressing of F1+ or F2- buttons the diodes 3 and 4 light for approximately 5 seconds. The actual values of response sensitivity is 2.5 mm. This corresponds to stage 6, i.e. -
Page 13: The Separating Drum
For non-magnetic high-grade steel applies: The FE St37 value from the table, multiplied by 1.5, is the approximate response sensitivity of a high-grade steel bullet. Notes for the values of sensitivity Notice: The sensitivity values apply to the centre of the detection ring, because, for technical reasons, there is the lowest sensitivity. -
Page 14: Operating Instructions For The Metal Separators
activation is the reliable separation of metallic particles of any size. A sticking of the separating unit will be prevent. The material discharge is reduced to a minimum by this new technology. At the end of this variable time the separating drum switches back again to the Ok position. -
Page 15: Operation Instructions
Operation Instructions • The metal separator should be permanently on. This will provide maximum lifetime of the electronic circuits. Failure Protection of the Metal Separator The metal separators mains inlet is protected against disturbing influences. Increased operation safety and additional protection against failures is reached applying the following measures: •... -
Page 16: Technical Characteristics
Technical Characteristics Article number MESEP VA digital 50 MESEP VA digital 70 Optional with connection control* Operation voltage 85V – 264 V AC Mains frequency 47Hz - 440Hz oder DC Power drain < 40 Watts Permissible operation temperature 0°C – 60°C Permissible product temperature max. -
Page 17: Technical Description
* Connection monitoring Units with this function have an additional solenoid valve and a return spring in the pneumatic cylinder. In case of compressed-air failure, the return spring brings the sorting gate into the NOT OK position. The second, additional solenoid valve acts only if main voltage is available. -
Page 18: Selection Of Operation Variants
Selection of Operation Variants The printed circuit board behind the front plate includes a potentiometer. It is used to adjust the separation time after metal detection. At supply, the device is adjusted for an average separation time of approx. 1 sec . The separation time should be adjusted according to quality and flow speed of the material to be handled. -
Page 19: Notes For The Values Of Sensitivity
Notes for the values of sensitivity Notice: The sensitivity values apply to the centre of the detection ring, because, for technical reasons, there is the lowest sensitivity. The measuring method analyses not only height and width, but also the depth of the metallic particle. This leads to a fact which applies to all conventional, analog metal-separating systems: Not the weight, but the size of the particle is decisive for the detection accuracy. -
Page 20: Product Effects - Disturbing Product Properties
• coil for generation of a high frequency magnetic field • a following evaluation electronics If metal or other conductive material move through the ring coil, the magnetic field is influenced. This influence changes the level of the electric current. This process is called electromagnetic induction. - Page 21 The electrical resistance of distilled water is unlimited, provided that it is pure, distilled water. Distilled water contains neither salts nor minerals. Dissolved salt changes the electric resistance so much that the solution gets electrically conductive. Similarly, conductive properties can be observed in some plastics due to additives. Raw materials are more or less conducting.
-
Page 22: Transport
Transport Safety Instructions for Transport and Erection Danger! To avoid damages to health and equipment during transport and erection of the metal separator, strictly observe the following: • Transport and erection may only be executed by qualified personnel, observing the relevant safety instructions. -
Page 23: Connectors
Item No.: 8214-0700 High-grade steel hoppers metal Material feeder as fixed intake hopper sensors 8217-xxxx 8219-xxxx, volume: 35 l Connectors material intake NOT OK discharge OK discharge (downward) -
Page 24: Sample Of Application
8.3 sample of application Metal separator for removal of metallic contaminations from plastic granules during octabine filling. MESEP® standard with mounted high-grade steel material hopper Prevent mecanical hart shocks. Install the unit solid with your installation frame. Install the unit vertical and not in a sloping position .See the picture above. -
Page 25: Electrical Connection
Electrical Connection The terminal strips are behind application. Fault signal Metal signal Mains voltage N P E P E L 1 L 1 N F u se The terminals of the relays on the power pack circuit board are connected as follows and have the below shown switching conditions during the operation: Switching conditions of the relays... - Page 26 Terminal assignment Terminal Designation Function Technical characteristics 1+ 2 digital inlet 1 normally open contact not available 3 + 4 digital inlet 2 normally open contact not available 5 + 6 compressed-air control normally open contact not available PNP inlet proximity initiator of gate +24V connected by manufacturer...
- Page 27 Terminal assignment Terminal Designation Function Technical characteristics At relay failure, terminals floating two-way switch, relay: failure 31+32 are closed and 31+34 are open max. 250 V / 5 A on metal detection, terminals relay: metal floating two-way switch, 41+42 are open and 41+44 are closed max.
-
Page 28: Printed Circuit Board
8.5 Printed Circuit Board The MESEP digital includes a blue terminal box in which the printed circuit board is located. It consists of two boards arranged one above the other. The bottom board serves for the power supply. The upper board serves for evaluation of the measured value and excitation of all external components. -
Page 29: Factory Setup
8.6 Factory Setup Ø maximum sensitivity (corresponds to Fe bullet 0,5mm for the 50model / 0.7 mm for the 70model) Ø separating time approx. 1 sec Ø input filter set up for maximum detection speed Ø working frequency of ring detector is 295 kHz (DIP1 = ON) Ø... -
Page 30: Maintenance
Maintenance 9.1. General Maintenance The metal separator is a sensitive measuring instrument. Erection and operation are described in this manual. Usually, the metal separator works safely and reliably without requiring further adjustments after commissioning. Necessary replacements of parts of the metal separator or adjustments are decisively depending on the use conditions. -
Page 31: Repairs And Wearing Parts - Important Notice
On the other hand, repairs of metal detectors and electronic modules must be carried out by PULSOTRONIC because only proper workmanship is a guaranty to achieve the device-specific sensitivities. It should also be kept in mind that only repairs carried out by PULSOTRONIC are guaranteed. Orders... -
Page 32: Removal Of The Laminated-Paper Protective Tube
We recommend to abtain suitable metal test bullets from Pulsotronic. These test bullets are encasted in plastic cubes, and the bullet sized is engraved. Test bodies are available for every type of metal separator. -
Page 33: Troubleshooting
• The metal test bullet should have the smallest detectable diameter. To perform the test, the bullet is sent together with the material through the metal separator to check, whether metal is signalised. • The test schedule defines when and by whom the metal separator has to be checked. -
Page 34: Accessories
• • Fuse (0.5 A, slow-blow) Replace fuse acted The fault cannot be eliminated ? Please contact Pulsotronic (see Annex,chapter 13) Accessories 9513-4000 Hopper magnet for metal separators This hopper magnet is laid into the 8210-xxxx, 8211-xxxx, 8212-xxxx, 8217- hopper, and it retains all magnetic xxxx and 8219-xxxx matters. -
Page 35: Spare Parts
In case of technical questions, please contact the MESEP production or MESEP despatch department of our main office. Contakt : Phone: 0049 (0) 3 72 96 / 930 –100 (exchange) Fax: 0049 (0) 3 72 96 / 930 –180 (exchange) Internet: www.pulsotronic-sks.de Mail: info@pulsotronic-sks.de...
